AI for Advanced Image Analysis — Full Text Extract (ZEISS arivis)
_Source: uploaded PDF. Extracted text; images/figures not included. Page headers inserted for easy navigation._
— — — — — — — — — — — — — — —
Page 1
AI for Advanced Image Analysis
A Practical Guide for Microscopy Analysis
with ZEISS Software
— — — — — — — — — — — — — — —
Page 2
_(No extractable text on this page.)_
— — — — — — — — — — — — — — —
Page 3
_(No extractable text on this page.)_
— — — — — — — — — — — — — — —
Page 4
Foreword
As the CEO of Carl Zeiss Microscopy, a global
leader in microscopy and imaging solutions, it
gives me great pleasure to introduce this book
on AI for image analysis. We at ZEISS believe
that technology can be a powerful tool for
driving innovation and advancing science and
we are proud to be leading the charge in the
field of microscopy and imaging solutions.
This book is not just a collection of technical
information: it is a source of inspiration for
anyone who wants to unlock the full potential
of AI in microscopy. Using Machine Learning
and Deep Learning, we can now achieve
results that were once thought impossible.
The examples and case studies included in this
book are a testament to the transformative
power of AI in image analysis.
At ZEISS, we are committed to pushing the
boundaries of what is possible and we are
proud to be at the forefront of this exciting
new field of AI-powered image analysis.
Whether you are a researcher, clinician, or
engineer, I believe this book will be a valuable
resource for unlocking the full potential of AI in
microscopy for you.
Dr. Michael Albiez
Member of the Management Board IQR &
Head of SBU RMS ZEISS
President & CEO Carl Zeiss Microscopy GmbH
“We at ZEISS believe that
technology can be a powerful
tool for driving innovation and
advancing science and we are
proud to be leading the charge
in the field of microscopy and
imaging solutions.”
— — — — — — — — — — — — — — —
Page 5
“AI and Machine Learning
are transforming the fi eld of
image analysis, and this book
provides a comprehensive
guide to these powerful new
technologies.”As the head of sales and service for Carl Zeiss
Microscopy, I am excited to introduce this
book on the power of AI for image analysis.
Our teams work tirelessly with our customers
to provide the tools and support needed
to achieve their goals, and AI technology
is a game-changer that can supercharge
their success. AI and Machine Learning are
transforming the fi eld of image analysis, and
this book provides a comprehensive guide to
these powerful new technologies. It covers the
basics of AI and provides practical examples
of how to apply these concepts to microscopy
image analysis.
At ZEISS, we believe that AI can make our
customers’ lives easier by reducing manual time
overhead in their workfl ows, both in terms of
microscope hardware and software. We are
proud to be pioneers in this exciting fi eld and
hope that our book will inspire and empower
others in the microscopy community to take
advantage of the incredible benefi ts of AI.
Martin Fischer
Head of Global Sales & Service
ZEISS Research Microscopy Solutions
— — — — — — — — — — — — — — —
Page 6
Contents
Foreword .............................................................................................................................. 4
What is AI and why does it matter? ..................................................................................... 8
Why you need AI in your research ......................................................................................................... 8
AI, Machine Learning, and Deep Learning: What is the difference? ....................................................... 9
Conventional Machine Learning vs. Deep Learning for image analysis .................................................. 9
Microscopy image analysis automation powered by AI ....................................................................... 11
No-code products from ZEISS.............................................................................................................. 11
An introduction to image segmentation ............................................................................ 14
What is image segmentation? ............................................................................................................. 14
Algorithms for image segmentation .................................................................................................... 14
Machine Learning segmentation techniques .......................................................................................... 15
Deep Learning algorithms for image segmentation ............................................................................. 16
The ZEISS software ecosystem ............................................................................................................. 17
AI in ZEISS arivis software for scalable automated analysis .............................................. 18
Training Deep Learning models using ZEISS arivis Cloud ...................................................................... 18
Tips for achieving a reliable Deep Learning model ............................................................................... 21
Using AI-trained models in applications .............................................................................................. 23
AI in ZEISS arivis Pro for automated image analysis .............................................................................. 24
Machine Learning for object classification in ZEISS arivis Pro ............................................................... 33
Deep Learning for denoising multi-dimensional datasets .................................................................... 34
AI in ZEISS arivis Hub for scalable image analysis ................................................................................. 36
— — — — — — — — — — — — — — —
Page 7
AI in ZEN and ZEN core imaging and analysis platform ..................................................... 42
Preconfigured workflows in ZEN and ZEN core ................................................................................... 42
AI-based image segmentation in ZEN and ZEN core ............................................................................ 43
Advanced AI tools for image analysis beyond segmentation ............................................................... 45
Harnessing AI in automated image analysis workflow s ....................................................................... 48
AI for routine image analysis using ZEISS Labscope .......................................................... 56
The potential role of AI tools in routine image analysis ............................................................................ 56
Overcoming limitations of AI tools ...................................................................................................... 57
The role of AI tools for determining cell confluency ............................................................................ 57
How AI can help with cell counting ..................................................................................................... 59
The benefits of AI in routine image analysis ........................................................................................ 60
AI for X-ray microscopy with Deep Learning-based reconstruction ................................... 62
Drawbacks of generating 3D reconstructions from 2D sample sections .............................................. 62
X-ray microCT: A versatile tool for non-destructive 3D characterization across scientific domains ....... 62
How XRM surpasses traditional microCT by using dual-stage magnification ....................................... 63
Advancements in CT reconstruction: Harnessing Deep Learning for enhanced imaging ...................... 63
Demonstrating the impact of Deep Learning with example applications ............................................. 66
Case studies : Example from Life Sciences .......................................................................... 72
Microscopy and Deep Learning for neurological disease research ....................................................... 72
Enhancing single-cell analysis with instance segmentation in phase contrast microscopy images ....... 78
Analysis of FIB-SEM volume electron microscopy data ......................................................................... 82
Analysis of mitochondria using Deep Learning .................................................................................... 88
— — — — — — — — — — — — — — —
Page 8
Enhancing the utility of zebrafish models to study infectious diseases using Deep Learning ................ 92
Exploring mouse embryo development with microCT and AI .............................................................. 98
Case studies : Example from Materials Science ................................................................. 102
Improving microstructure analysis of aluminum oxide with Deep Learning ....................................... 102
Instance segmentation in C45 steel analysis: Improving microstructural insights with AI .................. 110
Summary ............................................................................................................................ 114
ZEISS Microscopy Software Solutions ............................................................................... 116
ZEISS arivis Family of Products .......................................................................................... 116
ZEISS arivis Pro ................................................................................................................................... 116
ZEISS arivis Hub .................................................................................................................................. 117
ZEISS arivis Cloud ............................................................................................................................... 117
ZEISS ZEN Family of Products ........................................................................................... 118
ZEN Microscopy Software ................................................................................................................. 118
ZEISS ZEN core ................................................................................................................................... 119
Other Software Solutions ................................................................................................. 120
ZEISS Labscope .................................................................................................................................. 120
ZEISS DeepRecon Pro ........................................................................................................................ 121
Contributors .................................................................................................................... 122
— — — — — — — — — — — — — — —
Page 9
Cover image: The figure displays a cross-sectional view of an intestinal gut organoid captured at
20X magnification on ZEISS Celldiscoverer 7 and segmented using ZEISS arivis Pro image analysis
software. The i mage highlights outer cell layer nuclei in pink and the inner lumin al nuclei in yellow.
The chapters in this book employ the new product names for arivis products, which have been
rebranded by ZEISS following the acquisition. Specifically, arivis Vision4D is now known as ZEISS
arivis Pro, arivis VisionHub as ZEISS arivis Hub and APEER cloud platform as ZEISS arivis Cloud.
— — — — — — — — — — — — — — —
Page 10
What is AI and why does it matter? 8What is AI and why does it matter?
Why you need AI in your research
In 1955, John McCarthy, Assistant Professor
of Mathematics at Dartmouth College, coined
the term ‘Artificial Intelligence’ to represent
the field of thinking machines, including
cybernetics, automata theory, and complex
information processing [1]. Today, Artificial
Intelligence (AI) refers to the collection of
techniques that mimic human intelligence in
performing tasks.
AI has become ubiquitous in the 2020s,
helping us in many aspects of our lives, from
acting as personal assistants and delivering
customized information on social media, to
driving automobiles and trading stocks. In
recent years, it has become popular to use
AI capabilities for diverse image-processing
applications. In research, AI has the potential
to solve many challenges by enabling faster,
more accurate analysis of large amounts of
data. AI can significantly impact biotechnology,
where it can optimize the drug discovery and development process, reducing the time and
cost of bringing new therapies to market.
AI can also benefit diverse image analysis
applications, such as analyzing medical images
to help diagnose diseases and predict which
treatments will likely be most effective for an
individual patient.
While AI technology is rapidly developing,
certain challenges hinder the adoption of AI
in biomedical applications. Developing AI
systems can be expensive for biotech startups,
especially when hiring skilled personnel to
develop and maintain AI systems. There are
also ethical concerns around the use of AI
for biomedical applications. Despite these
objections, AI has seen rapid adoption in the
past decade, primarily driven by its ability
to solve challenges quickly. The exponential
growth in AI-related publications reflects
the technology adoption by the scientific
community (see Figure 1 ).
Figure 1: There has been a nearly exponential growth in the number of biomedical publications related to AI, including
Machine Learning and Deep Learning, since the year 2000. (Data sourced from PubMed January 2024).
— — — — — — — — — — — — — — —
Page 11
What is AI and why does it matter? 9AI, Machine Learning, and Deep
Learning: What is the difference?
Artificial intelligence, Machine Learning,
and Deep Learning are related but distinct
terminology (see Figure 2).
Artificial intelligence is the broadest term
and describes techniques that mimic human
intelligence in performing tasks. AI-related
biomedical publications in the past decade
primarily focused on solving challenges
using Machine Learning and Deep Learning
techniques.
Machine Learning is a subfield of AI that
focuses on learning from data and improving
processing efficiency and accuracy over time
with experience. There are several Machine
Learning algorithms available, encompassing
various learning approaches such as
supervised, unsupervised, and reinforcement
learning.
Deep Learning is a Machine Learning technique
that trains artificial neural networks on a large
dataset, allowing them to learn and make
independent, intelligent decisions. These
networks have gained popularity due to their
ability to learn and improve accuracy over time
without explicit programming. They are well
suited to solving image analysis challenges
that require algorithms to identify complex
Figure 2: Deep Learning is a powerful subset of Machine
Learning, which in turn is a subset of the broader field of
artificial intelligence.
Figure 3: Training a model on a small ROI to create the Machine Learning-driven classifier. The figure shows a mouse brain
cross-section imaged at 10x using ZEISS LSM980 with Airyscan. Sample courtesy of Prof. Jochen Herms, LMU München,
Germany.patterns and features in the data. It is worth
mentioning that, for the purposes of this book,
a distinction is made between Deep Learning
and non-Deep Learning-based algorithms.
The latter algorithms are referred to as
‘conventional’ Machine Learning techniques.
Conventional Machine Learning vs. Deep
Learning for image analysis
Conventional Machine Learning can learn from
a small amount of data, but an expert engineer
needs to handpick features to feed into a
classification algorithm such as Random Forest
[2] or Support Vector Machines [3] (SVM).
Features can be obtained from training images
through the use of digital image filters such
as Sobel, Entropy, and Gabor [4]. Alternatively,
Deep Learning networks trained on extensive
datasets can be utilized as a method for feature
— — — — — — — — — — — — — — —
Page 12
What is AI and why does it matter? 10extraction instead of manual feature crafting.
These approaches are ideal for scenarios where
future data is not anticipated to vary much
from the data used to train the model.
For example, a small region of interest (ROI)
from a large image can be used to train a
model, which can then process the entire large
image (see Figure 3 ). Similarly, users can take
random 2D slices from a 3D volume to train a
model to process the whole 3D dataset.
A conventional Machine Learning model
may not work well on datasets distinct from
the training data because the handful of
parameters used by Machine Learning cannot
be tuned to anticipate the variability in future
data. Additionally, a handful of parameters is
insufficient to capture the complexity in certain
data making the model fail at solving complex
challenges.
For example, conventional Machine Learning
fails at segmenting organelles in an electron
micrograph of a cell where the objects of
interest (e.g., mitochondria) show up against a
busy background (see Figure 4 ).
Deep Learning does not require hand-tuning
of features by an expert. It optimizes millions
of parameters during training without humans
explicitly engineering the features. These
algorithms can learn multiple levels of detail
and significance in the data, allowing them to
identify high-level features important
for the task.
This ability to learn by tuning millions of
parameters using a vast amount of data makes
Deep Learning algorithms generalizable to
handle data with large variations, such as
microscopy data that can vary because of
sample preparation, lighting, background,
objective, etc.
This large number of features also enables
Deep Learning to solve complex challenges, Figure 4: (a) Slice from a FIB-SEM volume of a HeLa cell
that was high-pressure frozen. The sample is courtesy
of Anna Steyer and Yannick Schwab of EMBL. (b) The
segmentation result from conventional Machine Learning.
A Random Forest algorithm was trained using features
derived by applying the first convolutional layer in the
pre-trained VGG16 model. The model was trained using
the AI toolkit in ZEISS ZEN software. (c) This figure depicts
the same outcome from (b), with the exception that the
output has been cleaned using a conditional random field
to remove isolated pixels. Although the segmentation was
able to detect a majority of pixels from mitochondria, it
failed to identify a significant number of pixels within these
objects, thereby making it challenging to differentiate them
entirely from the background. Furthermore, a large number
of non-mitochondria pixels were erroneously labeled as
mitochondria.
such as segmenting organelles against a busy
background (see Figure 5 ).
However, it is essential to note that Deep
Learning algorithms learn from the given data.
If the training data does not contain sufficient
examples of the variations, the model may not
perform well on those variations.
— — — — — — — — — — — — — — —
Page 13
What is AI and why does it matter? 11
Figure 5: (a) This picture displays the same slice from a
high-pressure frozen HeLa cell in a FIB-SEM volume as
seen in Figure 4a. The sample is courtesy of Anna Steyer
and Yannick Schwab of EMBL. (b) This image depicts the
result of Deep Learning segmentation. The U-net based
Deep Learning algorithm was trained on ZEISS arivis Cloud
platform. The segmentation results from Deep Learning
outperformed those obtained through conventional
Machine Learning. It is important to note that the pixels
utilized for training the conventional Machine Learning
(as seen in Figure 4) and the Deep Learning (as seen in this
figure) were not the same. Both approaches followed best
practices, as advised by the respective software packages.
school biology classrooms. The app provides
ready-to-use AI-powered solutions, including
fast and effective cell counting, allowing its
users to perform analysis on any microscope
with a camera.
Products for automated image
acquisition and segmentation
In biotech and academic research, users often
automate the image acquisition process to
ensure reproducibility and faster throughput.
ZEN software suite makes high-quality
image acquisition easy on research-grade
ZEISS microscopes. ZEN also provides an ‘AI
toolkit’ for image analysis that allows for
smart microscopy; for example, using AI to
automatically analyze a low-magnification
survey image to detect regions of interest for
high-magnification experiments. This allows for
automated imaging of multiple large samples
without any human intervention.
Automated imaging allows the collection Microscopy image analysis automation
powered by AI
A survey of PubMed publications since 2020
shows that AI technology has the potential to
solve a wide range of challenges in biomedical
research, including drug discovery [5], radiology
[6], and medical image analysis [7].
Microscopy image analysis as a subfield saw
rapid growth in AI-based applications, primarily
driven by the goal to automate image analysis
pipelines. Researchers have tried to automate
microscopy analysis to remove human bias and
improve throughput since the beginning of
digital image analysis in the 1960s [8].
This book focuses on AI applications for
microscopy image analysis, including various
case studies and the no-code tools from ZEISS
that make AI algorithms accessible to everyone.
AI can be daunting, especially for users with
little or no programming experience. The
no-code interfaces are user-friendly and allow
users with no coding experience to create
automated image analysis pipelines. They also
allow users to build custom workflows without
technical expertise. Labscope, ZEN, and arivis
are software platforms from ZEISS that provide
no-code interfaces that enable AI-powered
automated image analysis for scientific
challenges.
No-code products from ZEISS
ZEISS offers a range of no-code products to
allow users to benefit from AI-powered image
analysis solutions. These tools are accessible
to a range of users, from routine labs and
digital classrooms conducting small-scale
experiments, to biotech and academic
researchers conducting experiments with large,
multi-dimensional datasets.
Products for routine lab tasks
Many routine lab imaging tasks, such as
cell counting, can benefit from AI-powered
automation. Labscope is an easy-to-use
imaging app for routine labs and university or
— — — — — — — — — — — — — — —
Page 14
What is AI and why does it matter? 12
Learn more about ZEISS arivis Cloud
Train and share Deep Learning models on
the cloud for AI-driven image analysis.
www.zeiss.com/arivis-cloudof large amounts of data in a short period,
which can be helpful for applications such as
studying the eff ects of a particular treatment
on multiple cells or organisms. But the image
analysis throughput must keep up with image
acquisition to maximize the benefi t. ZEN’s AI
toolkit can be utilized to enhance application-
specifi c automated image analysis solutions.
Some sample applications within ZEN include
2D cell counting, cell confl uency, gene and
protein expression, as well as automated spot
detection. As the data size, dimensions, and
complexity increase, the analysis can be scaled
up using the arivis software ecosystem.
Data-agnostic image analysis tools
arivis represents an ecosystem of software
solutions designed for data-agnostic image
analysis, allowing the analysis of images in
many formats from diff erent microscope
vendors (and other imaging hardware, such
as MRI and CT). The primary arivis solutions
include ZEISS arivis Pro, ZEISS arivis Hub, and
ZEISS arivis Cloud.
ZEISS arivis Pro is a visualization-centric
multi-dimensional image analysis platform
that provides interactive tools and the ability
to develop automated analysis pipelines for
virtually unlimited-size data with just a few
clicks.
ZEISS arivis Hub enables the design and
execution of large-scale experiments via
parallelized processing using multiple
computational workers on local workstations,
servers, or cloud servers.
Figure 6 provides an overview of the ZEISS
microscopy software ecosystem.ZEISS arivis Cloud provides the infrastructure
for cloud storage and computation of image
analysis pipelines. Its segmentation tools
enable users to benefi t from Deep Learning
without needing to know how to code.
These Deep Learning trained models can be
incorporated into arivis and ZEN image analysis
pipelines.
Figure 6: ZEISS microscopy software ecosystem.
— — — — — — — — — — — — — — —
Page 15
What is AI and why does it matter? 13References
1. Wikipedia. Dartmouth workshop. URL: https://en.wikipedia.org/wiki/Dartmouth_workshop
(accessed 24 January 2023).
2. Wikipedia. Random Forest. URL: https://en.wikipedia.org/wiki/Random_forest (accessed 24
January 2023).
3. Wikipedia. Support vector machine. URL: https://en.wikipedia.org/wiki/Support_vector_
machine (accessed 24 January 2023).
4. Wikipedia. Gabor filter. URL: https://en.wikipedia.org/wiki/Gabor_filter (accessed 24 January
2023).
5. Vamathevan J, Clark D, Czodrowski P, Dunham I, Ferran E, Lee G, et al . Applications of Machine
Learning in drug discovery and development. Nat Rev Drug Discov. (2019) 18 (6):463–477. doi:
10.1038/s41573-019-0024-5.
6. Hosny A, Parmar C, Quackenbush J, Schwartz LH, Aerts HJWL. Artificial intelligence in
radiology. Nat Rev Cancer . (2018) 18(8):500–510. doi: 10.1038/s41568-018-0016-5.
7. Castiglioni I, Rundo L, Codari M, Di Leo G, Salvatore C, Interlenghi M, et al . AI applications
to medical images: From Machine Learning to Deep Learning. Phys Med. (2021) 83 :9–24. doi:
10.1016/j.ejmp.2021.02.006.
8. Prewitt, JMS, Mendelsohn, ML. The analysis of cell image. Ann N Y Acad Sci. (1966)
128:1035–1053. doi: 10.1111/j.1749-6632.1965.tb11715.x.
— — — — — — — — — — — — — — —
Page 16
An introduction to image segmentation 14An introduction to image segmentation
What is image segmentation?
Image segmentation is the process of dividing
an image into various sections corresponding
to different regions of similarity, referred
to as regions of interest (ROI) in scientific
terminology. These regions represent the
original image in a way that is easier to analyze.
In microscopy image analysis, segmentation is
a key step in many applications. For example,
automated counting, sizing, and tracking
of biological cells enable high-throughput
screening in drug discovery experiments (see
Figure 1 ).
Similarly, grain segmentation of 3D-printed
materials informs and improves the additive
manufacturing process by providing
microstructural insights. Plus, the segmentation
of various minerals and porous structures helps
petrologists understand the movability of
hydrocarbons in sedimentary rocks.
