Explore the ZEISS LSM 990 for advanced imaging with superior depth and label separation capabilities. Utilizing Airyscan, achieve unprecedented resolution and flexibility in microscopy applications.
Unlock Instant Volume Imaging with ZEISS LSM 990
Key Takeaways
- Research focus: Confocal imaging with high label separation.
- Model system: Versatile platform for diverse imaging needs.
- Research goal: Enhance imaging depth and resolution.
- Presented by: ZEISS product experts.
- Content type: Product Overview on advanced imaging solutions.
separate over 10 fluorescent labels in one go – to allow every one of them to tell
processes. Whether you're investigating flow in microfluidic systems or studying
your creativity in experimental design and advance your
Your ZEISS LSM 990 can be configured in many different ways depending on your imaging requirements, from a pure confocal system to an imaging platform that
integrates all available modalities. If you want to utilize specific strengths for your most demanding applications, we recommend choosing one of the following
Airyscan takes the confocal idea beyond its conventional implementation: Instead of light passing through a pinhole to reach a single detector, Airyscan consists of
or 1 or 2 PMA Hybrid detectors (QE 45 % typical @550 nm); 80 MCps sustained count rate, without afterpulsing, spectral detection range from 300 nm to 720 nm, timing resolution (IRF) typically 120 ps (FWHM),
MultiHarp 150 4P for time-correlated single photon counting (TCSPC) with 5 ps temporal resolution (time bin width), 65536 time channels, 80 MCps sustained countrate sum over all input channels,
1500 MCps peak count rate (for burst duration up to 1.3 μs), 0.65 ns dead time, 4 fully independent input channels and common sync channel for synchronization with excitation source (up to 1.2 GHz sync rate)
rapidFLIMHiRes fast data acquisition, counting of several photons per excitation pulse for up to 15 FLIM frames per second
Your microscope system from ZEISS is one of your most important tools. For over 175 years, the ZEISS brand and our experience have stood for reliable equipment
with a long life in the field of microscopy. You can count on superior service and support – before and after installation. Our skilled ZEISS service team makes sure
Not for therapeutic use, treatment or medical diagnostic evidence. Not all products are available in every country. Contact your local ZEISS representative for more information.
EN_41_011_339 | Version 1.0 | CZ 03-2025 | Design, scope of delivery, and technical progress subject to change without notice. | © Carl Zeiss Microscopy GmbH