Algorithms for image segmentation
Image segmentation has evolved significantly
over the last five decades, from traditional
techniques in the 1970s and 1980s to using
Deep Learning in recent years. Traditional
methods, such as thresholding, edge
detection, and region growing, relied on
manually tuning parameters making the results
irreproducible and subject to human bias.
Figure 1: Segmentation in a microscopy experiment tracking cell nuclei. (a) Image showing the DAPI-stained cell nuclei in
blue. (b) The nuclei from (a) were segmented by employing global thresholding and then separated using the Watershed
algorithm. The segmented nuclei are depicted in red. (c) The nuclei were segmented and tracked throughout the time
series, with each nucleus and its corresponding track displayed in randomly assigned colors. (d) A plot showing the mean
squared displacement of selected nuclei.Otsu’s segmentation method
A key method, called Otsu’s method, provides
a way to perform automatic segmentation
using the histogram threshold approach [1].
Otsu’s algorithm returns a single intensity
threshold value that separates pixels into either
foreground or background classes.
Otsu’s algorithm is a global thresholding
method and assumes the image is
homogeneous and follows a bimodal
distribution.
Therefore, this approach may not be ideal for
noisy images or showing multiple regions with
similar mean gray levels but varying textures.
However, its simplicity and computationally
fast nature made it the preferred choice for
simple segmentation tasks such as nuclei
segmentation in fluorescence microscopy
images (see Figure 2 ).
The Watershed algorithm
Otsu segmentation only divides the image
into background and foreground, but it
cannot distinguish between objects that touch
one another. Additional image processing
techniques, like the Watershed algorithm [2],
are often used to separate touching objects.
The Watershed algorithm separates objects by
creating boundaries between regions ‘flooded’
from different markers, hence its name (see
Figure 3 ).
— — — — — — — — — — — — — — —
Page 17
An introduction to image segmentation 15
Figure 2: Otsu-based segmentation of a fl uorescence
micrograph. (a) Fluorescence micrograph of a sample
stained with DAPI showing nuclei in blue. (b) Otsu
segmentation shows the nuclei regions in white.
However, a disadvantage of the Watershed
method is that it may break down a single
object into several pieces, depending on its
shape.
Machine Learning segmentation
techniques
The 2000s saw the introduction of
conventional Machine Learning techniques for
image segmentation, including decision trees,
Random Forests, and Support Vector Machines
(SVM). These methods improved traditional
techniques by incorporating contextual
information and learning from data, making
it possible to automate the segmentation of
images with complex or varied intensity values
and textures. Conventional Machine Learning
works by training a classifi er (e.g., a SVM) on
various attributes associated with the training
data. For images, these attributes can be
defi ned via features extracted from them.
Digital image fi lters can be engineered to
extract features representing various intensities
Figure 3: (a) Otsu-segmented binary image. (b)
Otsu-segmented binary image followed by the Watershed
separation of objects. The separation between grouped
objects is evident in this image. and textural information in images. For
example, the Sobel fi lter [3] calculates the
image intensity gradient at any point and
generates an image emphasizing edges.
Similarly, the Gabor fi lter [4] combines
sinusoidal and Gaussian functions to describe
and show diff erent textures. Adjusting fi lter
parameters can create countless Gabor kernels
that serve as feature extractors. For instance, a
kernel with theta set to π/2 acts as a band-pass
fi lter that emphasizes horizontal features in the
image. Likewise, a kernel with theta set to π
accentuates vertical features.
Figure 4 shows the application of these kernels
on a cross-section of a NAND fl ash memory
chip, illustrating that modifi cation of the theta
value can emphasize features oriented in a
specifi c direction.
Instead of handcrafting the features, Deep
Learning networks trained on large datasets
can also extract features from an image.
For example, the VGG16 network [5] trained
on the ImageNet [6] dataset can extract many
features from images of a NAND fl ash memory
chip (see Figure 5 ). These features can be used
as input information for conventional Machine
Learning algorithms capable of learning how to
classify pixels (segmentation) or entire images
(classifi cation).
Although it is possible to use conventional
Machine Learning techniques for a broad range
of image segmentation, their eff ectiveness
decreases as the images become more
complex in shape and texture. Furthermore,
these algorithms tend to perform poorly on
images that vary in intensity compared to
the training images, making them poorly
generalizable to other datasets.
— — — — — — — — — — — — — — —
Page 18
An introduction to image segmentation 16
Figure 5: The use of a pre-trained Deep Learning model as a feature extractor. (a) A cross-section of a NAND fl ash
memory chip imaged using ZEISS Crossbeam 550 FIB-SEM. (b) The VGG16 neural network was pre-trained on the ImageNet
dataset. (c) Features obtained from the input image using the second convolutional block of the pre-trained VGG16
network. See reference 5 for technical details.
Figure 4: Using the Gabor fi lter to extract features from a micrograph of NAND fl ash memory. (a) A cross-section of a
NAND fl ash memory chip imaged using ZEISS Crossbeam 550 FIB-SEM. (b) Digital fi lter kernels generated from adjusting
Gabor parameters. (c) The features that are produced when the appropriate Gabor kernels are applied. One kernel
emphasizes the input image’s horizontal details (top), and the other highlights the vertical details (bottom).
Deep Learning algorithms for image
segmentation
Deep Learning algorithms demonstrate greater
generalizability than conventional Machine
Learning algorithms.
A convolutional neural network (CNN) is a
Deep Learning algorithm explicitly designed
for image processing tasks. One of the
most popular CNN architectures is U-net,
introduced in 2015 by Olaf Ronneberger et
al. [7]. It is widely used for biomedical image
segmentation.The U-net architecture is particularly good at
image segmentation because it can learn both
local and global features of images.
While Deep Learning is a powerful technique,
it requires a lot of labeled data and
computational resources for training. But once
trained, Deep Learning models can be used
for extended periods due to their excellent
generalizability. ZEISS provides software
solutions to assist researchers in addressing the
diffi culties of analyzing massive amounts of
— — — — — — — — — — — — — — —
Page 19
An introduction to image segmentation 17data with limited resources, enabling them to
achieve reproducible results at a quicker pace.
The ZEISS software ecosystem
Each method discussed has its strengths
and weaknesses, and the choice of method
depends on the application and the type of
image being analyzed. The ZEISS software
ecosystem offers a variety of powerful tools
to train and integrate conventional Machine
Learning and Deep Learning models into image
processing and analysis pipelines. The key
software products covered in this book are:
■ZEISS arivis suite: Designed for scalable
data-agnostic image analysis.
ZEISS arivis Cloud: Provides user-friendly
access to Deep Learning tools, enabling
the training of custom models for image
segmentation tasks.
References
1. Otsu N. A Threshold Selection Method from Gray-Level Histograms. I EEE Trans Syst Man
Cybern. (1979) 9(1):62–66. doi: 10.1109/TSMC.1979.4310076.
2. Wikipedia. Watershed (image processing). URL: https://en.wikipedia.org/wiki/Watershed_
(image_processing) (accessed 14 February 2023).
3. Wikipedia. Sobel operator. URL: https://en.wikipedia.org/wiki/Sobel_operator (accessed 31
January 2023).
4. Wikipedia. Gabor filter. URL: https://en.wikipedia.org/wiki/Gabor_filter (accessed 31 January
2023).
5. Simonyan K and Zisserman A. Very Deep Convolutional Networks for Large-Scale Image
Recognition. (2014) arXiv:1409.1556. doi: 10.48550/arXiv.1409.1556.
6. Deng D, Dong W, Socher R, Li L-J, Li K, and Fei-Fei L. ImageNet: A large-scale hierarchical image
database. IEEE Conference on Computer Vision and Pattern Recognition, Miami, FL, USA. (2009)
248–255. doi: 10.1109/CVPR.2009.5206848.
7. Ronneberger O, Fischer P, and Brox T. U-Net: Convolutional Networks for Biomedical Image
Segmentation. (2015) arXiv:1505.04597. doi: 10.48550/arXiv.1505.04597.ZEISS arivis Pro: Visualization-centric
multidimensional image analysis software.
ZEISS arivis Hub: Execution of large-scale
experiments via parallelized processing using
multiple computational workers.
■ZEN and ZEN core: Universal software
interfaces for image acquisition and analysis
on advanced microscopes from ZEISS.
■Labscope: An easy-to-use imaging app for
routine labs, universities, and schools.
■ZEISS DeepRecon Pro: State-of-the-art Deep
Learning-based reconstruction for ZEISS
X-ray Microscope (XRM) or microCT.
“ZEISS provides software solutions
to assist researchers in addressing
the difficulties of analyzing massive
amounts of data with limited
resources.”
— — — — — — — — — — — — — — —
Page 20
AI in ZEISS arivis software for scalable automated analysis 18
In the previous chapter, we introduced ZEISS
arivis, a versatile software suite designed for
data-agnostic image analysis. This powerful
suite can handle images from various sources,
including different microscope vendors, MRI
scanners, and CT scanners, across multiple file
formats. The primary products within the arivis
suite are:
■ZEISS arivis Cloud.
■ZEISS arivis Pro.
■ZEISS arivis Hub.
This chapter starts by focusing on ZEISS arivis
Cloud, which provides user-friendly access
to advanced Deep Learning tools for training
custom models tailored to image segmentation
tasks. These models can be seamlessly
integrated into ZEN, ZEN core, ZEISS arivis Pro
and ZEISS arivis Hub, enabling automated,
scalable analysis of multidimensional datasets.
Additionally, we will discuss the AI capabilities
Figure 1: A re-created U-net architecture based on the original paper [2] which takes in an RGB input image with
dimensions of 512x512 and produces a segmented image with the same dimensions for a chosen class. The ZEISS arivis
Cloud implementation dynamically chooses the tile size based on the images, ranging from 1024x1024 for larger images to
128x128 for smaller images.embedded within ZEISS arivis Pro and ZEISS
arivis Hub, as well as the ability to create
ground truth labels in three dimensions
(3D) using the immersive ZEISS arivis Pro VR
environment.
Training Deep Learning models using
ZEISS arivis Cloud
ZEISS arivis Cloud helps users annotate images
and train Deep Learning models for image
segmentation. Users can use the resulting
models on both ZEISS arivis and ZEN platforms.
ZEISS arivis Cloud offers a user-friendly interface
that allows users to establish the ground
truth by simply painting pixels and training
a personalized model by clicking the “Train”
button. The following link leads to a video
tutorial that explains the process of custom
Deep Learning model training for image
segmentation using ZEISS arivis Cloud:
bit.ly/arivis-deep.
ZEISS arivis Cloud employs the widely
recognized U-net architecture (see Figure1 ) AI in ZEISS arivis software for scalable
automated analysis
— — — — — — — — — — — — — — —
Page 21
AI in ZEISS arivis software for scalable automated analysis 19Figure 2: The training interface in ZEISS arivis Cloud showing partial annotations for mitochondria (yellow) and
background (purple dots). The image shows a slice from a FIB-SEM volume of a HeLa cell that was high-pressure frozen.
The sample is courtesy of Anna Steyer and Yannick Schwab of EMBL.
for semantic segmentation with encoder and
decoder modifi cations to enhance speed
and accuracy. For instance segmentation,
ZEISS arivis Cloud uses Mask2Former [1]. Both
architectures have been adapted to work with
microscopy data and to enable segmenting
images with any number of channels. The
“loss functions” for both approaches have
also been customized for training with partial
annotations, further improving the effi ciency
and accuracy of the training process.
Note: As Deep Learning technology evolves,
the specifi c algorithms used for semantic and
instance segmentation may change in the
future.
Several other improvements have been made in
the Deep Learning training and segmentation
process to make it user-friendly and accessible
to individuals of any skill level. Examples
include:
■Using pre-trained weights.
■Allowing for partial annotations.
■Automatic defi nition of boundary
annotations.■Using image augmentation techniques.
■Selecting the segmentation tasks
“Semantic Segmentation” and “Instance
Segmentation”.
■Implementation of smooth tiling.
P re-trained weights
Unlike conventional Machine Learning, Deep
Learning can require a large amount of data
for training. However, ZEISS arivis Cloud is
equipped with preloaded, pre-trained weights,
allowing fast model training from less data.
It is recommended to start with as little as 20
annotations. The users can then add additional
labels based on the outcome of the initial
segmentation, thus tweaking their trained
model with only the necessary eff ort.
Partial annotations
Traditional training methods for Deep Learning-
based semantic or instance segmentation
algorithms often require extensive labeling.
Every pixel in each training image must be
annotated, including any over-represented
areas, which can be a time-consuming and
ineffi cient process.
— — — — — — — — — — — — — — —
Page 22
AI in ZEISS arivis software for scalable automated analysis 20Figure 3: Augmented images and the respective masks produced while training a model on ZEISS arivis Cloud. The image
shows a slice from a FIB-SEM volume of a HeLa cell that was high-pressure frozen. The sample is courtesy of Anna Steyer
and Yannick Schwab of EMBL.
ZEISS arivis Cloud introduces a more effi cient
method called “partial annotations” for
segmentation as part of its Deep Learning
workfl ow. It allows users to concentrate on
under-represented regions in training images
to make the process more effi cient. This is
particularly useful for microscopy applications
where images are usually large (see Figure 2 ).
Automatic boundary annotation further
optimizes the usefulness of partial annotations.
Au tomatic boundary annotation
Segmenting the central pixels of objects is
easier than segmenting the edge because
the boundary between objects and the
background is often uncertain. Thus, it is
crucial that users properly annotate them
during the training phase. ZEISS arivis Cloud
makes it convenient for the user to defi ne
these boundaries by automatically cutting
out annotated objects from the surrounding
background (see Figure 2 ).
Im age augmentation
Image augmentation improves the
generalizability of a trained model by giving the
algorithm variations of the training data, such
as rotated, zoomed, and stretched images. This
helps improve model accuracy when it analyzes
new data because they might resemble the
transformed images used during training.
ZEISS arivis Cloud performs various image
augmentation in the background (see Figure 3 ).Cho osing the appropriate segmentation
method
On ZEISS arivis Cloud, users can select the
segmentation approach appropriate to
their desired application. There are two
segmentation options:
1. Semantic segmentation (pixel-based).
2. Instance segmentation (object-based).
For example, when classifying regions of tissue,
semantic segmentation enables users to assign
each pixel to a specifi c tissue class. When
segmenting nuclei, instance segmentation
is necessary as it allows the user to identify
and outline each individual nucleus and, for
example, extract morphological parameters
from them. ZEISS arivis Cloud off ers both
options, giving the user the freedom to achieve
their image segmentation goals.
Figure 4 shows the results obtained using
semantic and instance segmentation
approaches. Figure 4a displays the original
phase contrast image and Figure 4b displays
the semantic segmentation result, where every
pixel corresponding to the cells is colored
purple.
While this approach highlights the pixels
occupied by cells eff ectively, it fails to
distinguish each individual cell as a separate
object, which is crucial for quantifying and
— — — — — — — — — — — — — — —
Page 23
AI in ZEISS arivis software for scalable automated analysis 21Figure 4: Comparison of semantic and instance segmentation approaches for phase contrast cells. (a) Original phase
contrast image. (b) Semantic segmentation result highlighting pixels corresponding to the cells in purple. (c) Instance
segmentation result, clearly delineating each individual cell as a separate object, even when they are touching each other
(shown in random colors).
analyzing them at the object level. In contrast,
Figure 4c shows the result from instance
segmentation, where each individual cell is
clearly segmented as a distinct object. This
result emphasizes the benefit of instance
segmentation when object-level information is
required for analysis.
Smooth tiling
Deep Learning-based segmentation uses a
lot of device memory. To address this, it is
common practice to divide large images into
smaller patches (tiles) and combine them
back into the large image. However, simply
arranging the patches back into a large
image can result in edge artifacts where the
continuity of objects may be disrupted (see
Figure 5 ). To avoid this, ZEISS arivis Cloud uses
predictions from overlapping tiles that are
blended by assigning a weighting coefficient
to pixels. Satisfactory blending is achieved by
assigning larger weights to pixels closer to the
tile center.
This method is called “smooth tiling”. The
logic behind it is that pixels closer to the tile
center provide more image context and are
considered more reliable.
Tips for achieving a reliable Deep
Learning model
ZEISS arivis Cloud offers a range of features
that simplify Deep Learning training.
Additionally, the user can make many decisions
to further streamline the model creation process. Here are some suggestions to achieve
a reliable Deep Learning model.
Standardize the imaging conditions
The complexity of the segmentation task is
impacted by variations in imaging conditions.
Standardizing the imaging parameters
facilitates the Deep Learning algorithm’s
learning of the task, as fewer annotations are
required. Adhering to the following guidelines
ensures optimal training of the model on ZEISS
arivis Cloud.
■The microscope illumination settings
should remain consistent between images
to maintain similar intensity histograms
between them.
■The magnification and binning should be
kept so that identical objects have similar
pixel sizes.
Choose a magnification and resolution that is
sufficient to visualize the structures of interest
that don’t unnecessarily increase resolution.
An unnecessarily high resolution makes it
harder for the model to detect the structures of
interest and increases the processing times.
Avoid complexity when defining classes
Try to avoid defining multiple classes to
segment similar objects with minor differences.
For example, instead of training an algorithm
to segment small and large objects, it may be
better to train an algorithm to segment
— — — — — — — — — — — — — — —
Page 24
AI in ZEISS arivis software for scalable automated analysis 22all objects and use the size information to
separate them into distinct classes after the
initial segmentation. While segmenting objects
into specifi c classes during the training process
may seem easier and obvious, post-processing
can be more effi cient because it enables
a more generic model that can handle a
wide range of objects to adapt to diff erent
applications.
Start simple and increasing the
complexity as needed
Achieving robust segmentation of many classes
across diff erent imaging conditions is the goal
of developing a Deep Learning segmentation
model. However, it is challenging for the
algorithm to learn all the complexities when
provided only a few annotated objects within
the large parameter space.
A data-centric approach [1] can quickly develop
a robust Deep Learning segmentation model.
ZEISS arivis Cloud provides the necessary tools
to construct the perfect training dataset using
the data-centric strategy (see Figure 6 ). Such
datasets include just the correct number of
annotations in crucial areas to attain the level
of segmentation robustness that the user
desires.Figure 5: (a) Cryo-electron microscopy image of a cell showing mitochondria. A Deep Learning model has been trained
using ZEISS arivis Cloud to segment faint mitochondria from the background. (b) The segmentation result without
smooth blending produces noticeable artifacts along the patch edges, leading to incorrect classifi cation of edge pixels
as mitochondria. Improbably straight edges are also clearly visible, as indicated by the black arrows. (c) The seamless
integration of patches using smooth tiling creates a segmented image without any visible anomalies. Sample courtesy of
Dr. York-Dieter Stierhof from Eberhard Karl University of Tübingen.
It is recommended to approach complex
tasks by starting with a small, straightforward
portion of data before gradually increasing
the complexity in order to build the complete
annotated dataset.
Recommended approach for
segmentation
■Begin by selecting a single class to segment.
■Approximately 20 objects or regions in
similar images should be annotated (for
example, from a single experiment).
■After the training, the accuracy of the
algorithm at segmenting the fi rst class
should be evaluated.
■To improve the robustness of the algorithm,
images with more variability (such as from
diff erent experiments) should be added and
steps 2 and 3 should be repeated.
■Once the fi rst class has been successfully
segmented across all images, additional
classes should be annotated and trained by
repeating these fi ve steps.
— — — — — — — — — — — — — — —
Page 25
AI in ZEISS arivis software for scalable automated analysis 23
This approach allows the user to concentrate
on annotating challenging features rather
than wasting time on easy ones. Gradually
increasing the complexity helps the user
develop intuition about which image features
are diffi cult for the algorithm to learn.
In microscopy, variations in data sets can
arise because of diff erent sample preparation
procedures and experimental conditions.
Examples include the illumination source,
magnifi cation, and duration of observation.
Therefore, to create generalized models, it
is essential that the fi nal annotated data set
refl ects the diversity expected in future data.Additional tips to enhance image
segmentation effi ciency
1. It is advised not to waste time annotating
areas where the algorithm has already
demonstrated mastery.
2. The recent training segmentations should
be examined to determine areas where the
algorithm struggles, and these areas should
be given priority for annotating.
3. Recognizing rare classes can be a
challenge for the algorithm. To improve
its understanding of these classes,
fi nding additional training images that
include examples of these rare classes is
recommended.
Using AI-trained models in applications
Models trained with ZEISS arivis Cloud can be
incorporated into image analysis workfl ows
across various ZEISS software packages,
including ZEN and arivis. The models can
be used for image segmentation on ZEISS
arivis Cloud, which is especially eff ective for
applications where no further image analysis is
needed beyond the initial segmentation andFigure 6: Model-centric versus data-centric model development for microscopy applications.
Figure 7: FIB-SEM image of a high-pressure frozen HeLa
cell segmented in ZEISS arivis Pro for various organelles
using Deep Learning models trained on ZEISS arivis Cloud.
Sample courtesy of Anna Steyer and Yannick Schwab.
— — — — — — — — — — — — — — —
Page 26
AI in ZEISS arivis software for scalable automated analysis 24simple measurements. Users get a report that
details over 18 morphological measurements
extracted from the segmented objects,
including the area and diameter of each object.
Many applications will require advanced post-
segmentation image analysis. ZEISS arivis Cloud
models can be downloaded and used with the
ZEN, ZEN core, ZEISS arivis Pro, and ZEISS arivis
Hub image analysis pipelines. These products
off er customizable, push-button solutions for
most applications. On-microscope analysis of
images captured using ZEISS microscopes is
achievable using AI-powered image analysis
pipelines in ZEN. Large multi-dimensional
datasets can be imported into ZEISS arivis Pro
(see Figure 7 )for automated analysis regardless
of whether they were collected using ZEISS or
non-ZEISS microscopes. Automated analysis
can be performed on these datasets and scaled
up for faster processing with ZEISS arivis Hub.
The rest of this chapter provides an overview of
AI-powered tools in ZEISS arivis Pro and ZEISS
arivis Hub.
AI in ZEISS arivis Pro for automated
image analysis
ZEISS arivis Pro is a visualization-centric
platform designed for multi-dimensional image
analysis, off ering interactive tools and the
ability to develop automated analysis pipelines
for datasets of virtually unlimited size with just
a few clicks.
The software provides users with a
comprehensive range of segmentation options,
from traditional thresholding techniques to
advanced Deep Learning models. This includes
tools for detecting round objects using blob
fi nder, membrane-based segmentation that
leverages bright outlines, feature-based
Machine Learning, and state-of-the-art Deep
Learning approaches (see Figure 8 ). This diverse
Case Study: AI for Image
Analysis in vEM
www. zeiss.com/ai-for-vemFigure 8: The segmentation window in ZEISS arivis Pro
off ering a comprehensive range of options from traditional
techniques such as intensity thresholding and color-based
segmentation to advanced methods such as blob fi nding,
Watershed segmentation, Machine Learning-based
segmentation, Deep Learning segmentation (ZEISS arivis
Cloud-trained models, user-defi ned models, and pre-
trained Cellpose models), membrane-based segmentation,
and seeded region growing. This diverse selection enables
users to choose the most appropriate tool tailored to their
specifi c image analysis requirements.
selection empowers users to choose the most
appropriate tool for their specifi c analysis
requirements.
In ZEISS arivis Pro, automated image analysis
routines are confi gured using a “pipeline”
concept. This approach allows users to arrange
image processing and analysis operations
into a seamless workfl ow, with data input
automatically from the previous step and
output to the next stage. This streamlined
process ensures reproducible analysis between
multiple datasets.
— — — — — — — — — — — — — — —
Page 27
AI in ZEISS arivis software for scalable automated analysis 25Segmentation is a critical operation that is
often irreproducible. Manual approaches,
such as threshold-based segmentation
which requires user input, can introduce
irreproducibility, user bias, and impact
the overall throughput of image analysis.
Fortunately, AI technologies integrated into
ZEISS arivis Pro, including both feature-based
conventional Machine Learning and Deep
Learning, enable automatic segmentation even
for complex images.
Conventional Machine Learning for
image segmentation in ZEISS arivis Pro
As previously discussed, conventional Machine
Learning involves extracting various features
from the training data by applying digital
filters and training a Machine Learning model
based on these extracted features. Compared
to Deep Learning, Machine Learning is
faster to train and requires smaller training
datasets, making them a preferred choice for
applications where the complexity of features
in the image is low. For example, segmenting
bright objects against a gray background.
Figure 9 shows the Machine Learning Trainer
interface in ZEISS arivis Pro. The central image
Figure 9: Machine Learning Trainer interface in ZEISS arivis Pro showing a 2D slice of Nissl-stained neuronal soma imaged
using micro-optical sectioning tomography (MOST). The bright soma objects are annotated in yellow as the class of
interest, while background regions are annotated in cyan. Additional information about this dataset can be found in the
corresponding citation [4].
displays a two-dimensional (2D) slice from a
volumetric dataset of Nissl-stained neuronal
soma imaged using micro-optical sectioning
tomography (MOST). The soma appears as
bright rounded objects scattered throughout
the image. This is a classic example of an
image that is too challenging to segment using
traditional thresholding methods, but which
can be segmented using conventional Machine
Learning. The training process involves defining
the classes, in this case, background and
Neuronal Soma, followed by annotating the
respective pixels to establish the ground truth.
In the figure, a handful of neuronal soma are
annotated in yellow, while background regions
are annotated in cyan.
ZEISS arivis Pro provides a comprehensive suite
of digital filters for feature extraction from
multichannel images, including intensity, edge,
texture, and orientation-based filters, available
in both 2D and 3D formats. The software
allows users to preview the effect of applying
specific filters to their data. For example, Figure
10 shows the response obtained by applying a
Texture filter with a medium kernel size on the
Nissl-stained neuronal soma example shown in
Figure 9 .
— — — — — — — — — — — — — — —
Page 28
AI in ZEISS arivis software for scalable automated analysis 26Figure 10: Feature matrix in the Machine Learning Trainer of ZEISS arivis Pro. Users can select the appropriate feature
set based on the microscopy image type and preview the effects of applying different filters, such as the response from a
Texture filter with a medium kernel size.
Figure 11: Machine Learning-based segmentation of neuronal soma. (a) 2D slice of Nissl-stained neuronal soma. (b)
Pixel-level segmentation of soma (yellow) using a trained Machine Learning model. (c) Object-level segmentation of
individual soma (random colors) after applying a Watershed algorithm. Note that many objects are not fully separated as
the sensitivity of the Watershed algorithm was set to a conservative value to avoid over-segmentation of objects.Using the features generated from the
annotated pixels shown in Figure 9 , a Random
Forest Machine Learning model was trained.
Given the small training dataset, the training
process finished within seconds. The trained
model was subsequently integrated into an
image analysis pipeline in ZEISS arivis Pro to
segment the entire volumetric dataset. This
dataset consisted of 86 planes (2D slices), each
measuring 571x571 pixels.
Figure 11a displays the same 2D slice shown in
Figure 9 . Since conventional Machine Learning
is designed for pixel-level segmentation,
it performed excellently in segmenting all
pixels corresponding to soma, depicted in
yellow in Figure 11b . To convert this pixel-level segmentation into object segmentation, a
Watershed algorithm was applied to separate
touching objects. Figure 11c shows the
individually segmented soma in random colors.
The Machine Learning-based segmentation
of soma, followed by the Watershed-based
separation of objects, was applied to all 86
planes in the dataset. This process segmented
all the soma within the entire volumetric
dataset. Figure 12 displays a volumetric
rendering of the segmented 3D soma overlaid
onto the original dataset. ZEISS arivis Pro
automatically performs 3D measurements and
reports various morphological and intensity
measurements for every segmented object
within the dataset.
— — — — — — — — — — — — — — —
Page 29
AI in ZEISS arivis software for scalable automated analysis 27This conventional Machine Learning approach
is recommended for segmenting large regions
of interest, such as auto-fluorescent tissue
sections. To segment individual objects,
conventional Machine Learning can be used in
conjunction with Watershed-based separation
to separate the objects, as illustrated in
this example. However, depending on the
sensitivity with which the Watershed algorithm
is applied, objects may not be fully separated,
as shown in Figure 11c , or may be over-
segmented for high settings. Therefore, for
robust and automated segmentation, a Deep
Learning-based approach is recommended.
Deep Learning for image segmentation
in ZEISS arivis Pro
ZEISS arivis Pro offers various Deep Learning
tools, including a Deep Learning Trainer, Deep
Learning Segmenter, and Cellpose-based
Segmenter, respectively.
Deep Learning Trainer
The Deep Learning Trainer can be used to
locally train custom models. The trained model
can be integrated into the Analysis Pipeline
to segment images or extract probability
maps. As with any AI model training process,
the user begins by labeling the ground truth.
The labeling process is performed similarly
to conventional Machine Learning, where Figure 12: Volumetric rendering of the segmented 3D neuronal soma (colored objects) overlaid onto the original
Nissl-stained dataset achieved using the Machine Learning-based segmentation pipeline in ZEISS arivis Pro.
different classes are defined, and pixels are
painted to establish ground truth for their
respective classes.
External annotations can also be imported to
define the ground truth in ZEISS arivis Pro. This
approach is especially useful when historical
data and ground truth labels already exist. It
is also useful for training models using public
datasets with ground truth labels. Regardless
of the source of external labels, users are urged
to validate the ground truth before training
the model, as the model’s performance is
inherently dependent on the quality of the
training data itself.
During the training process in the Deep
Learning Trainer, users can monitor the
Intersection over Union (IoU) metric reported
per epoch (see Figure 13 ). After starting at a
low value, the IoU should exhibit an upward
trend as the model trains. This trend reflects
improved model accuracy. An IoU metric
above 0.7 is generally considered “very good”
for many segmentation tasks, indicating a
substantial overlap between predicted and
ground truth masks. However, what constitutes
an “excellent” IoU metric can vary depending
on the specific application and the complexity
of the objects involved. In some cases, an IoU
of 0.8 or higher may be necessary to meet the
— — — — — — — — — — — — — — —
Page 30
AI in ZEISS arivis software for scalable automated analysis 28Figure 13: Mean IoU plot during Deep Learning model training showing the IoU value increase over epochs before
reaching saturation.
task requirements. For particularly demanding
tasks, striving for an IoU of 0.9 or above may
be essential.
For example, when studying specifi c
subcellular structures such as mitochondria,
endoplasmic reticulum, or the Golgi apparatus
using confocal microscopy, high IoU values
are necessary. These structures often have
complex shapes and are densely packed within
cells. Accurate segmentation ensures reliable
quantifi cation of their volume, surface area,
and spatial distribution, which is crucial for
understanding cellular processes like apoptosis,
energy metabolism, and protein traffi cking.
If the IoU does not improve during training,
users can attempt to improve it by adding new
images and additional annotations, as these
provide the model with a richer understanding
of the data.
The mean IoU plot generated during training
(see Figure 13 ) shows the current IoU value
at 91.75% after 65 epochs. The best IoU was achieved at epoch 64, with a value of
92.3%. It also shows that, when the model
started training, the IoU was low in the fi rst
few epochs. It subsequently increased and
plateaued for a few epochs before rising again
and appearing to plateau again at a value of
around 92%. This fi nal plateau is known as
“saturation,” and model training should be
stopped at saturation if no improvement in IoU
is observed for subsequent epochs.
Where model training occurs on a local
workstation, the process is reliant on the local
computational resources available. Therefore,
running Deep Learning training on a system
equipped with a modern GPU that supports
Compute Unifi ed Device Architecture (CUDA®)
is recommended for achieving faster training
times locally. Alternatively, ZEISS arivis Cloud
can be used to train Deep Learning models,
as it provides on-demand access to scalable
resources tailored for effi cient model training,
eliminating the need to maintain local
GPU hardware specifi cally for this purpose.
Regardless of where the Deep Learning model
— — — — — — — — — — — — — — —
Page 31
AI in ZEISS arivis software for scalable automated analysis 29is trained, it can be used to seamlessly segment
images locally in ZEISS arivis Pro using the Deep
Learning Segmenter operation.
Deep Learning Segmenter
The Deep Learning Segmenter operation
allows users to segment images using a
trained semantic or instance Deep Learning
model on datasets of any size and dimension.
This operation can be incorporated into an
analysis pipeline and combined with all other
analysis operations in ZEISS arivis Pro. The Deep
Learning Segmenter supports a wide range
of Deep Learning models, including models
trained locally in ZEISS arivis Pro using the Deep
Learning Trainer as described above, models
trained on the ZEISS arivis Cloud platform, as
well as external pre-trained models saved in the
ONNX format.
Figure 14b shows the segmentation result of
the image from Figure 14a using the trained
model from the Deep Learning Trainer, as
described earlier. Figure 14a is the same as
Figure 11a , depicting a 2D slice of Nissl-stained
neuronal soma. The Deep Learning-based
approach in this example employs semantic
segmentation at the pixel level. Therefore,
objects need to be separated using a
Figure 14: (a) 2D slice of Nissl-stained neuronal soma. (b) Semantic segmentation result using a trained Deep Learning
model from the Deep Learning Trainer in ZEISS arivis Pro.
Watershed algorithm, like the approach taken
for conventional Machine Learning-based
segmentation. However, the Watershed
algorithm can struggle with over- or under-
splitting objects, especially when the objects
vary in size, which requires a more effective
instance segmentation approach.
Comparing this result with the one obtained
using the Machine Learning-based approach in
Figure 11c , both results appear nearly identical,
suggesting that semantic segmentation Deep
Learning does not offer a significant advantage
over conventional Machine Learning for simple
objects in this specific dataset. However, it
is worth noting that Deep Learning models
typically yield more robust results when the
input image exhibits variance in image contrast.
To leverage the true power of Deep Learning,
an instance segmentation model can be
trained on ZEISS arivis Cloud and imported into
the Deep Learning Segmenter in ZEISS arivis
Pro (requires version 4.2 or later). Users can
access the “ZEISS arivis Cloud AI model store”
using an access token that allows them to
download ZEISS arivis Cloud-trained models for
local execution (see Figure 15 ).
— — — — — — — — — — — — — — —
Page 32
AI in ZEISS arivis software for scalable automated analysis 30Figure 15: Accessing the “ZEISS arivis Cloud AI model
store” to download trained models for local execution.
Figure 16: Comparison of segmentation results for neuronal soma using (a) conventional Machine Learning, (b)
semantic Deep Learning, and (c) instance Deep Learning with a mode trained on ZEISS arivis Cloud. Note that the instance
segmentation approach results in proper separation of touching objects (blue arrows). While the diff erence may seem
minor in a single slice, the errors accumulate signifi cantly over large volumes or areas containing vast amounts of objects.
Once downloaded, the model can be used in
various image analysis pipelines to automate
the segmentation process. Figure 16c shows
the instance segmentation result using a
trained arivis Cloud instance model imported
into the Deep Learning Segmenter in arivis Pro.
For comparison, the results from conventional
Machine Learning (see Figure 16a )and
semantic Deep Learning (see Figure 16b )are
also juxtaposed next to the instance Deep
Learning segmentation result (see Figure 16c ).
Individual soma are segmented much better
using the instance segmentation method
compared to pixel level segmentation using
Machine Learning or Deep Learning followed
by Watershed-based separation. This allows
for reproducible image analysis when instance segmentation models are used in large analysis
pipelines.
Figure 17 showcases a challenging
segmentation task involving tightly packed
nuclei from an intestinal organoid dataset
spanning 170 time points. Panels (a), (b),
and (c) depict time points 1, 85, and 170,
respectively, at which individual nuclei need to
be reliably segmented and tracked throughout
the experiment. Deep Learning-based instance
segmentation proves to be the ideal approach
for tackling this task.
A custom instance segmentation model,
trained on ZEISS arivis Cloud, was downloaded
and employed in ZEISS arivis Pro to segment
the nuclei across the entire dataset. The
segmentation results, displayed in panels
(d), (e), and (f), (corresponding to the
respective input images), demonstrate
robust performance. It is noteworthy that
the segmentation results are robust, even for
the last time point shown in panel (f) , where
the intensity appears to gradually decrease
due to photobleaching. This level of reliable
segmentation across time points and z-planes
prepares the data for downstream analysis,
enabling valuable applications such as tracking.
While training custom Deep Learning models
on ZEISS arivis Cloud enables tailored solutions
for segmenting complex images, off -the-shelf
— — — — — — — — — — — — — — —
Page 33
AI in ZEISS arivis software for scalable automated analysis 31
Figure 17: Deep Learning-based instance segmentation of nuclei in an intestinal organoid dataset across multiple
time points. (a–c) Input images at time points 1, 85, and 170. (d–f) Corresponding instance segmentation results using
a ZEISS arivis Cloud-trained model, enabling robust nuclei tracking over time. Sample credit: Clayton Schwarz of Labs of
Anna-Katerina Hadjantonakis at Memorial Sloan Kettering Cancer Center and Eric Siggia at Rockefeller University.
pre-trained models can be useful in certain
scenarios. For example, when segmenting cells
in fluorescent microscopy images, a pre-trained
Cellpose model may provide excellent results
without the need for custom training.
Cellpose Pre-trained Segmenter
ZEISS arivis Pro provides the option to
seamlessly incorporate Cellpose-based
Segmenter operations that are designed
specifically to segment cells or nuclei in
fluorescence microscopy images. Custom-
trained Cellpose models can also be imported into this operation to segment objects of
interest.
The Cellpose Segmenter, an open-source
software, provides pre-trained models that can
be used to segment images for cells and nuclei,
in most cases, without any custom training.
These include models trained on fluorescent
cell images, diverse cell images, cytoplasm
models, models trained on multiple channels,
and nuclei models. Similar to other Deep
Learning tools in ZEISS arivis Pro, the Cellpose-
— — — — — — — — — — — — — — —
Page 34
AI in ZEISS arivis software for scalable automated analysis 32Figure 18: Cellpose segmentation parameters in ZEISS
arivis Pro, including cell diameter, mask threshold, and
mask quality.
Figure 19: Segmentation results obtained using Cellpose. (a) Fluorescence microscopy image showing cytoplasm (green),
mitochondria (red), and nuclei (blue). (b) Cell segmentation result using the pre-trained Cellpose model in ZEISS arivis Pro.
Detected cells are shown in random colors.
based Segmenter leverages GPU acceleration
for faster computations if it’s available.
The Cellpose model uses additional parameters
for segmentation, including cell diameter, mask
threshold, and mask quality parameters (see
Figure 18 ). Please refer to the corresponding
Cellpose paper [2] for a detailed explanation of
these parameters and their impact. In Figure
18, the pre-trained Cellpose model (named
“CP”) refers to a model primarily trained on fl uorescence microscopy images of cells. This
model has been applied to segment cells in
the image shown in Figure 19a, which displays
cytoplasm (green), mitochondria (red), and
nuclei (blue), respectively.
The green cytoplasm channel was defi ned as
the primary input, with the blue nuclei channel
as the secondary input. The approximate
cell diameter was set to 30 microns after
measuring several cells using the measurement
tool in ZEISS arivis Pro. Other parameters
were set to their default values. With a
single click, the image was segmented with
excellent results, shown in Figure 19b . This
demonstrates the out-of-the-box power of
the Cellpose-based Segmenter for segmenting
cells in fl uorescent microscopy images. Custom
Cellpose models can also be imported, or
custom ZEISS arivis Cloud models may be
trained for more challenging images.
Labeling 3D ground truth using ZEISS
arivis Pro VR
ZEISS arivis Pro VR is a module that enables
virtual reality-based collaborative data
visualization and interactivity during image
analysis. While virtual reality (VR) is often
associated with gaming, its applications extend
far beyond entertainment. With ZEISS arivis Pro
VR, researchers can literally step into their 3D
— — — — — — — — — — — — — — —
Page 35
AI in ZEISS arivis software for scalable automated analysis 33Figure 20: 3D data annotation in ZEISS arivis Pro VR. (a) User interface for selecting annotation tools, with a 3D dataset of
cells from a developing fl y embryo in the background. (b) 3D annotated objects created by navigating through the dataset
and annotating cells using the selected tool. Dataset courtesy of Celia Smits, Stanislav Y. Shvartsman, Department of
Molecular Biology, Princeton University.
ZEISS arivis Pro VR capabilities
www. zeiss.com/arivis-pro-vr
datasets, tagging voxels for ground truth and
laying the foundation for advanced 3D Deep
Learning.
Figure 20 shows the data annotation screen in
ZEISS arivis Pro VR as experienced through the
immersive VR environment. Figure 20a displays
the user interface within the VR environment,
where the user can select an appropriate tool
for 3D annotation, in this case, a Magic Wand.
The 3D dataset in the background corresponds
to images of cells from a developing fl y embryo
acquired using a Luxendo MuVi SPIM. Figure
20b illustrates 3D annotated objects, where
the user can navigate through the cells and
annotate them using the selected tool, creating
ground truth data for advanced 3D Deep
Learning applications.
A recent Nature Methods paper [3] highlights
the innovative use of virtual reality annotation
with ZEISS arivis Pro VR. Researchers discovered
that the immersive VR environment allowed
them to generate high-quality 3D training data
for Deep Learning-based cell segmentation
across entire mouse brains, much faster than
traditional 2D methods.By leveraging the power of VR, researchers
can truly immerse themselves in their data,
enabling more intuitive and effi cient 3D ground
truth labeling. This cutting-edge technology
paves the way for advanced 3D Deep
Learning analysis, opening new possibilities in
understanding complex biological structures
and processes.
Machine Learning for object
classifi cation in ZEISS arivis Pro
The segmentation and analysis of images in
ZEISS arivis Pro result in the quantifi cation of
various parameters for all detected objects
in the dataset. These parameters range
from morphological characteristics, such
as area, volume, and sphericity, to intensity
measurements from various channels in the
dataset. The Machine Learning trainer for
object classifi cation in ZEISS arivis Pro uses
these parameters as input features to train
a Random Forest algorithm. Conventional
Machine Learning is well suited to this task,
given the limited number of features required
for training. The trained Machine Learning
model can then be used to classify all
segmented objects within a dataset.
Figure 21 illustrates the ZEISS arivis Pro interface
for Machine Learning-based Object Training.
The objects displayed on the screen depict
the Nissl-stained neuronal soma segmented
using conventional Machine Learning shown
— — — — — — — — — — — — — — —
Page 36
AI in ZEISS arivis software for scalable automated analysis 34Figure 21: Machine Learning-based Object Training interface in ZEISS arivis Pro, showing segmented neuronal soma
objects classifi ed into Spherical (blue) and Non-Spherical (orange) classes based on selected features like Mean intensity,
Sphericity, and VoxelCount.
earlier in Figure 11 . It is worth noting that any
segmentation approach, including semantic
or instance Deep Learning methods discussed
earlier, could be used to generate objects for
this training process.
To initiate object classifi cation training,
individual objects were manually selected
by clicking and assigned to one of two
classes: Spherical and Non-Spherical in this
example. Various morphological and intensity
measurements can be chosen as features to
train the Machine Learning object classifi er.
In the provided example, “Mean intensity,”
“Sphericity,” and “VoxelCount” were selected
as the features for training. The training
process typically occurs in real-time, within a
second. Clicking the “Run” button applies the
trained model to the entire dataset, providing
valuable visual feedback for any necessary
modifi cations. In this example, all objects in
blue correspond to the “Spherical” class, while
the orange objects represent the “Non-Spherical” class, as defi ned by the user. It is
important to note that this is a simple example
featuring two classes, but multiple classes and
multiple features can be selected for other
object classifi cation tasks.
This object classifi cation approach is highly
benefi cial for classifying objects that cannot
be easily categorized using a single parameter,
especially when classifying into more than
two classes. Typical applications range from
classifying contaminant particles on fi lter paper
to categorizing cells undergoing mitosis into
various stages.
Deep Learning for denoising multi-
dimensional datasets
Fluorescence microscopy of biological
specimens, especially for live-cell imaging,
often exhibits noise due to the low signal-to-
noise ratio. This arises from the need to limit
the amount of excitation energy to avoid
phototoxicity or damage to the live cells,
— — — — — — — — — — — — — — —
Page 37
AI in ZEISS arivis software for scalable automated analysis 35
Figure 22: Denoising of 4D fluorescence microscopy data. (a) Raw, noisy image of a live cell undergoing mitosis, showing
microtubules (green) and separating chromatids (red). (b) Denoised image after applying a Noise2Void model trained in
ZEN and imported into ZEISS arivis Pro, revealing clear microtubule structures and cellular features.resulting in a relatively weak fluorescence
signal. While techniques like signal averaging
or slower scanning can improve the signal-
to-noise ratio during image acquisition, the
resulting images still contain noise, requiring
the use of denoising algorithms to enhance the
quality of the acquired data.
The advent of Deep Learning in the mid-2010s
has led to numerous proposed Deep Learning-
based denoising algorithms, offering more
robust and efficient solutions. Among these,
the Noise2Void approach has emerged as
the preferred algorithm for scientific image
denoising [4,5]. It is capable of learning directly
from noisy images and effectively removing
noise while preserving important image
features and details. Noise2Void models can
be easily trained using ZEN, as will be discussed
in detail in the next chapter. These models
can also be trained using custom code and
saved in the CZANN format using the czmodel
library [6]. The trained CZANN denoising model
can then be imported into ZEISS arivis Pro
to denoise images, including large multi-
dimensional datasets.
Figure 22 shows a denoising example of 3D
time-series data (4D). Figure 22a shows the
raw, noisy fluorescence microscopy image of
a live cell undergoing mitosis. As discussed earlier, the noise arises from the necessity to
image the sample under gentle conditions to
avoid disturbing the mitotic process. The green
channel shows the microtubules, and the red
channel shows the separating chromatids.
Individual microtubules are indiscernible in
this noisy image. To denoise the data, a single
plane was extracted from this dataset and
used to train a Noise2Void model in ZEN. This
trained model was then imported into ZEISS
arivis Pro and applied to denoise the entire
4D dataset. The denoised image in Figure 22b
clearly reveals the microtubules, along with
other features in the image. This level of clarity
allows researchers to extract insights from the
dataset to further scientific understanding of
the process under study.
As discussed, ZEISS arivis Pro offers various
AI-powered tools to enable automated
image analysis via customized pipelines.
These pipelines can be executed to process
multiple datasets in batches. The computation
fully relies on the local resources available
on the workstation. However, for very large
datasets, particularly in applications such as
3D high-content analysis, scalable processing
infrastructure is required to obtain timely
results. ZEISS arivis Hub is specifically designed
to address this need.
— — — — — — — — — — — — — — —
Page 38
AI in ZEISS arivis software for scalable automated analysis 36AI in ZEISS arivis Hub for scalable image
analysis
ZEISS arivis Hub enables the design and
execution of large-scale experiments via
parallelized processing using multiple
computational workers on on-premises or
cloud-based servers. It is designed to execute
the AI-powered image analysis pipelines
customized in ZEISS arivis Pro at scale by
parallelizing the computation across local or
cloud-based server resources.
Applications that fall under high-content
analysis (HCA), where numerous samples
in multiwell plates are analyzed, can greatly
benefi t from such scaled analysis capabilities.
AI becomes crucial for these applications,
even for 2D analysis. For example, assays
that rely on unlabeled samples can leverage
Deep Learning-based segmentation of cells
imaged under brightfi eld illumination. Even
for labeled samples where cellular and nuclear
segmentation is challenging, custom Deep
Learning models trained on ZEISS arivis Cloud
or pre-trained open-source models such as
Cellpose can be employed to segment cellular
and nuclear structures accurately.
Figure 23: Example of a 3D organoid analysis pipeline in ZEISS arivis Pro, using blob detection for nuclei and conventional
Machine Learning segmentation for the overall organoid structure.
While traditional HCA has focused primarily
on 2D cell cultures, there is a growing
recognition of the limitations associated with
this approach. 2D cell cultures often fail to
accurately replicate the complex 3D structure
and microenvironment of tissues found in the
human body, leading to potential discrepancies
between in vitro and in vivo results. In contrast ,
3Dcell cultures off er a more physiologically-
relevant model for studying cellular responses.
They enable the investigation of cell–cell and
cell–matrix interactions, nutrient gradients,
and other factors that are not present in 2D
cultures. As a result, there is an increasing
demand for 3DHCA in drug discovery and
other biomedical research fi elds .
Transitioning from 2Dto3DHCA poses
signifi cant challenges due to the inherent
complexity and heterogeneity of 3D cell
cultures compared to their 2Dcounterparts,
making image acquisition and analysis more
diffi cult. A major bottleneck for most HCA
analysis software lies in their limited capability
to handle large 3D datasets, which can contain
terabytes of data. The ZEISS arivis software
architecture addresses this limitation by
— — — — — — — — — — — — — — —
Page 39
AI in ZEISS arivis software for scalable automated analysis 37
Visit Organoid Analysis Case Study
www.zeiss.com/3d-organoid-analysisseamlessly processing 2Dand3Dimages in the
terabyte range. In addition, the scalability of
ZEISS arivis Hub, coupled with its AI-powered
analysis capabilities, enables the handling and
analysis of growing image and experiment
sizes for a wide range of applications, including
phenotypic screening, organoid analysis, and
other 2D, 3D, and 4D cellular studies .
AI-Powered 3D analysis of organoid
multiwell plates on ZEISS arivis Hub
3D analyses of organoids in multiwell plates
illustrate the power of automated scalable
analysis in ZEISS arivis Hub. The process
begins in ZEISS arivis Pro, where users
construct an image analysis pipeline with
real-time 3D feedback during the defi nition
phase. This interactive approach allows for
experimentation with various tools and parameter optimization. For segmentation
tasks, users may start by evaluating traditional
methods like thresholding or blob detection.
If these prove unsuitable for specifi c features,
they can use conventional Machine Learning
or Deep Learning models. ZEISS arivis Pro
enables the creation of complex image
analysis pipelines tailored to extract desired
insights from the image data. Figure 23 shows
one such pipeline for 3D organoid analysis,
employing Deep Learning (Cellpose) for nuclei
segmentation and conventional Machine
Learning segmentation (Random Forest) for
the overall organoid structure, complemented
by additional image processing operations
like region growing. The pipeline follows the
workfl ow illustrated in Figure 24.
Once validated on a few datasets, the pipeline
is imported into ZEISS arivis Hub for scalable
analysis across multiple datasets. Users can
apply the pipeline as individual jobs or larger
workfl ows to analyze numerous images stored Figure 24: Workfl ow chart for the 3D organoid analysis pipeline.
— — — — — — — — — — — — — — —
Page 40
AI in ZEISS arivis software for scalable automated analysis 38
Figure 25: ZEISS arivis Hub viewer showing the multiwell plate layout in the top left, featuring an image of a single
organoid in the selected well B7 on the right.as datasets within ZEISS arivis Hub. Figure 25
shows an image of a single organoid in well B7
from a multiwell plate, shown in the top left
of the fi gure. The multiwell plate dataset has
been analyzed using the pipeline constructed
in ZEISS arivis Pro, with the workfl ow results
screen displayed in Figure 26 .
This image shows a heat map of the selected
metric, which in this case is the mean intensity
of nuclei within the organoid. Clicking on a
specifi c well, such as B7, reveals additional
result details alongside the processed image
in an interactive viewer on the bottom left.
Results can be exported in various formats,
including CSV outputs for further analysis. A
detailed study of this use case is found using
the link below.While this example focuses on a single
multiwell plate, users benefi t signifi cantly
from this AI-powered automated and scaled
analysis when applied to multiple multiwell
plates, where data is processed in parallel using
multiple analysis worker processors (see
Figure 27 ). This speed scales seamlessly based
on the number of analysis workers subscribed
to local or cloud servers.
As the microscopy fi eld continues to evolve, so
must the tools and techniques. By embracing
AI powered solutions, researchers can continue
to analyze microscopy data even when it grows
in size and complexity.
— — — — — — — — — — — — — — —
Page 41
AI in ZEISS arivis software for scalable automated analysis 39
Figure 26: Workfl ow results screen in ZEISS arivis Hub, displaying a heat map of the mean intensity of nuclei in the
organoid with additional result details and an interactive viewer for the processed image.
Figure 27: An illustration highlighting the scalable analysis capabilities of ZEISS arivis Hub, depicting parallel processing
of multiple multiwell plate datasets. Multiple analysis worker processors are shown concurrently processing diff erent
organoids, demonstrating the ability of the platform to effi ciently analyze large volumes of data through seamless scaling.
— — — — — — — — — — — — — — —
Page 42
AI in ZEISS arivis software for scalable automated analysis 40References
1. Youtube. A Chat with Andrew on MLOps: From Model-centric to Data-centric AI. URL: https://
www.youtube.com/watch?v=06-AZXmwHjo&ab_channel=DeepLearningAI (accessed 02
September 2024).
2. Stringer C, Wang T, Michaelos M, et al . Cellpose: a generalist algorithm for cellular
segmentation. Nat Methods . (2021) 18 :100–106. doi: 10.1038/s41592-020-01018-x.
3. Kaltenecker D, Al-Maskari R, Negwer M, et al . Virtual reality-empowered deep-learning analysis
of brain cells. Nat Methods . (2024). doi: 10.1038/s41592-024-02245-2.
4. Krull A, Buchholz T-O, Jug F. Noise2Void - Learning Denoising from Single Noisy Images. (2018)
arXiv:1811.10980. doi: 10.48550/arXiv.1811.10980.
5. Höck E, Buchholz T-O, Brachmann A, Jug F, and Freytag A. N2V2 - Fixing Noise2Void
Checkerboard Artifacts with Modified Sampling Strategies and a Tweaked Network
Architecture.
6. Pypi. czmodel. URL: https://pypi.org/project/czmodel/ (02 September 2024).
— — — — — — — — — — — — — — —
Page 43
AI in ZEISS arivis software for scalable automated analysis 41
— — — — — — — — — — — — — — —
Page 44
AI in ZEN and ZEN core imaging and analysis platform 42Figure 1: A schematic representation of a typical microscopy imaging workfl ow, illustrating the sequential steps from
image acquisition to preprocessing, image analysis, classifi cation, and result and report generation.
Figure 2: Microscopy imaging workfl ow with examples of AI techniques applied in preprocessing (denoising), image
analysis (segmentation), and classifi cation.
A schematic representation of a typical microscopy imaging workfl ow, illustrating the sequential steps from
Microscopy imaging workfl ow with examples of AI techniques applied in preprocessing (denoising), image
ZEN and ZEN core are robust microscopy
software packages that off er a broad range
of image analysis and processing tools
tailored to support the standard workfl ow
of microscopists (see Figure 1 ). From image
acquisition to preprocessing, analysis, and the
fi nal result presentation, these tools guide users
through every step.
The ZEN software packages off er dedicated
analysis tools alongside a versatile image
analysis toolkit, incorporating powerful
Machine Learning algorithms for diff erent
phases of the workfl ow (see Figure 2 ). For
example, the Noise2Void algorithm facilitates
image denoising, while semantic and instance
segmentation methods are available for image AI in ZEN and ZEN core imaging and analysis platform
segmentation tasks. Additionally, the software
supports Machine Learning-based object
classifi cation.
These solutions build upon established and
widely recognized tools and frameworks like
PyTorch, TensorFlow, and ONNX, and are fi ne-
tuned for simplicity and seamless integration
with imaging workfl ows. They can be readily
used within preconfi gured workfl ows in ZEN
and ZEN core.
Preconfi gured workfl ows in ZEN and
ZEN core
Preconfi gured workfl ows in ZEN and ZEN core
simplify common image analysis tasks and
are organized into Material Apps (for tasks
— — — — — — — — — — — — — — —
Page 45
AI in ZEN and ZEN core imaging and analysis platform 43Figure 3: Machine Learning segmentation in ZEN facilitates training classical Machine Learning models for image
segmentation tasks. (a) Image of an organoid that requires segmentation. (b) Annotated organoid demonstrating how
only a few annotations are required for training. (c) Organoid image segmented into cell layer (orange), lumen (red),
and background (cyan) classes. (d) The initial prediction along with annotations. Panel (c) illustrates the model’s final
segmentation predictions, assigning every pixel to one of the three classes. Additional annotations can refine the model,
enabling segmentation of the entire 3D organoid stack.
like Grain Size Analysis and layer thickness
measurement) and Bio Apps (for tasks such as
cell counting and gene expression analysis). The
following modules are available:
Bio Apps
■Cell Counting.
■Gene- and Protein Expression.
■Translocation.
■Confluency.
■Automated Spot Detection.
Material Apps
■Grain Size Analysis.
■Multiphase Analysis.
■Cast Iron Analysis.
■Layer Thickness.
■Technical Cleanliness Analysis.The integration of AI within the ZEN
software has revolutionized microscopy,
enhancing speed, efficiency, and accuracy to
unprecedented levels.
AI-based image segmentation in ZEN and
ZEN core
Image segmentation is a critical step in the
automated analysis process of microscope
images. It involves the precise and reliable
identification and separation of regions of
interest (ROI) from the background. ZEN
and ZEN core offer a diverse range of image
segmentation options, including classical
methods such as thresholding, variance-based
segmentation, and dynamic thresholding.
Machine Learning
In recent years, Machine Learning-based
techniques like Random Forest pixel classifiers
and Deep Neural Networks (DNNs) have
been developed and successfully applied to
enhance image segmentation. ZEN and ZEN
core provide the capability to directly train a
Machine Learning model based on a Random
Forest pixel classifier within the software or
to use prior-trained Deep Learning networks
for segmentation. This flexibility enables users
— — — — — — — — — — — — — — —
Page 46
AI in ZEN and ZEN core imaging and analysis platform 44Figure 4: Examples of image segmentation via classical Machine Learning across life sciences and materials sciences
disciplines. The figure displays original microscopy images acquired through techniques such as (a) X-ray microscopy, (b)
and (c) fluorescence microscopy, (d) and (e) brightfield microscopy, and (f) electron microscopy. Image pairs are presented
with the original image on the left and the segmentation results obtained using conventional Machine Learning algorithms
on the right.
to choose the most suitable method for their
specific application.
Users can train the Random Forest pixel
classifier within ZEN, where they can load
images, create multiple classes as required,
annotate the images, and train the model.
Figure 3 illustrates the training user interface,
demonstrating an example of training a
Machine Learning model to segment the cell
layer and lumen of an organoid.
A variety of examples from both life sciences
and materials sciences are illustrated in Figure
4, where the image on the left-hand side in
each column depicts the original image, and
the corresponding image on the right-hand
side displays the segmentation result using
a conventional Machine Learning model
trained in ZEN. These examples reflect the
agnostic nature of these algorithms regarding
the microscope that generated the images,
encompassing brightfield and fluorescent
light microscopy images, electron microscopy
images, and even three-dimensional
(3D) volumetric data collected on X-ray
microscopes.Deep Learning
While conventional Machine Learning provides
robust segmentation for many applications,
users may opt for Deep Learning to achieve
enhanced segmentation of complex images.
ZEN offers various interfaces for importing
externally trained Machine Learning and
Deep Learning models. For example, Deep
Learning models trained on ZEISS arivis Cloud
can be imported to segment images as part
of image analysis pipelines. ZEN software has
also expanded its AI capabilities by enabling
users to import instance segmentation
models trained on ZEISS arivis Cloud.
These models excel in scenarios involving
touching and/or overlapping objects, which
are common in scientific images and pose
significant challenges for traditional pixel-level
segmentation methods.
The openness of AI interfaces in ZEN (see
Figure 5 ) empowers users to import models
trained elsewhere, such as those developed
using their own Python code in a Jupyter
notebook. These external models can be
seamlessly imported using the czmodel [1]
open-source Python package. By integrating
— — — — — — — — — — — — — — —
Page 47
AI in ZEN and ZEN core imaging and analysis platform 45Figure 5: Flowchart illustrating the integration of AI models trained from various sources into ZEN and ZEN core software
for image analysis tasks. Conventional Machine Learning models can be trained using the Intellesis Training UI within
ZEN. Deep Learning models for semantic or instance segmentation can be trained on the ZEISS arivis Cloud platform,
while semantic segmentation or denoising models can be developed through custom Jupyter notebooks or Python code.
Regardless of where the models are trained, they can be imported and used within the ZEN and ZEN core environments for
diverse image analysis applications.
various segmentation algorithms into one
analysis, users can adaptively address the
specifi c requirements of their samples.
Advanced AI tools for image analysis
beyond segmentation
With its diverse segmentation options, ZEN
is invaluable to researchers in biology and
materials sciences. Yet, segmentation is just
one facet of image analysis workfl ows where
AI can make signifi cant contributions. For
example, segmented objects can undergo
further classifi cation using Machine Learning
algorithms. Additionally, AI-driven denoising
enhances image quality, which is particularly
benefi cial for sensitive samples yielding images
with low signal-to-noise ratios. This section
explores these additional aspects to shed light
on the transformative potential of AI beyond
segmentation.
Object classifi cation
Various methods ranging from simple
thresholding to advanced Deep Learning
techniques can segment objects within images. However, certain applications demand
additional classifi cation of these objects based
on shape, size, morphological parameters,
and pixel intensity values from one or more
channels. While traditional cluster analysis can
achieve this, Machine Learning off ers a more
robust approach to object classifi cation.
ZEN and ZEN core object classifi cation
solutions
ZEN and ZEN core provide a user-friendly
interface for training Machine Learning-based
object classifi cation models, leveraging various
morphological and intensity parameters
calculated automatically by the software.
For model training, users can use one or
more images that have been previously
segmented using any segmentation method
(e.g., thresholding or Deep Learning) via the
image analysis tools in ZEN or ZEN core. Users
can classify segmented objects into as many
diff erent classes as needed, simply by visually
identifying objects belonging to specifi c classes
and assigning them a label by simply clicking
on them with a computer mouse.
— — — — — — — — — — — — — — —
Page 48
AI in ZEN and ZEN core imaging and analysis platform 46Figure 6: The Object Classification Training interface in ZEN core facilitates training classical Machine Learning models for
particle classification tasks. (a) All particles are segmented via simple thresholding and shown with a light gray outline. (b)
A selection of particles from each of the three classes: metallic (orange), non-metallic (cyan), and fiber (red) are selected
from the thresholded particles to train the classification model. (c) The final model predictions with every particle classified
into one of the three classes. (d) Classification results for the entire image based on the training selections. This trained
model could be applied to classify particles in other images.
Only a few labeled objects are needed to
initiate training, during which the Machine
Learning model learns from the parameters
extracted from these objects. The training
process occurs in near real-time, allowing users
to dynamically adjust the selection of objects,
add or remove labels, or reassign labels based
on the evolving results.
Figure 6 shows the ZEN core training interface,
demonstrating a filter sample with various
particles; fibers labeled in red, metallic particles
in orange, and non-metallic particles in
cyan. Once trained, the model can automate
the object classification process as part of
end-to-end image analysis workflows for future
images.
Denoising
Microscope image quality can be compromised
by a multitude of imperfections originating
from various sources. For example, electronic
and thermal sources often introduce noise into images, making it challenging to
distinguish signal from noise (see Figure 7).
Noise is particularly problematic and affects
image quality across different microscopy
modalities, including fluorescence and electron
microscopy. It obscures the signal of interest,
complicating the differentiation between
genuine signal and noise.
Noise in fluorescence microscopy images
Fluorescence microscopy of biological
specimens, especially live-cell images, often
suffer from a low signal-to-noise ratio due to
several factors. Live cells are highly sensitive
to external stimuli, such as intense light
or chemicals, which limits the amount of
excitation energy that can be used to induce
fluorescence without causing phototoxicity
or other damage to the cells. Consequently,
the fluorescence signal emitted by the
fluorophores in the sample is relatively weak,
making it challenging to distinguish from the
background noise.
— — — — — — — — — — — — — — —
Page 49
AI in ZEN and ZEN core imaging and analysis platform 47Figure 7: Examples of various imaging imperfections and noise sources that degrade image quality. The top row shows
noise-free images as well as artifacts like diff raction limit, uneven background, and imaging errors. The bottom row
displays corresponding line profi les, illustrating how diff erent noise types, such as shot noise and detector noise, aff ect the
detected intensity profi les compared to the noise-free case.
For images collected at low laser power,
approaches such as averaging the signal
over multiple frames or slowing the scanning
speed can be employed to improve the
signal-to-noise ratio. However, these may still
result in noisy images, necessitating the use
of noise-removing techniques to enhance the
quality of the acquired data.
Noise in electron microscopy images
Electron microscopy is also susceptible to
noise arising from various factors, including
low electron dose, specimen drift, and
detector noise. While metallic samples and
other conductors can be imaged under higher
voltages and currents to achieve higher
resolution, non-conductive materials such as
ceramics, polymers, and biological specimens
must be imaged at ultra-low voltages and
currents to prevent beam charging eff ects and
sample damage. This reduced-dose approach
results in images in which the underlying
structure of interest is obscured by the noise.
Therefore, denoising techniques become
essential for extracting meaningful information
from these low-dose electron microscopy
images.ZEN and ZEN core denoising solutions
Traditional denoising algorithms, while
eff ective, often come with trade-off s. For
example, applying a Gaussian fi lter is a
straightforward way to remove noise, but
it also reduces image sharpness due to the
blurring operation at every pixel. Non-local
means fi ltering [2,3] and block-matching and
3D fi ltering (BM3D) [4] are reliable denoising
approaches and are widely used, especially in
the fi elds of computed tomography and MRI
imaging. However, since the advent of Deep
Learning, numerous Deep Learning-based
algorithms that off er more robust and effi cient
denoising solutions have been proposed.
Among these, the Noise2Void approach [5–7]
has become a popular choice, as it can directly
learn from noisy images and remove noise
eff ectively while preserving important features
and details.
— — — — — — — — — — — — — — —
Page 50
AI in ZEN and ZEN core imaging and analysis platform 48Figure 8: Application of Noise2Void in ZEN for denoising an electron microscopy image. (a) The original image of a
tobacco leaf, displaying significant noise due to low voltage and current settings chosen for the sensitive nature of the
sample. (b) The image after denoising with Noise2Void in ZEN, revealing improved clarity and reduced noise artifacts. Real-time AI-assisted denoising
Noise2Void models can be easily trained
and deployed using ZEN and ZEN core,
allowing users to denoise images from any
imaging source, including light and electron
microscopy (see Figure 8 ). A key advantage of
the Noise2Void algorithm is that it does not
require corresponding clean images (ground
truth) for training, unlike typical Deep Learning
approaches. This makes the process of training
a Noise2Void model relatively straightforward.
Users simply need to load their noisy images,
train the model, and then apply it to denoise
images. The trained model can even be applied
during live sample navigation (see Figure 9 ),
reducing the need for higher light intensities,
thus allowing for gentler imaging with less
photobleaching and phototoxicity.
This real-time denoising capability of
Noise2Void models in ZEN offers a powerful
solution for enhancing image quality while
minimizing potential damage to sensitive
biological samples during the setup of live-cell
imaging experiments.
Harnessing AI in automated image
analysis workflows
While the AI tools discussed earlier for
segmentation, classification, and denoising are
valuable for analyzing individual datasets, their
full potential is realized when integrated into
end-to-end image analysis workflows tailored
to specific tasks. For example, tasks such as
grain size distribution analysis in materials and
geosciences or automated gene expression
workflows in biological research can benefit
immensely from the automation provided by
AI-trained models. These models streamline
processes that would otherwise be labor-
intensive and time-consuming, enabling users
to focus on higher-level analysis.
AI models can also facilitate guided image
acquisition workflows, allowing for the
efficient collection of high-resolution multi-
dimensional images from specific ROI. In the
following sections, a concise overview of
these applications is provided, exploring how
the integration of AI into the pre-defined
applications in ZEN, known as Material
Apps and Bio Apps, as well as guided image
acquisition workflows, enhances efficiency and
productivity in microscopy.
— — — — — — — — — — — — — — —
Page 51
AI in ZEN and ZEN core imaging and analysis platform 49Integration of AI into Material Apps
ZEN core Material Apps offer standardized
workflow-driven solutions tailored for materials
and production labs, adhering to industry
standards. These solutions, including Grain
Sizing, Multiphase Analysis, Cast Iron Analysis,
Layer Thickness measurements, and Technical
Cleanliness Analysis, are designed to support
the specific requirements of each application.
Each Material App comprises pre-configured
workflows encompassing all stages from
acquisition and analysis to result display and
reporting. For challenging samples, several
workflows incorporate the use of Machine
Learning models for image segmentation
during analysis.
Using Material Apps for Grain Size
Analysis
Grain Size Analysis plays a crucial role as the
size and distribution of grains directly impact
material properties. This analysis enables the
quantification of the crystallographic structure
of metallographic samples in accordance
with international standards. Segmenting
grain structures in microscope images has
traditionally been challenging due to various factors. The methods used often fall short
in accurately identifying individual grains,
leading to the adoption of alternate manual or
semi-automated approaches like the intercept
method. However, these tend to yield less
accurate results as they do not sample all grains
in their entirety to calculate grain size. Even
conventional Machine Learning and Deep
Learning techniques for semantic segmentation
struggle to properly segment and separate
grains.
In response to these challenges, Deep
Learning-based instance segmentation
techniques have emerged as the preferred
solution. This approach excels in detecting
touching and overlapping objects, making
it highly suitable for grain size distribution
analysis. Instance segmentation models
trained on ZEISS arivis Cloud can be seamlessly
imported into ZEN core Material Apps, offering
a streamlined analysis process that ensures
accurate and reliable results for materials
characterization.
Figure 10 displays the ZEN core Grain Size
Analysis results screen, featuring both the
original image and the analyzed image Figure 9: Live denoising during sample navigation. (a) Raw image captured during sample navigation in a widefield
microscope, showcasing a fluorescently labeled sample. (b) The same image with live denoising switched on demonstrates
improved clarity, highlighting the effectiveness of denoising even on images collected during navigation.
— — — — — — — — — — — — — — —
Page 52
AI in ZEN and ZEN core imaging and analysis platform 50Figure 10: Grain Size Analysis in ZEN core showing the ZEN core interface for Grain Size Analysis. An instance
segmentation model trained on ZEISS arivis Cloud is imported into ZEN core to segment individual grains within an
aluminum Barker etched sample. This segmentation process enables the extraction of the size distribution of individual
grains, facilitating comprehensive analysis.
with clearly separated grains. These grains
have been automatically segmented using
an instance segmentation model trained
on ZEISS arivis Cloud. In addition, Figure
10 includes a grain size distribution plot,
demonstrating the eff ectiveness of AI-powered
instance segmentation models in providing
single-click solutions for grain size distribution
analysis. Such automation not only enhances
analysis throughput but also ensures result
reproducibility, regardless of who conducts the
image analysis.
Integration of AI into Bio Apps
Bio Apps comprise a streamlined suite of image
analysis tools specifi cally tailored to common
tasks in cell biology and cancer research. These
tools provide specialized solutions for tasks
such as cell counting, cellular gene expression
analysis, and nuclear translocation studies.
Using Bio Apps to quantify gene
expression
Gene expression assays are powerful
techniques employed by researchers to investigate the complex patterns of gene
activity within cells or tissues. These assays
enable the quantifi cation of specifi c messenger
RNA (mRNA) molecules, or the corresponding
proteins produced to provide invaluable
insights into the dynamic processes that govern
cellular function and behavior. One widely
used approach in gene expression studies
involves the use of fl uorescent proteins, such
as mCherry [8], which can be genetically
engineered to serve as reporters for the
expression of genes of interest [9].
To accurately quantify gene expression at the
single-cell level, it is crucial to precisely segment
and identify individual cells within the sample.
While multiple fl uorescent markers can be
used to mark various cellular and sub-cellular
regions, researchers often prefer working with
unlabeled samples for cost-eff ectiveness and
to allow for gentle imaging conditions. Oblique
contrast microscopy of such unlabeled samples
provides the necessary contrast to visually
discriminate individual cells. To computationally
automate the cellular segmentation process
— — — — — — — — — — — — — — —
Page 53
AI in ZEN and ZEN core imaging and analysis platform 51and accurately quantify gene expression at
the single-cell level, advanced Deep Learning
techniques are required. For example, when
cells are confluent or even overlapping,
instance segmentation approaches designed to
segment touching or overlapping objects are
necessary.
Figure 11a depicts the Gene Expression Bio
App interface within the ZEN software. The
cells displayed in the figure were imaged using
a ZEISS Celldiscoverer 7 microscope, employing
oblique contrast imaging to enhance cellular
morphology and facilitate better segmentation.
The channel corresponding to mCherry
fluorescence is colored pink and displayed
alongside the cell channel, as shown in the top
right corner of Figure 11a . A Deep Learning
model for instance segmentation, trained on
the ZEISS arivis Cloud platform, was imported
into the “Gene- and Protein Expression”
module in ZEN Bio Apps to perform automated
cellular segmentation.
This automated application segments the
image to identify individual cells, calculates the
mCherry fluorescence intensity within each
segmented cell, and classifies cells as positive
or negative based on a predefined intensity
threshold. The bottom right corner of Figure
11a shows the segmented cells, with mCherry-
positive cells colored in green, negative cells in
Figure 11: Gene Expression Bio App in ZEN. (a) The setup of the Gene- and Protein Expression Bio App within the ZEN
interface. An instance segmentation model trained on ZEISS arivis Cloud is used for the segmentation of cells in the oblique
channel. Following cell segmentation, mCherry-positive cells are identified to evaluate the expression rate. (b) The result
of analyzing a multiwell plate using the Gene- and Protein Expression Bio App. It presents the percentage of positive cells
per well at the current time-point of the time series, offering insights into gene expression dynamics.aluminum Barker
etched sample. This segmentation process enables the extraction of the size distribution of individual grains, facilitating
comprehensive analysis.
white, and cell boundaries and background in
gray. This visual representation allows users to
easily distinguish between cells expressing the
gene of interest (positive) and those without
detectable expression (negative).
Figure 11b extends the analysis to a multiwell
plate, providing insights into transfection
efficiency. A heat map in the top right image
visualizes transfection efficiency across wells,
while a detailed table in the bottom right
summarizes analytical information from the
multiwell timeseries dataset.
This application showcases the power of
AI-driven automation in cellular analysis. It
leverages the Gene- and Protein Expression
Bio App and Deep Learning models trained
on the ZEISS arivis Cloud platform for efficient
processing of multiwell datasets across
various imaging modalities and experimental
conditions.
Integration of AI into guided acquisition
workflows
Biological imaging often involves multi-step
procedures, especially when identifying
and examining rare events or ROIs at
high resolution. For instance, to capture
multichannel fluorescence images of rare
events for further analysis, users must first
identify the specific ROIs and then zoom in
— — — — — — — — — — — — — — —
Page 54
AI in ZEN and ZEN core imaging and analysis platform 52
Figure 12: Workflow for guided acquisition in ZEN.
The diagram illustrates the guided acquisition process,
starting with an overview scan to capture a large area for
high-throughput imaging. Image analysis assisted by AI is
performed to identify specific ROI for detailed acquisition.
Finally, high-resolution multi-dimensional images are
acquired, facilitating comprehensive characterization of
the identified ROIs.to capture high-resolution images, possibly
under various illumination conditions. Another
example is when users need to sample a
predefined number of objects for statistical
purposes, such as selecting a specific number
of random organoids in each well of a
multiwell plate for further imaging.
Historically, manual ROI identification relied on
researcher expertise and was time-intensive,
susceptible to human error, and inefficient,
wasting valuable researcher time in searching
for rare events or sampling a statistically
relevant number of objects for analysis.
Simplified ROI identification with guided
acquisition in ZEN
ZEN addresses this challenge by enabling
automated guided acquisition workflows
(see Figure 12 ). In addition to conventional
segmentation methods, ZEN can also leverage
trained AI models to detect rare events or
other ROIs during an initial overview scan. The
coordinates of these identified ROIs are then
used to automatically guide the microscope
to image those specific regions at higher
resolution and under pre-defined experimental
conditions, enabling efficient multidimensional
image acquisition. This automated guided
acquisition approach streamlines the imaging
process, minimizes human error, and optimizes
the use of valuable microscope time.
The power of guided acquisition in ZEN is
exemplified in the imaging of mouse Lgr5+ gut
organoids mounted in a 3D matrix (Matrigel).
As shown in Figure 13a, the initial low-
magnification overview scan of a single well
from a 24-well plate reveals multiple organoids.
Individual organoids are precisely identified
and segmented using a simple thresholding
method, leveraging the contrast difference
between the organoids and the background.
Considering these objects are easy to segment,
this approach demonstrates that Deep
Learning is not required for segmentation.
However, in scenarios where organoids are clustered together or situated in the shadows
of the wells near the edges, a Deep Learning-
based approach may be required for accurate
segmentation.
With the coordinates of these target
organoids located, ZEN automatically
guides the microscope to acquire detailed,
high-resolution z-stack images of only the
identified organoids, capturing multi-channel
fluorescence information. Figures 13b and (c)
show 2D sections of these high-resolution 3D
scans, highlighting nuclei (blue) and E-cadherin
(green), respectively. Figure 13d is a composite
image combining both channels. This targeted
imaging approach ensures efficient use of
microscope time while enabling comprehensive
multi-dimensional characterization of the
organoids of interest within a complex 3D
culture system.
— — — — — — — — — — — — — — —
Page 55
AI in ZEN and ZEN core imaging and analysis platform 53Figure 13: Guided acquisition of mouse Lgr5+ gut organoids in ZEN. (a) The initial low-magnifi cation overview scan of
a single well from a 24-well plate, revealing multiple organoids. The three images on the right display high-resolution
two-dimensional (2D) sections of a select organoid from panel (a), highlighting nuclei (blue) in panel (b), E-cadherin (green)
in panel (c), and both channels combined in panel (d). The multi-dimensional characterization of organoids within a
complex 3D system is showcased. The organoids were mounted in a 3D matrix (Matrigel) and imaged on a Celldiscoverer
7, Sample courtesy of Dr. M. Lutolf, EPFL, Switzerland.
Conclusion
The integration of AI into ZEN and ZEN core has
ushered in a new era of AI-assisted microscopy,
empowering users with unprecedented speed,
effi ciency, and accuracy in image analysis. From
segmentation and classifi cation to denoising
and guided acquisition, AI-driven solutions
have revolutionized the way users approach
microscopy workfl ows within these platforms.As integral components of the ZEISS software
ecosystem, ZEN and ZEN core seamlessly
interface with the ZEISS arivis suite of
software for scalable image analysis. This
software ecosystem empowers users with the
combined power of AI, facilitating automated
image acquisition and the analysis of large
multidimensional datasets.
— — — — — — — — — — — — — — —
Page 56
AI in ZEN and ZEN core imaging and analysis platform 54References
1. Pypi. czmodel. URL: https://pypi.org/project/czmodel/ (accessed 06 April 2024).
2. Buades A, Coll B, Morel JM. A review of image denoising algorithms, with a new one.
Multiscale Model Simul. (2005) 4:490–530. doi: 10.1137/040616024.
3. Buades A, Coll B, Morel JM. Nonlocal image and movie denoising. Int J Comput Vis. (2008)
76:123–139. doi: 10.1007/s11263-007-0052-1.
4. Kostadin D, Alessandro F, Vladimir K, Karen E. Image denoising by sparse 3D transform-
domain collaborative filtering. IEEE Trans Image Process. (2017) 16(8):2080–2095. doi: 10.1109/
TIP.2007.901238.
5. Krull A, Buchholz T-O, Jug F. Noise2Void - Learning Denoising from Single Noisy Images. (2018)
arXiv:1811.10980. doi: 10.48550/arXiv.1811.10980.
6. Höck E, Buchholz T-O, Brachmann A, Jug F, and Freytag A. N2V2 - Fixing Noise2Void
Checkerboard Artifacts with Modified Sampling Strategies and a Tweaked Network Architecture.
(2022). URL: https://openreview.net/forum?id=IZfQYb4lHVq (accessed 06 April 2024).
7. GitHub. Juglab/n2v. URL: https://github.com/juglab/n2v?tab=readme-ov-file (accessed 06 April
2024).
8. Shaner NC, Campbell RE, Steinbach PA, Giepmans BN, Palmer AE, Tsien RY. Improved
monomeric red, orange and yellow fluorescent proteins derived from Discosoma sp. red
fluorescent protein. Nat Biotechnol . (2004) 12 :1567–1572. doi: 10.1038/nbt1037.
9. Ransom EM, Ellermeier CD, Weiss DS. Use of mCherry Red Fluorescent Protein for Studies
of Protein Localization and Gene Expression in Clostridium difficile. (2015) 5 :1652—1660. doi:
10.1128/AEM.03446-14.
— — — — — — — — — — — — — — —
Page 57
AI in ZEN and ZEN core imaging and analysis platform 55
— — — — — — — — — — — — — — —
Page 58
AI for routine image analysis using ZEISS Labscope 56AI for routine image analysis using ZEISS Labscope
Life science encompasses diverse disciplines—
from systematic zoology to human anatomy
and protein interactions at the molecular
level. Equally diverse is the application of
microscopy in these branches of science.
Microscopes are capable of much more than
resolving smaller and smaller structures. The
microscope is perhaps the best multitool in the
laboratory, with uses in medical diagnostics,
biotechnology, and the pharmaceutical sector.
Analysis and monitoring are two critical
applications of microscopes. For example,
tissue and blood samples are routinely analyzed
for atypical cells and cell morphologies, and
eukaryotic cells in cell cultures are checked for
their health and physiological behavior (see
Figure 1 ). Furthermore, these applications are
routine and repetitive, and the resulting images
can answer crucial questions, such as:
■Are my cells healthy?
■Is there a detectable pathogen?
■Was the gene successfully inserted into my
cells?
Figure 1: Cell cultures need regular monitoring to check their health and behavior.While reliability and reproducibility are
always critical, time is also important because
microscopy experiments can produce a lot of
data, all of which needs to be analyzed with
care and validity.
The potential role of AI tools in routine
image analysis
AI tools can assist with repetitive and time-
consuming microscopy tasks to save time and
eliminate human error (see Figure 2 ).
Artificial neural networks can identify
processes, patterns, and states in organisms,
tissues, and cells that humans may find difficult
to detect even with advanced microscopy
techniques.
These AI tools can also link vast amounts of
data and learn from accumulated experience
to refine specified processes. Manual work that
may have taken hours, days, or weeks can now
be performed automatically with ease, and
results are delivered in real time. Plus, the ability
of AI to detect and analyze properties that
would be difficult for humans to detect enables
the fascinating prospect of revolutionary
discoveries.
— — — — — — — — — — — — — — —
Page 59
AI for routine image analysis using ZEISS Labscope 57Like the human brain, AI algorithms constantly
learn and improve. Features are detected,
interpreted, and compared, and decisions
and predictions are made. The accuracy of
predictions and decisions improves with larger
datasets, and with every new input or inquiry,
the network learns to adapt to new structures.
Overcoming limitations of AI tools
While AI tools for lab applications are
sophisticated, their wider use may be limited
because they can be difficult to adapt to new
applications, require enormous amounts of
computing power, or require advanced IT skills.
Ideally, AI tools should be accessible to as many
people as possible, adaptable to different areas
of interest, and work on inexpensive hardware.
The AI modules for the ZEISS Labscope imaging
app offer these advantages and assist with
performing time-consuming yet important lab
tasks.
Figure 2: Counting cells and determining their confluency manually can become cumbersome.
“While AI tools for lab applications are
sophisticated, their wider use may be
limited.”By combining Deep Learning methods with
large training datasets, the modules can adapt
to various cell types and morphologies on
which they were not initially trained and can
handle images of varying quality.
The versatility and the ability to collect reliable
and reproducible data with minimal input and
expertise required from the user make the
Labscope AI modules from ZEISS an essential
product for microscopists in life science,
medicine, and biotechnology.
The role of AI tools for determining cell
confluency
Cell confluency refers to the extent to which
a layer of cells in a culture dish or flask has
grown and spread to cover the surface area. It
describes how densely packed the cells are and
is typically expressed as a percentage of the
total surface area covered by cells.
In general, cells are seeded into a culture dish
or flask at a low density and allowed to grow
until they reach a desired level of confluency
(see Figure 3 ). At low confluency, cells are
often actively dividing and may be used for
experiments that require actively proliferating
— — — — — — — — — — — — — — —
Page 60
AI for routine image analysis using ZEISS Labscope 58
Figure 3: Cells can be seeded in Petri dishes, flasks or even cell factories.cells. At higher confluency, cells may become
more quiescent and may exhibit different
behaviors or responses to stimuli.
Cell confluency is a fundamental parameter
in cell culture experiments, as it can impact
cell behavior and experimental outcomes.
Monitoring cell confluency is routine for every
cell culture, as it determines when cultures
need to be transferred to a new cell culture
vessel. This step may dictate whether an
experiment can be carried out or not and thus
has a significant impact on the laboratory
workflow.
Challenges of measuring cell confluency
Traditionally, cell confluency is assessed by
looking at the layer of cells under a microscope
and estimating the degree of surface area
coverage. However, relying on individual
estimates of cell confluency has several
disadvantages in cell culture experiments.
These include:
■Lack of reproducibility.
■Inaccuracy.
■Lack of standardization between
laboratories.
These issues can be caused and exacerbated
by different individuals making confluency measurements, and variability in how the cells
were seeded.
AI tools can improve reliability
and reproducibility of confluency
measurements
AI tools like ZEISS Labscope AI Cell Confluency
address these issues, enabling reproducible
and accurate measurements with the click of a
button.
The AI-trained algorithm recognizes cells in
culture vessels based on transmitted light
microscopy images, regardless of cell type and
magnification of the image, and provides a
specific value for confluency in the respective
frame. The algorithm also provides an average
of all acquired data points in the culture vessel
(see Figure 4 ). Also, users can retrospectively
analyze already stored image data for
confluency.
“The AI-trained algorithm recognizes
cells in culture vessels based on
transmitted light microscopy
images, regardless of cell type
and magnification of the image.”
— — — — — — — — — — — — — — —
Page 61
AI for routine image analysis using ZEISS Labscope 59
Figure 4: Screenshot showing ZEISS Labscope AI Cell Confluency measurement for HeLa cells. The module shows the
confluency for the current field of view (55%) and the average of the already acquired field of views (55%).The ability to examine any number of sections
of the culture vessel enables a statistical
determination of cell density. Furthermore, the
accumulated confluence data can be easily
exported and further analyzed in statistical
analysis software.
Given these advantages, the Labscope AI Cell
Confluency module significantly enhances
the efficiency and accuracy of cell confluency
measurements, ultimately improving the
reliability of experimental outcomes.
How AI can help with cell counting
Cell counting is another essential task in
cell biology laboratories, enabling the
determination of the number of cells in a
culture vessel or experiment setup. This
information is crucial for planning experiments
and ensuring the available number of cells is
sufficient.
Challenges associated with traditional
cell counting
The traditional method for cell counting
is to detach cells from the surface of the
culture vessel using trypsin, transfer them to a counting chamber, and count them using
phase contrast microscopy and a manual hand
counter.
However, manual cell counting is a time-
consuming and labor-intensive process,
especially when large numbers of samples
need to be counted. This can slow research
progress and increase the likelihood of errors
due to fatigue. It also relies on the observer’s
ability to visually distinguish between cells
and debris, and to accurately count the cells
in each grid, which can introduce significant
subjectivity into the results, as different
observers may count cells differently.
In addition, manually counting cells can
increase the risk of contamination and
impact cell viability. The results can be hard
to reproduce since they differ across different
observers, labs, and experiments. In cases
when there are not enough cells for an
experiment after manual counting, valuable
time is lost both by the measurement itself and
while the cells settle down and reattach to the
culture vessel so they can continue to grow.
— — — — — — — — — — — — — — —
Page 62
AI for routine image analysis using ZEISS Labscope 60
Figure 5: ZEISS Axiovert 5 digital is an all-in-one cell imaging system based on AI.
Learn more about microscopy solutions
for cell culture
Using cell contrast in current times.
www.zeiss.com/microscopy/cell-cultureAI tools can help simplify cell counting
The AI Cell Counting module for Labscope
overcomes these challenges by recognizing
and counting cells in a fi eld of view at the
touch of a button. The AI algorithm can detect
and diff erentiate cells regardless of their type
or morphology. Moreover, the algorithm’s
reliability and reproducibility provide consistent
and accurate results.
Like the Cell Confl uency module, users can
process and analyze existing images. In
addition to the number for the cell count,
a graphical representation of the detection
process allows users to check the algorithm’s
functionality at any time. Results can be
exported in common fi le formats for further
processing in statistical tools such as Microsoft
Excel.
The benefi ts of AI in routine image
analysis
Using AI in daily laboratory work promises
to optimize routine workfl ows and improve
productivity. AI combined with microscopy will
Learn more about Labscope
Easy-to-use imaging app for connected
microscopes, share your discoveries.
www.zeiss.com/labscopecontinue to be one of the game changers in
everyday laboratory life. Routine microscopes
like ZEISS Axiovert 5 digital, are already
compatible with the AI modules for Labscope
and off er all the advantages of automatic
cell counting and automatic confl uency
measurement (see Figure 5 ). While the human
factor remains essential in ensuring the
accuracy and reliability of results, AI enriches
microscopy examinations with tools for
reducing errors and providing greater effi ciency
by eliminating the need to perform repetitive
and time-consuming tasks.
— — — — — — — — — — — — — — —
Page 63
AI for routine image analysis using ZEISS Labscope 61
— — — — — — — — — — — — — — —
Page 64
AI for X-ray microscopy with Deep Learning-based reconstruction 62Traditionally, microscopy studies aimed
at examining the volumetric structure of
samples have relied on two-dimensional (2D)
slice-by-slice imaging using light or electron
microscopy, followed by the reconstruction of
the three-dimensional (3D) volume through
the registration of individual 2D slices. This 2D
slice-by-slice approach comes with significant
challenges, notably the risk of damaging
delicate structures or altering sensitive features
due to mechanical sectioning. Moreover, it
may introduce mechanical cutting or surface
ablation artifacts, expose internal structures to
the atmosphere, and cause damage through
physical cutting tools, FIB-SEM, or laser
exposure.
Drawbacks of generating 3D
reconstructions from 2D sample sections
Relying solely on 2D images to infer 3D
conclusions has proven problematic. Although
stereography has provided quantifiable
results in ideal conditions, research indicates
that extrapolating 2D images to 3D metrics
can be highly inaccurate, particularly for
heterogeneous or anisotropic real-world
materials. To overcome these limitations,
novel techniques for 3D characterization have
emerged, including the extension of optical
and electron microscopy to 2D-based serial
sectioning microanalysis [1].
Despite their potential, these methods
involve the repetitive slicing of samples while
capturing 2D surface images, which are
then used for 3D reconstruction. Although
this approach brought researchers closer to
achieving comprehensive 3D characterization,
its dependence on slicing frequently results in
restricted depth resolution, voxel shapes that
deviate significantly from cubes, and persistent
issues related to damage caused by 2D interior
sectioning. Ultimately, this method consumes
the sample during the imaging process, AI for X-ray microscopy with Deep Learning-based
reconstruction
eliminating the possibility of subsequent
re-imaging for four-dimensional (4D) studies
(3D imaging over time) or conducting multi-
length scale analyses using alternative imaging
modalities.
High-resolution 3D X-ray microscopes (XRM)
provide a solution to these challenges by
facilitating non-destructive 3D imaging at
comparable length scales [2]. The deep
penetration of X-rays eliminates or significantly
reduces the necessity for extensive sample
preparation. Additionally, full X-ray tomography
avoids altering the sample, which remains
unaffected by mechanical sectioning artifacts
and avoids non-cubic voxels. Consequently,
this approach offers superior visualization and
quantification of 3D microstructures.
X-ray microCT: A versatile tool for non-
destructive 3D characterization across
scientific domains
X-ray microCT (micro-computed tomography)
is a non-destructive imaging technique that
uses X-rays to generate 3D representations of
internal structures within objects at the micron
scale. This method is based on the principles of
computed tomography (like medical CT scans,
but with significantly higher spatial resolution).
Achieving these enhanced resolutions
necessitates fundamentally different instrument
architecture: the detector and X-ray source
remain fixed while the sample undergoes
rotation. In contrast, medical CT instruments
require stationary patients for obvious reasons,
with synchronized rotations of both the source
and detector.
The basics of X-ray microCT and its
applications
In X-ray microCT, the object under examination
is positioned in the path of an X-ray beam and
a sequence of X-ray projections is captured
from multiple angles around the object. These
— — — — — — — — — — — — — — —
Page 65
AI for X-ray microscopy with Deep Learning-based reconstruction 63projections are then used to reconstruct a 3D
image of the internal structure of the object.
This process allows the non-destructive
visualization of internal features, including
pores, cracks, and other details.
X-ray microCT has many applications across
diverse scientific and industrial domains,
spanning materials science, biology, geology,
and paleontology. It enables researchers to
explore the internal structure of samples
without the need for physical sectioning
to provide invaluable insights into their
microstructure. These applications are
demonstrated in 3D renderings of various
samples (see Figure 1 ).
How XRM surpasses traditional microCT
by using dual-stage magnification
Most microCT instruments rely on large
pixel (~100 μm) flat panel detectors and
primarily use small spot size and geometric
magnification (larger apparent size of an object
when it’s closer to the source) to achieve high
resolution. However, this approach results in a
rapid deterioration of resolution as the working
distance (the distance between the detector
and the sample) increases, which can be
problematic for large samples.
In contrast, XRM architecture integrates a
patented detector system rooted in ZEISS’
synchrotron heritage. This system features
small pixels (<0.5 µm) facilitated by scintillators
coupled with visible light optics. The optical
magnification within the detector diminishes
Figure 1: Diverse applications of X-ray microCT demonstrated using 3D renderings of samples from different fields. (a)
Materials science (21700 battery). (b) Geology (meteorite). (c) Life science (pig eye). (d) Electronics (camera module of a
smartphone).
the dependence on geometric magnification,
thus maintaining high resolution (small voxels)
even at long working distances. Consequently,
large samples of approximately 100 mm in size
or samples contained within in situ devices can
be imaged at submicron resolution.
Advantages of XRM
There are significant advantages of XRM over
microCT, including enhanced contrast and
higher resolution when imaging large samples
and conducting in situ studies, preserving the
physiological or environmental context of the
sample being studied. As illustrated in Figure 2 ,
the dual-stage magnification of XRM eliminates
the need for sample destruction to achieve
high-resolution imaging on large samples.
Unlike microCT, where samples must be cut to
bring the region of interest as close to the X-ray
source as possible for higher magnification,
XRM uses a combination of geometric and
optical magnifications to achieve the same
resolution without damaging the sample.
Advancements in CT reconstruction:
Harnessing Deep Learning for
enhanced imaging
The traditional method for reconstructing a 3D
volume from a series of sequentially acquired
2D X-ray projections is known as “filtered back
projection” in cone beam CT geometry and is
commonly referred to as FDK reconstruction
[3]. This technique involves weighting and
filtering projections before distributing them
across the image volume along their projection
directions.
— — — — — — — — — — — — — — —
Page 66
AI for X-ray microscopy with Deep Learning-based reconstruction 64Figure 2: Comparison of imaging techniques demonstrated using an example of non-destructive imaging of apple
seeds withing the fruit. (a) Traditional microCT imaging requires the extraction of an apple seed for high-resolution
imaging, where the seed is positioned close to the X-ray source for optimal magnification. (b) Because of the dual-stage
magnification in XRM, the full apple is imaged non-destructively. The image of the seed is first geometrically magnified on
a scintillator and further magnified using ZEISS proprietary optics before being detected by a CCD detector. This enables
high-resolution imaging without sample destruction.
The challenges of generating accurate
3D CT reconstructions
Achieving an accurate representation of the
3D volume of the sample necessitates a large
number of projections (ideally thousands).
However, this technique relies on the
assumption that the total projection dataset
contains sufficient projections spaced at small
angular intervals (i.e., that the data is “well
sampled”) and is free of significant noise. In
practice, to increase throughput and reduce
total tomography acquisition time, the total
projection dataset is often not well sampled,
leading to errors in the reconstructed image.
This challenge is particularly pronounced in
in situ experiments requiring higher temporal
resolution or industrial applications where the
effective cost per sample must be minimized.
Such errors can result in inaccuracies in
segmentation and any subsequent analysis
derived from the data.
Deep Learning overcomes challenges in
3D CT reconstruction
Deep Learning-based algorithms offer
promising solutions to the challenges
encountered in CT reconstruction, with
the potential to enhance image quality and
decrease throughput time for high-resolution
3D X-ray microscopes [4]. This innovative approach involves using trained neural
networks positioned between the X-ray
projections and the final reconstructed volume.
Deep Learning-based CT reconstruction
techniques can effectively reduce
noise in 3D XRM data and mitigate CT
reconstruction artifacts, such as aliasing
artifacts (shadow bands, dark streaks, or
noise-like distortions), which may arise when
insufficient X-ray projection data is available.
While Machine Learning applications in the
field have predominantly concentrated on
post-reconstruction tasks such as image
segmentation, feature classification, and
object recognition, the integration of Deep
Learning-based techniques within the complex
workflow of 3D XRM has only recently begun
to be extensively explored.
Enhancing 3D CT reconstruction with
ZEISS DeepRecon Pro
A Deep Learning-based reconstruction
workflow developed by ZEISS, known as
ZEISS DeepRecon Pro, greatly assists the CT
reconstruction phase of XRM measurement. It
is part of the Advanced Reconstruction Toolbox
(ART), which offers image reconstruction
technologies on ZEISS X-ray microscopes to
enhance X-ray system performance.
— — — — — — — — — — — — — — —
Page 67
AI for X-ray microscopy with Deep Learning-based reconstruction 65
Figure 3: Integrating a pre-trained neural network between 2D X-ray projections (radiographic data) and 3D CT
reconstructed volume.This Deep Learning-based reconstruction
workfl ow features a user-friendly software
interface that minimizes user input, requiring
only the specifi cation of the desired application
result, such as improved image quality or
reduced throughput time. ZEISS DeepRecon
Pro employs trained convolutional neural
networks positioned between the X-ray
projections and the fi nal reconstructed volume
(see Figure 3 ). This streamlined workfl ow
enables XRM image processing, interpretation,
and retrieval using an on-demand trainable
neural network. Consequently, high-quality
reconstructed data can be obtained even with
a reduced number of projections (Np).
ZEISS DeepRecon Pro uses ZEISS proprietary
cost functions and training protocols to
generate image reconstructions from datasets
obtained with a low Np as the training
input [4]. This is achieved by using an FDK-
reconstructed image produced with a large Np
as the reference ground truth training target
data. The Deep Learning network training is
customized to specifi ed XRM data acquisition
settings and a particular sample class, defi ned
as a group of samples with similar X-ray
attenuation, and scan recipe parameters.
Once trained, the network can eff ectively
process datasets belonging to the same sample
class. If there are diff erences in the sample
class or modifi cations in the XRM acquisition
parameters, retraining of the network is
necessary.Training a Deep Learning network with
ZEISS DeepRecon Pro doesn’t require prior
knowledge of the sample type, meaning
users can create custom networks for various
applications without Machine Learning
expertise. This automated training scheme is
seamlessly integrated into a software interface,
off ering users a selection of options through an
intuitive drop-down menu.
Comparing FDK and ZEISS DeepRecon
Pro 3D reconstructions
Figure 4 provides a compelling illustration of
the benefi ts off ered by Deep Learning-based
reconstruction methods. The fi gure compares
the reconstruction of a 21700 lithium-ion
battery using both traditional FDK and ZEISS
DeepRecon Pro.
The 2D section shown in Figure 4a was
reconstructed using the FDK algorithm from
a dataset comprising 3,200 projections
acquired over 11 hours. This extensive
projection dataset is typically required to
capture the necessary details when using
standard FDK reconstruction. Figure 4b shows
the same region reconstructed using FDK,
but from a signifi cantly reduced number of
projections, with only 400 collected over
84 minutes. This dramatic reduction in the
number of projections results in various
artifacts, particularly evident in the region
highlighted by the red ellipse. However,
when the same 400-projection dataset was
— — — — — — — — — — — — — — —
Page 68
AI for X-ray microscopy with Deep Learning-based reconstruction 66Figure 4: Comparison of FDK and ZEISS DeepRecon Pro reconstruction techniques for a 21700 lithium-ion battery sample.
(a) 2D section from a volume reconstructed using FDK from a dataset of 3,200 projections acquired over 11 hours. (b) 2D
section from a volume reconstructed using FDK from a reduced dataset of only 400 projections collected over 84 minutes,
exhibiting various artifacts, particularly in the region highlighted by the red ellipse. (c) 2D section from a 3D volume
reconstructed using the ZEISS DeepRecon Pro Deep Learning-based approach from the same 400-projection dataset,
demonstrating a clean, artifact-free image comparable to the high-quality FDK reconstruction in (a) despite the 8-fold
reduction in acquisition time and Np.
reconstructed using the ZEISS DeepRecon Pro
Deep Learning-based algorithm, the resulting
image (see Figure 4c ) is clean, artifact-free,
and comparable to the high-quality FDK
reconstruction from the comprehensive
3,200-projection dataset.
This remarkable 8-fold improvement in
throughput without compromising image
quality underscores the practical benefits of
the ZEISS DeepRecon Pro Deep Learning-based
reconstruction. The next section provides
additional examples further illustrating the
advantages of this Deep Learning-powered
technique.
Demonstrating the impact of Deep
Learning with example applications
Improving graphite contrast in battery
materials
Battery analysis represents a compelling
application for X-ray microscopy due to the
sealed nature of these devices. Batteries are
complex systems consisting of not just a single
material, but rather a functional composite of
multiple materials arranged precisely, as shown
in Figure 1a .
Battery analysis encompasses a wide range of
tasks, including inspection and measurement,
defect inspection, material evaluation, in
situ monitoring of cycling behaviors, and high-resolution imaging to provide input for
performance models. AI-based reconstruction
algorithms such as ZEISS DeepRecon Pro can
significantly enhance the value of these tasks.
Beyond inspection tasks, researchers often
seek to integrate the results of 3D imaging
experiments into computer simulation
packages to model the performance of various
microstructural and chemical arrangements in
batteries. Achieving the best possible image
quality is essential for accurately segmenting
different phases and generating suitable inputs
for these models. For instance, in lithium-
ion pouch cell batteries, obtaining good
contrast within the graphite anode region
can be challenging due to its low density
and immersion in a liquid electrolyte. ZEISS
DeepRecon Pro offers capabilities that surpass
those of standard reconstruction techniques,
particularly in applications of this nature.
Figure 5 presents a comparison of FDK and
ZEISS DeepRecon Pro reconstructed images
collected from a cell imaged for 24 hours on
the ZEISS Versa XRM at high magnification.
Figure 5a depicts a 2D section from the
volume reconstructed using standard FDK
reconstruction, whereas Figure 5b image
shows the same section from a volume
reconstructed using ZEISS DeepRecon Pro.
While Figure 5a (FDK) exhibits excellent
contrast between the graphite anode and
— — — — — — — — — — — — — — —
Page 69
AI for X-ray microscopy with Deep Learning-based reconstruction 67Figure 5: Comparison of reconstruction techniques
in a lithium-ion pouch cell battery. (a) 2D section
from a volume reconstructed using standard FDK
from a dataset acquired over 24 hours showing
good contrast but lacking detail within the anode
region. (b) The same section from a volume
reconstructed using ZEISS DeepRecon Pro from
the same dataset acquired over 24 hours. This
ZEISS DeepRecon Pro reconstruction demonstrates
improved visualization of fine details in the anode
structure allowing more accurate segmentation.
Note the contrast has been enhanced in both
(a) and (b) for better visualization of the darker
graphite regions. (c) 2D section from a volume
reconstructed using FDK from a quarter of the
projections of the original 24-hour dataset,
simulating a 6-hour acquisition. The data quality
is notably degraded compared to the 24-hour
dataset, with increased noise evident in the
image inset. (d) The same section from a volume
reconstructed using ZEISS DeepRecon Pro from the
simulated 6-hour dataset, demonstrating a 4-fold
improvement in quality without compromising
image information, as evidenced by the clean inset
image.
other cell components, it lacks the fine detail
within the anode region (dark gray) necessary
for accurate segmentation.
Conversely, Figure 5b (ZEISS DeepRecon
Pro) clearly depicts fine details in the anode
structure, facilitating improved segmentation
of these regions [5]. Note that contrast has
been enhanced in both panel (a) and (b) for
better visualization of the darker graphite
regions (see Figure 5 ). By employing ZEISS
DeepRecon Pro, much of the noise present in
standard FDK reconstruction can be eliminated
while preserving the features and sharpness
required for visualizing structures within the
sample. This capability enables researchers to
segment the anode layer microstructure more
easily and provides more accurate inputs for
modeling and expediting research objectives.
To further explore the benefits of ZEISS
DeepRecon Pro, a quarter of the projections
from the 24-hour dataset depicted in Figure 5a
and Figure 5b were used to simulate a 6-hour
acquisition and reconstructed using FDK and
ZEISS DeepRecon Pro, respectively. Figure
5c illustrates a 2D section from the volume
reconstructed using the FDK algorithm, where the quality is notably impacted compared
to the 24-hour dataset. This degradation is
particularly evident in the noisy inset image,
which displays a zoomed-in region from the 2D
slice. Conversely, Figure 5d shows the same 2D
section, reconstructed using ZEISS DeepRecon
Pro. The clean inset image demonstrates a
remarkable 4-fold improvement in quality
achievable with ZEISS DeepRecon Pro without
compromising the information contained in the
images.
Enhancing Inconel imaging in additive
manufacturing
Inconel, a nickel-based superalloy, has
emerged as a workhorse material for additive
manufacturing (AM) applications. Inconel has
unique properties, including high strength,
crack and corrosion resistance, and excellent
performance under harsh conditions, that
make it a popular choice for a wide range of
AM parts. In recent years, non-destructive
tomography techniques like microCT and
X-ray microscopy have become established
methods for testing and analyzing additively
manufactured Inconel components. These
advanced imaging techniques have proven
especially useful and accurate for dimensional
— — — — — — — — — — — — — — —
Page 70
AI for X-ray microscopy with Deep Learning-based reconstruction 68Figure 6: Comparison of FDK and ZEISS DeepRecon Pro reconstruction techniques for high-resolution imaging of an
Inconel alloy sample. (a) FDK reconstruction from 1601 projections, representing an optimal scanning recipe with longer
exposure times. (b) FDK reconstruction from only 401 projections, showing a significant decline in image quality and
the obscuring of smaller voids. (c) ZEISS DeepRecon Pro reconstruction from the 1601-projection dataset, delivering the
cleanest image with the best signal-to-noise ratio. (d) ZEISS DeepRecon Pro reconstruction from the 401-projection dataset,
maintaining the same level of detail as in panel (c), despite a 4-fold reduction in acquisition time.
measurement and porosity analysis of AM
parts. High-resolution scanning is often
required for these applications to detect tiny
defects and pores within the internal structures
of Inconel AM parts.
Dense metal samples, such as Inconel, can
pose significant challenges for high-resolution
interior tomography scans. Dense materials
often require extremely long exposure
times to achieve acceptable noise levels
in the reconstructed images. Figure 6
shows a comparison of Inconel alloy scans
reconstructed using both standard FDK
algorithms and the Deep Learning-based ZEISS
DeepRecon Pro approach.
The FDK-reconstructed slice from 1601
projections (see Figure 6a ) demonstrates
the image quality that can be achieved with
an optimal scanning recipe that consists of
longer scans. However, reducing the number
of projections to 401 results in a noticeable
decline in quality, where smaller voids become
obscured, as seen in Figure 6b .
In contrast, the ZEISS DeepRecon Pro-
reconstructed slices maintain exceptional image
quality, with the 1601-projection dataset in
Figure 6c showing the cleanest image with the
best signal-to-noise ratio. The 401-projection
ZEISS DeepRecon Pro reconstruction in Figure
6d captures the same level of detail as the 1601-projection ZEISS DeepRecon Pro result,
despite the 4-fold reduction in acquisition time.
This highlights the powerful capabilities of the
Deep Learning-based reconstruction, which
can deliver high-quality images without the
need for long scanning times.
Advancing PCB inspection with XRM and
Deep Learning reconstruction
The relentless push for miniaturization in the
semiconductor industry has introduced new
quality control challenges. X-ray microCT
has become a widely adopted technique to
quickly identify design issues, discrepancies,
and internal defects within printed circuit
boards (PCBs). The need for even higher image
resolution to detect smaller defects in large
PCB samples is addressed by the two-stage
magnification capabilities of XRM systems.
Until recently, the sensitivity of classic
scintillator materials to high-energy X-rays
has limited the application of XRM for PCB
inspection. The introduction of the “resolution
performance” feature in the ZEISS Xradia 630
Versa XRM system has been a game-changer,
enabling high-resolution imaging at the high
X-ray energies required to penetrate large PCB
samples. While this technological advancement
has significantly expanded the usefulness of
XRM for PCB analysis, long acquisition times
are often still necessary, and high noise levels
can obscure small defects. Deep Learning-
— — — — — — — — — — — — — — —
Page 71
AI for X-ray microscopy with Deep Learning-based reconstruction 69based reconstruction using ZEISS DeepRecon
Pro can generate higher-quality, lower-noise
images in shorter scanning times.
The value of XRM paired with advanced
reconstruction techniques like ZEISS
DeepRecon Pro is exemplified in the analysis
of PCBs. Figure 7 demonstrates a multi-scale
imaging workflow applied to a PCB sample,
highlighting the benefits of the ZEISS
DeepRecon Pro approach.
Figure 7a shows a low-magnification (12 μm
voxel) overview image capturing the full field
of view of the PCB sample. To further inspect
a specific region of interest, a high-resolution
(0.4 μm voxel) scan was performed targeting
the solder bump highlighted in Figure 7a .
The 2D slice from the high-resolution FDK
reconstruction reveals a noisy image, where
some of the larger cracks within the solder
bump are visible (see Figure 7b ). While this image provides good overall detail, the defects
and cracks present within the solder bump are
not clearly discernible. In contrast, the 2D slice
from the ZEISS DeepRecon Pro-reconstructed
volume reveals the critical solder bump
defects much more clearly (see Figure 7c ).
This highlights the importance of the Deep
Learning-based reconstruction for applications
requiring the detection of smaller, more
subtle internal features within complex PCB
structures.
Conclusion
The increasing complexity of X-ray
tomographic microscopy experiments has
made advanced image processing algorithms
an essential component of achieving accurate
and high-quality results. Traditionally, there has
been a trade-off between image quality and
experimental throughput that needed to be
carefully balanced. However, Deep Learning,
specifically convolutional neural networks,
Figure 7: Multi-scale XRM and Deep Learning-based reconstruction for printed circuit board (PCB) analysis. (a)
Low-magnification (12 μm voxel) overview image of the PCB sample, with a region of interest (solder bump) highlighted. (b)
2D slice from the high-resolution (0.4 μm voxel) FDK reconstruction of the solder bump region, where defects and cracks
are not clearly visible. (c) 2D slice from the high-resolution volume reconstructed using the ZEISS DeepRecon Pro Deep
Learning-based approach, revealing the critical solder bump defects much more clearly. The ZEISS DeepRecon Pro method
demonstrates the ability to detect subtle internal features within complex PCB structures that are obscured in standard FDK
reconstructions.
— — — — — — — — — — — — — — —
Page 72
AI for X-ray microscopy with Deep Learning-based reconstruction 70holds the potential to revolutionize this field by
overcoming this persistent challenge.
To address the obstacles associated with
implementing Deep Learning for X-ray imaging applications, a new technology called ZEISS DeepRecon Pro has been developed. ZEISS DeepRecon Pro enables fully automated training of high-performance neural networks for image reconstruction, with minimal user input required beyond specifying the desired outcome, such as improved image quality or increased throughput. This streamlined approach is effective in removing various imaging artifacts, including sparse sampling issues and random noise, resulting in higher-quality reconstructions with lower error.The effectiveness of the ZEISS DeepRecon Pro Deep Learning-based reconstruction has been demonstrated across a range of application examples, encompassing both full-field and interior tomography. Both qualitative and quantitative analyses have shown the ability of the network to produce high-quality results within its specific training dataset and for a broad range of samples and imaging conditions.
References
1.Lidke DS, Lidke KA. Advances in high-resolution imaging--techniques for three-dimensional
imaging of cellular structures. J Cell Sci . (2012) 125 (11): 2571–2580. doi: 10.1242/jcs.090027.
2.ZEISS Microsc opy. What is 3 D X-ray microscopy? Technic al Note. URL: https://pages. zeiss.com/
rs/896-XMS-794/images/Ebook_3D- X-ray-Microscopy-Second-Edit ion.pdf (accessed 23 April
2024).
3.Andrew M, Sanapala R. Advan ced reconstruct ion technolo gies Technical Note. URL: https://
zeiss.widen.ne t/s/zjqgbrsqs f/en_journal- article_eptc- 2021_package-f a-with-correla ted-xrm-
laserfib_viswa nathan-jiao-h artfield (acc essed 23 Apri l 2024).
4.Villarraga-Góm ez H, et al. I mproving thr oughput and i mage quality of high-resolu tion 3D
X-ray microscopes using deep learning reconstruction techniques. 11th Conference on IndustrialComputed Tomography (iCT), Wels, Austria. (2022) 8-11 Feb. e-Journal of Nondestructive Testing27(3). doi: 10.58286/26644.
5. Allen G, et al . Accelerate your 3D X-ray failure analysis by deep learning high resolution
reconstruction. Proceedings of the ISTFA 2021. ISTFA 2021: Conference Proceedings from the 47thInternational Symposium for Testing and Failure Analysis, Phoenix, Arizona, USA . (2021) 291–295.
doi: 10.31399/asm.cp.istfa2021p0291.
— — — — — — — — — — — — — — —
Page 73
AI for X-ray microscopy with Deep Learning-based reconstruction 71
— — — — — — — — — — — — — — —
Page 74
72
Case Studies: Examples from Life ScienceCase studies
Examples from Life Sciences
Microscopy is one of the primary methods
used to understand neurological diseases,
such as Parkinson’s disease, by studying
neural circuits. By examining the cellular
mechanisms that drive synapse formation
and regulate synapse composition,
researchers can identify patterns and rules
necessary for establishing neural circuits.
Mouse models are often used to investigate
the generation and function of these
circuits, which are relevant to various human
diseases.
This analysis involves examining dendritic
spines and neuronal projections to
understand neural circuits.
Figure 1: A four-channel microscopy image of a mouse brain with fluorescence of various labels. (a) Full image, and (b)
a single-channel image of td Tomato that highlights the neuron structure requiring segmentation for dendritic spines and
neuronal projections. (c) Zoomed-in view of a selected region from panel b , where yellow arrows indicate some dendritic
spines, which are small protrusions from the neuronal projections.The sample used for this study was provided
by R. Thomas and D. L. Benson from Icahn
School of Medicine at Mount Sinai, New York,
USA. Primary neurons expressing tdTomato
were isolated from the mouse brain and plated
in a 96-well plate for microscope imaging.
3D z-stack images were captured using a
ZEISS Celldiscoverer 7 microscope with LSM
900 and Airyscan 2, equipped with a 50x/1.2
water objective and 0.5x Tube lens. A 3D
z-stack image from one of the wells clearly
displays the reddish-yellow-colored neuronal
projections and dendritic spines that need to
be segmented (se e Figure 1 ).To truly understand and appreciate the power of AI for image analysis, practical applications
are key. This chapter shares various case studies demonstrating the diverse and practical ways
in which AI can aid image analysis. Through these examples, you’ll see the potential impact and
benefits that AI can bring to your imaging.
Microscopy and Deep Learning for neurological disease research
— — — — — — — — — — — — — — —
Page 75
73
Case Studies: Examples from Life ScienceSeparating dendritic spines and neuronal
projections with Deep Learning
A Deep Learning model must be trained to
separate spines and neuronal projections. Deep
Learning is superior to conventional Machine
Learning when dealing with complex images,
as is the case here, where spines and neuronal
projections appear similar in images.
A Deep Learning-based semantic segmentation
model was trained on ZEISS arivis Cloud. The
objective was to recognize two classes, namely
dendritic spines and neuronal projections, in
addition to the background. To create a ground
truth for each of the three classes, twelve
random slices were selected from the z-stack
and partially annotated.
The annotation process involved using a
digital paintbrush of different colors to mark
respective pixels for each class. In this case,
neuronal projections were painted in yellow,
dendritic spines in green, and the background
in dotted purple (see Figure 2 ).
Figure 2: The arivis AI training interface on the ZEISS arivis Cloud with three defined classes for segmentation: projections
(yellow), spines (green), and background (dotted purple). The inset image showcases a zoomed-in area with labeled classes
representing each category’s ground truth. It is important to note that the image is partially labeled, focusing on regions
that provide useful information for the Deep Learning model.
To refine the trained model, initial results
were visually inspected and annotations
added to indicate areas where the model was
unsuccessful. This iterative process is crucial
in data-centric model training, where the
expert’s input is a vital part of the workflow.
The iterative training process continued until
the subject matter expert was content with
the result. The model was then downloaded
and integrated into an image analysis pipeline
that involves segmentation followed by object
analysis, utilizing the 3D toolkit in ZEN. Figure 3
shows the segmented dendritic spines overlaid
on the tdTomato fluorescence image.
How microscopy and Deep Learning can
aid neurological research
Microscopy and Deep Learning are valuable
tools in Parkinson’s research, allowing
researchers to study neural circuits and
understand the cellular mechanisms that
regulate synapse formation and composition.
A Deep Learning-based semantic segmentation
model was trained to separate dendritic spines
— — — — — — — — — — — — — — —
Page 76
74
Case Studies: Examples from Life ScienceFigure 3: (a) Single-channel image of td Tomato highlighting neuron structure; same as Figure 1b. (b) Dendritic spines
segmented in blue and overlaid on the image in panel a. (c) Inset image zooms in on a region from panel b to show clear
segmentation of spines.
and neuronal projections using 3D z-stack
images captured from a ZEISS Celldiscoverer 7
microscope. An iterative process involving data-
centric model training was employed to refine
the model before integrating it into an image
analysis pipeline utilizing the 3D toolkit in
ZEN. The successful segmentation of dendritic
spines using the trained model demonstrates
the effectiveness of Deep Learning in complex
image analysis and its potential to contribute to
future neurological disease research.
Organoid analysis
Organoids are artificial three-dimensional
model systems that can imitate the cellular
composition and tissue architecture of organs
while being easier to maintain and manipulate
experimentally, making them ideal tools for
developmental biology research.
Intestinal (gut) organoids are indispensable
tools for studying both normal gut
development and the mechanisms that lead to
morbidities (e.g., inflammatory bowel disease).
The Wnt pathway is a well-known signaling
pathway regulating intestine development and
maintenance. The functions and effects of Wnt are very intricate and context-dependent, with
Wnt contributing to maintaining healthy tissue
stem cells and the transition and differentiation
of stem cells into mature enterocytes (intestinal
tissue cells). However, excessive Wnt activity
(e.g., by genetic mutations) contributes to
intestinal cancer.
Investigation of Wnt inhibition on
organoid formation
To study the effect of Wnt inhibition, intestinal
stem cells equipped with fluorescent proteins
Histone2B-RFP and Mem9-GFP to mark cell
nuclei and membranes were allowed to grow
to organoids for 5 days in the presence or
absence of Wnt signaling pathway inhibitor
IWP-2. Organoids were then fixed and
antibody-stained for aldolase B, a marker for
differentiated enterocytes, and counterstained
with DAPI (for nucleus detection).
Image acquisition was performed using a
confocal ZEISS Celldiscoverer 7 that combines
widefield and confocal imaging modes. Single
organoids were acquired at 20X magnification
with image stacks spanning the complete
organoid depth.
— — — — — — — — — — — — — — —
Page 77
75
Case Studies: Examples from Life ScienceFigure 4: Imaging of Organoids. (a) Overview scan of organoids (widefield). (b) Identification of areas of interest. (c)
Detailed confocal scan using Airyscan detector. The overview scan was performed with a 2.5x magnification in camera-
based widefield mode. For detailed scans (20x magnification), image stacks spanning the complete organoid depth were
captured in confocal mode using the Airyscan detector.
The ZEISS ZEN (blue edition) module ‘Guided
Acquisition’ was used to acquire many
individual organoids. This is an automated
imaging workflow consisting of three parts.
A large overview scan with a low magnification
(Figure 4a ), an image analysis pipeline to
identify areas of interest, in this case, individual
organoids on the overview image ( Figure 4b ),
and a detailed scan of all identified positions
(Figure 4c ).
Leveraging many segmentation tools in
ZEISS arivis Pro
The images were analyzed using ZEISS arivis
Pro with Machine Learning segmentation
performed to segment the outer organoid
cell layer. Next, the organoid lumen was
determined by filling inclusions in the
organoid cell layer segmentation. Nuclei were
segmented with the blob finder function from
H2B-RFP and DAPI channels. Nuclei within the
organoid cell layer and the organoid lumen
were separated into two object groups based
on object distances to the organoid lumen. The cell bodies were segmented via regions
growing from nuclei objects within the
organoid cell layer. Finally, all object groups
were stratified for single organoids to enable
better statistical analysis.
The validity and quality of the different
segmentations applied during the analysis were
checked. The organoid cell layer and organoid
lumen were segmented with the Machine
Learning segmenter. Employing Machine
Learning leads to superior segmentation results
compared to conventional threshold-based
segmentation, allowing discrimination
between cells in the cell layer (included in the
objects) and lumen (excluded from the objects)
based on complex image texture (see Figure
5a).
Cell nuclei were segmented with blob finder
segmentation, allowing high-quality separation
of nuclei despite them being densely packed
in 3D and despite intensity variations. By
setting up relationships between the organoid
Figure 5: Organoid cell layer and lumen segmentation. (a) The cell layer overlay is shown in green, and the lumen overlay
in yellow. (b) Nuclei in organoid cell layer and lumen. Cell layer nuclei are shown in red, and luminal nuclei in yellow. (c)
Cell bodies in the organoid cell layer. Cell layer nuclei are shown in red, and cell layer cell bodies are shown in green.
— — — — — — — — — — — — — — —
Page 78
76
Case Studies: Examples from Life ScienceFigure 6: Wnt inhibition impacts morphology of organoids. Overview images of organoids treated without (a) and with
(b) Wnt inhibitor. The images show that Wnt inhibition changes the morphology of the organoids, including size and
shape. Control-treated organoids are larger and have an irregular shape. (c) The roundness of full organoids. Single data
points, mean, and standard deviation are depicted. p -value from statistical t -test is shown.
cell layer and lumen object, nuclei were then
further separated into cell layer nuclei and
luminal nuclei (see Figure 5b ). Cell bodies were
segmented by region, growing from cell layer
nuclei. By object filtering, they were restricted
to the organoid cell layer (see Figure 5c ).
Wnt inhibition affects the morphology of
organoids
Analysis of organoid morphology showed
a trend for larger volumes and particularly a
larger spread of volumes in the control group,
suggesting that Wnt inhibition interferes
with the proper growth of the spheroids (see
Figure 6 ). However, none of these trends were
significant in a statistical t-test.
The control-treated organoids formed more
amorphous shapes, while organoids treated
with Wnt inhibitor remained spherical.
ZEISS arivis Pro offers several morphological
parameters to analyze such observations.
Statistical analysis of ‘roundness’ showed a
significant drop in control-treated samples
(see Figure 6c ). Thus, Wnt inhibition indeed
interferes with the formation of amorph
organoid shapes.
Cell numbers in different organoid
compartments
The number of cells in the different organoid
compartments were analyzed based on
nucleus object counts. There was a significant
increase in cell numbers for control-treated
organoids compared to organoids exposed
to Wnt inhibition (p < 0.05 each in statistical t-tests), indicating that Wnt inhibition interferes
with proper organoid outgrowth.
Aldolase B is a marker for enterocyte
differentiation and mainly localizes to the
cytosol, making the cell body objects the
best suited for analysis (see Figure 7a ). Using
ZEISS arivis Pro to extract channel intensities
from different hierarchical layers, aldolase B
expression was measured for the complete
organoid (see Figure 7b ), and the single-cell
mean aldolase B intensities measured
independently on every cell (see Figure 7c ). In
both cases, there is a strong and significant
increase (p < 0.001 in statistical t-tests) in
organoids that were mock-treated compared
to organoids treated with Wnt inhibitor, adding
further evidence that Wnt inhibition interferes
with organoid maturation.
Determining aldolase B-positive cells as
an alternative read out
More realistically, cells are either ‘positive’ or
‘negative’ for aldolase B, as can be observed
in a typical organoid cross section (see Figure
8). Therefore, a more suitable analysis strategy
stratifies cells into aldolase B-positive and
-negative groups, then evaluates the fraction of
positive cells within an organoid.
Using a mean pixel intensity of 15 as a
threshold for aldolase B-positive cells, positive
and negative cells were generated that match
well with the visual impression of aldolase B
— — — — — — — — — — — — — — —
Page 79
77
Case Studies: Examples from Life ScienceFigure 7: Localization of aldolase B expression in the organoids. (a) Aldolase B expression (gray) is localized to entire
cell bodies (green) rather than the nuclei (red). (b) Total organoid aldolase B expression. Single data points, mean, and
standard deviation are depicted. p -value from statistical t -test is shown. (c) Average cellular mean aldolase B intensity.
Single data points, mean, and standard deviation are depicted. p -value from statistical t -test is shown.
Figure 8: Determining aldolase positivity. (a) Localization of aldolase B expression in the organoids. Aldolase B expression
(gray) is localized to the entire cell bodies (green) rather than the nuclei (red). (b) Number of aldolase B-positive cells per
organoid. Single data points, mean, and standard deviation are depicted. p -value from statistical t -test is shown. (c)
Percentage of aldolase B-positive cells per organoid. Single data points, mean, and standard deviation are depicted.
p-value from statistical t-test is shown.
distribution in the example cross section (see
Figure 8 ). Results are shown as total positive
cells per organoid (see Figure 8b ) and as the
percentage of positive cells per organoid (see
Figure 8c ). Again, control-treated organoids
had significantly more aldolase B-positive cells,
indicating better organoid maturation.
Summary
This study highlights how combining a ZEISS
Celldiscoverer 7 and ZEISS arivis Pro for image
analysis allows easy analysis of organoids
and can help uncover biological insights,
such as the role of Wnt signaling in intestinal
organogenesis. Only 30 organoids per sample
were analyzed, which is insufficient for a
professional study and statistically relevant
conclusions. This kind of ‘real-world’ use case
helps users to learn about image analysis
strategies they can use for their data.
— — — — — — — — — — — — — — —
Page 80
78
Case Studies: Examples from Life ScienceFigure 9: (a) Phase contrast image of HeLa cells captured at 10x magnification. (b) Entropy-filtered image revealing
subtle variations in texture and tone from panel (a). (c) Segmented regions containing cells against the background
after applying a threshold to the image in (b). Note that while the cellular region is segmented, individual cells are not
separated.
Cell tracking is a commonly used assay in
biotech research, as it provides valuable
insights into a wide range of diseases and
conditions. For example, it can be used to
monitor the behavior of cancer cells, including
their proliferation, migration, and invasion,
thus helping researchers to develop new
cancer therapies and evaluate the effectiveness
of existing treatments. While fluorescent
labeling facilitates cell segmentation and
tracking, researchers often choose to image
cells in brightfield or phase contrast. This is
because these imaging techniques can provide
valuable information about cell morphology
and structure, including the size, shape, and
texture of the cell. Also, they do not require
any additional preparation of the cells, such as
labeling or staining, which means that the cells
can be imaged directly in their natural state,
without being altered by the labeling process.
This is particularly important for studying
certain cellular processes or phenomena, as
adding fluorescent labels may interfere with or
alter the behavior of the cells.
The benefits of object-based
segmentation in biomedical applications
Both conventional Machine Learning and
Deep Learning techniques (such as the use of
U-net [1) share a similar limitation: they cannot separate individual cells, which is essential
for accurate tracking algorithms. While these
methods may produce satisfactory results by
defining an additional border class, a more
reliable approach is to use object-based
segmentation algorithms, also known as
‘instance segmentation’ in the AI community.
This method is more effective in accurately
segmenting individual cells, allowing for more
precise tracking and analysis of their behavior.
Instance segmentation is a computer vision
technique used for identifying and outlining
individual objects within an image. Unlike
semantic segmentation, which assigns a
single label to each pixel in an image, instance
segmentation identifies and separates objects
based on their unique characteristics, such
as shape, size, and color. It is particularly
useful for biomedical applications, such as cell
segmentation in brightfield and phase contrast
microscopy images.
The challenges of segmenting brightfield
micrographs
However, segmenting cells in brightfield and
phase contrast images can be challenging,
primarily because the average gray level of the
cells is often equal to the average gray level
of the background. This makes it impossible Enhancing single-cell analysis with instance segmentation in phase
contrast microscopy images
— — — — — — — — — — — — — — —
Page 81
79 Case Studies: Examples from Life ScienceFigure 10: A screenshot of the annotation interface from arivis AI displaying a partially annotated training image of HeLa
cells. The cells are clearly labeled in red, while the background is labeled in dotted purple.
for demonstration purposes to illustrate the
diff erences between the semantic and instance
approaches. Figure 11 shows the input image
and its corresponding semantic segmented
images. The segmentation successfully
distinguished the cellular region and the
background, but failed to separate the cells.
Semantic segmentation is adequate if only the
area fraction of the cellular region is required,
but instance segmentation is the appropriate
tool for tracking and extracting individual
cellular information.
There are various Deep Learning-based
algorithms available for instance (object-based)
segmentation such as a modifi ed version of
U-net, but the most widely known algorithms
are Mask R-CNN [2] and Mask2Former [3].
arivis AI uses a Mask2Former approach, which
has been adapted to work with microscopy
data and is capable of segmenting images
with multiple input channels. The loss function
is also customized for training with partial
annotations, further improving the effi ciency
and accuracy of the training process. The
annotations shown in Figure 10 . were used
to train the initial instance model, and further to segment cells using conventional threshold
techniques. One solution is to apply digital
fi lters to generate fi ltered images that can then
be segmented using threshold techniques. For
example, an entropy fi lter can highlight regions
of high texture (see Figure 9b ), which can help
separate cells from the background.
However, this approach fails at properly
separating cells from each other (see Figure
9c). Watershed-based separation is often
used to address this issue, but it can lead to
inconsistent results between frames, potentially
making cell tracking discontinuous between
frames.
Instance segmentation of HeLa cells to
track their movement, shape and size
In this case study, HeLa cells grown over time
in a multi-well plate were imaged under phase
contrast mode using a ZEISS Celldiscoverer 7
microscope with a Plan-Apochromat 20X/0.95
objective and 0.5x Tube lens yielding an
eff ective magnifi cation of 10x. To study the
cells at a single-cell level, including tracking
over time, they were segmented using the
instance segmentation approach. ZEISS arivis
Cloud platform was used to annotate the
training images (see Figure 10 ).ZEISS arivis Cloud off ers tools for both semantic
segmentation and instance segmentation.
A semantic model was initially trained only
— — — — — — — — — — — — — — —
Page 82
80
Case Studies: Examples from Life Science
Figure 11: (a) Phase contrast
image of HeLa cells captured at
10x magnification. (b) Semantic
segmentation result using a U-net-
based Deep Learning architecture.
The pink area represents the
cellular region, which has been
successfully segmented from the
background. However, it should
be noted that individual cells are
not separated by this approach.
Figure 12: (a) Phase contrast
image of HeLa cells captured at
10x magnification. (b) Result of
instance segmentation using the
Mask2Former Deep Learning
method, clearly separating
individual cells and enabling
direct use of the result in
applications such as cell tracking.annotations were added based on the results
to better segment regions where the model
encountered difficulty, primarily the regions
with high density of cells. This data-centric
approach saves time by focusing on annotating
challenging areas instead of wasting time
on simple ones. Figure 12 illustrates the
results of instance segmentation on the same
input image as in Figure 11 . The instance
segmentation effectively separated individual
cells, allowing for the tracking of cells in the
time series image dataset.
All images from the time series underwent
segmentation using the trained model. The
resulting masks were imported into ZEISS
arivis Pro for further analysis, where cells were
tracked and followed individually throughout
the time course. Tracking was made easy
by the well-separated, segmented masks
generated through instance segmentation.
Even cell division events were detectable in
tracking, with daughter cells retaining their
tracking identity. Figure 13c displays the first
image in the time series with tracks overlaid to
show the cell center positions at each
time point.While this particular use case focused on the
use of instance segmentation for cell tracking,
the instance segmentation approach can
provide insights from images in many other
ways. For example, the size and shape of cells
can provide crucial information about their
state and behavior, enabling the monitoring
of the effects of various treatments on cells.
As instance segmentation separates individual
cells, they can be sorted based on size (see
Figure 14b ) or shape (see Figure 14c ) with ease.
Summary
In summary, instance segmentation enables
the easy segmentation and separation of
individual objects, allowing for various insights
to be extracted through object tracking and
sorting based on size and shape, among other
methods. arivis AI’s data-centric approach
saves time and ensures efficient annotation of
complex features for instance segmentation
model training. The resulting trained model can
then be used in end-to-end applications such
as cell tracking.
— — — — — — — — — — — — — — —
Page 83
81
Case Studies: Examples from Life ScienceFigure 13: (a) Phase contrast image of HeLa cells captured at 10x magnification. (b) Result of instance segmentation
using the Mask2Former Deep Learning method. (c) Result of the tracking algorithm showing cell tracks overlaid on the
original image from (a). The tracking analysis was performed using ZEISS arivis Pro.
Figure 14: (a) Phase contrast image of HeLa cells captured at 10x magnification. (b) Cells are color-coded by size, with
smaller cells in green and larger cells in pink. (c) Cells color-coded by shape, with rounded cells in green, less rounded cells
in purple, and cells with medium sphericity in cyan.
References
1. Ronneberger O, Fischer P and Brox T. (2015). U-Net: Convolutional Networks for Biomedical
Image Segmentation. In: Navab N, Hornegger J, Wells W, and Frangi A. (eds) Medical Image
Computing and Computer-Assisted Intervention – MICCAI 2015. MICCAI 2015. Lecture Notes in
Computer Science (Vol. 9351, pp. 234-241). Springer, Cham. doi:10.1007/978-3-319-24574-4_28.
2. Kaiming H, Georgia G, Piotr D, Ross G. Mask R-CNN. (2018) arXiv:1703.06870 doi
org/10.48550/arXiv.1703.06870.
3. Bowen C, Ishan M, Alexander S, Alexander K, Rohit G. Masked-attention Mask Transformer for
Universal Image Segmentation. (2021) arXiv:2112.01527
— — — — — — — — — — — — — — —
Page 84
82
Case Studies: Examples from Life ScienceFocused ion beam scanning electron
microscopy (FIB-SEM) is a powerful imaging
tool that achieves resolutions of under 10
nm and produces highly detailed 3D image
volumes. FIB-SEM highlights the entirety of
the cell, generating images dense with cellular
features, structural edges, and varying pixel
combinations. The complexity of these images
makes it difficult to use standard image
processing segmentation algorithms to detect
many cellular structures of interest. Therefore,
quantitative analysis of FIB-SEM data often
relies on the tedious and time-consuming
manual drawing of features of interest on 2D
slices of a 3D image volume.
AI-assisted volume EM (vEM) analysis using
Deep Learning approaches offer a way to
move beyond reliance on manual annotation
for segmenting cellular structures [1]. Such an
approach was used to develop a cell-profiling
workflow using neural network training and
image analysis tools that are readily accessible
to researchers and do not require coding.
The first step was training the Deep Learning
model. Using the ZEISS arivis Cloud platform,
subsets of organelles (mitochondria and
nucleus) within a FIB-SEM image of a HeLa
cell (see Figure 15 ) were manually drawn
and used to train neural network models to
identify these large organelles successfully
(see Figure 16 ). These arivis AI-trained Deep
Learning models were initially used to infer
mitochondria and the nucleus in ZEISS arivis Pro
before analysis pipelines were built to filter and
improve the initial inferences into usable 3D
segments.
Segmentation and measurements of
organelles
The neural network models developed from
the arivis AI training allowed the automated
measurement of organelle volume (see Figure
17). ZEISS arivis Pro computes the volume
Figure 15: Overview of HeLa cell image set. The image
set was collected using a ZEISS Auriga Crossbeam FIB-SEM.
(a) nm-resolution image volume of the HeLa cell. (b) Pixel
intensities were inverted to achieve positive signals in a
dark background. (c and d) 3D volumetric renderings of the
image volume, which do not make sense without a positive
signal in black background.
for all 3D objects, making it easy to calculate
the percentage of total cell volume occupied
by each organelle (see Figure 17c ). The
profiling results were consistent with previous
measurements, showing that mitochondrial
volume is ~10% of the cytoplasm volume
within HeLa cells [2].
Mitochondrial characterization and
spatial classification
Once the organelles were segmented, their
distribution and surface-to-volume ratios were
characterized ( Figure 18 ). Analysis pipelines Analysis of FIB-SEM volume electron microscopy data
— — — — — — — — — — — — — — —
Page 85
83 Case Studies: Examples from Life Science
Figure 16: Generation of Deep Learning models for organelles using the ZEISS arivis Cloud platform. Mitochondria and
the nucleus were painted as individual classes for training.
in ZEISS arivis Pro computed the distances of
mitochondria to cellular structures. While the
distances of each mitochondrion’s center of
geometry were not signifi cantly correlated
to the nuclear membrane (see Figure 18c )
or the plasma membrane (see Figure 18d ),
the minimum distance of each mitochondrial
center of geometry to either membrane did
show a significant correlation (see Figure 18e ).This method can be used with any cell
structures that have been segmented and can
measure distances between object surfaces
or centers of geometry. It is also possible to
scale this method using the ZEISS arivis Hub to
allow the analysis of multiple cell image sets in
parallel and produce automated, high-quality
profiles.
Figure 17: Segmentation results from a Deep Learning trained model can predict the percent of cell volume for organelles.
— — — — — — — — — — — — — — —
Page 86
84
Case Studies: Examples from Life ScienceInitial 3D segmentation of nuclear pore
complex regions
3D segmentation of nuclear pore complex
(NPCs) regions was limited by the image
resolution (100–150 voxels per pore) and the
3D structure of each pore uniquely oriented
to the curvature of the nuclear membrane.
Extremely tedious annotation of the NPCs in
all possible orientations would be required
to segment and measure the nuclear pores.
Instead, the relatively large (~400–2000 voxels)
pockets under the pores were analyzed.
The under-NPC objects were used to derive
objects representing the actual pores to create
ground truths for a new 3D-aware Deep
Learning neural network that can segment the
NPCs directly (see Figure 19 ).
Once the segmentation of the NPCs
was complete, the image stack and the
corresponding NPC mask were rotated 30°,
60°, and 90° on the X and Y axes, and the
resulting stacks were resampled to provide the 3D-aware augmented images of the 2D Deep
Learning algorithm on the ZEISS arivis Cloud
platform.
The trained model was used to segment
the nuclear pores on the entire nucleus
to characterize their spatial distributions
(see Figure 20 ). Approximately 80% of the
total NPCs in the nucleus were successfully
segmented.
Distribution and density analysis of
nuclear pores
The segmented NPCs were used to view
and quantify the 3D distribution of NPCs
throughout the nuclear membrane using two
approaches: (1) the ZEISS arivis Pro Distances
operator and (2) the ZEISS arivis Pro Python
application program interface (API) (see
Figure 21 ). Both the ZEISS arivis Pro Distance
operator and the kernel density Python script
were capable of consistently identifying clusters
of pores. Further characterization of the NPC
distribution across the nuclear membrane Figure 18: Mitochondrial surface area-to-volume ratios are negatively correlated with the distance to membranes.
— — — — — — — — — — — — — — —
Page 87
85
Case Studies: Examples from Life Science
Figure 19: NPCs have variable density distribution across areas of the nucleus. Several processing steps were done to
create masks of NPCs from the pocket objects. Taking the pocket objects (a), a binary masked image was generated (b),
followed by a closing operation of the pockets to the nuclear membrane (c). Next, the nuclear membrane and pockets
were used to mask the white space shown in panel c (d). These objects were then dilated (e). Masking using these objects
enhances the visualization of NPCs (f).
found that NPC density is higher within the
smaller nucleus section with higher curvature
(see Figure 21d ). In contrast, the larger section
with a lower curvature degree has more
low-density regions for nuclear pores.
The benefits of Deep Learning for
analysis of FIB-SEM imaging
The combination of traditional and Deep
Learning algorithms with prior biological
knowledge can produce powerful workflows,
Figure 20: Training a 3D-aware neural
network for nuclear pore segmentation.
Several processing steps were done to
create masks of NPCs from the pocket
objects. Taking the pocket objects, a
binary masked image was generated,
followed by the 3D-aware resampling
in preparation for arivis AI training
(a). The resulting CZANN model was
used to create the probability map in
ZEISS arivis Pro with the Deep Learning
Reconstruction operator (b). This 3D
stack was filtered using the ‘Preserve
bright particles’ operator, and the
objects were segmented using the
Watershed algorithm with a strict
threshold (c). In the following step,
the smaller subset of the particles was
expanded by region-growing, while the
largest particles were split and filtered
with the segment feature filter (d).
as demonstrated in this chapter. By generating
objects in the vicinity of NPCs, we can more
accurately identify nuclear pores in 3D regions,
which may not be clearly visible through 2D
analysis alone. These 3D objects, representing
nuclear pores, can then serve as ground truths
for neural network training in Deep Learning.
Overall, this approach can lead to more
precise and comprehensive analyses
of cellular structures.
— — — — — — — — — — — — — — —
Page 88
86
Case Studies: Examples from Life ScienceFigure 21: NPCs have variable density distribution across areas of the nucleus. (a) The average distance of each nuclear
pore object to the nearest eight nuclear pore objects was measured using the Distance operator in ZEISS arivis Pro. The
nuclear pore objects were then color-coded according to these distance measurements to represent the density of nuclear
pores across the nuclear membrane. (b) As an alternative method of analyzing the distribution of the pore objects, the
densities of NPCs were determined by taking the 3D centroid of each NPC object and calculating a Gaussian kernel density,
with a kernel radius of 0.1 µm, using a custom Python script. (c) The density distribution of NPCs is significantly different
across separate areas of the nucleus. Sectioning the nucleus into two sections, a larger and a smaller section, based on
the nuclear cleavage furrow, reveals significant differences in kernel density scores. (d) Two-tailed t-test was performed to
calculate the significance of differences between the kernel density scores in these two sections of the nucleus.
References
1. Parlakgül G, Arruda AP, Pang S, et al . Regulation of liver subcellular architecture controls
metabolic homeostasis. Nature (2022) 603 (7902):736–742. doi: 10.1038/s41586-022-04488-5
2. Posakony JW, England JM and Attardi G. Mitochondrial growth and division during the cell cycle
in HeLa cells. J Cell Biol . (1977) 74 (2):468–491 doi: 10.1083/jcb.74.2.468.
— — — — — — — — — — — — — — —
Page 89
87
Case Studies: Examples from Life Science
— — — — — — — — — — — — — — —
Page 90
88
Case Studies: Examples from Life Science
Figure 22: Manual annotation of control and swollen
mitochondria phenotypes (in yellow) of TEM images of
hippocampus tissue sections to create ground truths for
training the Deep Learning model. Original imaging data
was kindly provided by Dr. Wendy Bautista, MD PhD,
Barrow Neurological Institute, Phoenix Children’s Hospital.To understand the effects of hypoxic
conditions on mitochondria in brain tissue,
researchers from the Barrow Neurological
Institute, Phoenix Children’s Hospital used
the ZEISS arivis Pro pre-trained Deep Learning
model to segment all the mitochondria objects
on the hippocampal tissue section. Exposure to
hypoxic conditions means the mitochondria in
these tissue samples have varying morphology:
some appear normal, and some have
‘swollen’ morphology. Creating one Deep
Learning model to recognize all mitochondria
phenotypes in a single step posed an additional
challenge.
Training the Deep Learning model
30 TEM serial sections were used with 309
mitochondria objects, annotated manually
with the ZEISS arivis Pro drawing tool to create
ground truths for training the Deep Learning
model (see Figure 22 ). The U-net model,
with architecture very similar to the original
publication [1], was used.
Using Deep Learning to segment and
classify mitochondria
The Deep Learning model was applied to the
whole dataset in ZEISS arivis Pro for automated
segmentation (see Figure 23a ). ZEISS arivis Pro
has an extensive list of quantitative features
that characterize each object. In addition,
it is possible to create custom features or
import them from external sources. A custom
object feature that computes the ratio of the
mean intensity of each object to its volume
was created to classify the objects into the
‘control’ and ‘swollen’ groups. For visualization
purposes, each object was color-coded
according to the value of the mitochondria
phenotype custom feature (see Figure 23b ).
Comparing the Deep Learning segmentation
with the manual segmentation (see Figure
23) shows the accuracy of the Deep Learning
model for segmenting mitochondria and how Analysis of mitochondria using Deep Learning
this segmentation, combined with the ability
to create custom object features, can be used
to classify individual mitochondrial phenotypes,
simplifying the investigation of the effects of
hypoxic conditions on mitochondria in brain
tissue.
Segmenting mouse muscle 3D
ultrastructure
Unraveling the architecture of muscle fibers
is crucial for understanding their functional
properties and underlying physiological
processes. Electron microscopy (EM) imaging
plays a pivotal role in this effort, enabling
researchers to visualize the detailed subcellular
organization within muscle tissue. However, the
complexity of muscle samples poses significant
challenges for accurate segmentation and
analysis of EM data.
To address these challenges, an approach
leveraging advanced AI-powered segmentation
techniques was employed to study the
ultrastructure of mouse muscle samples,
— — — — — — — — — — — — — — —
Page 91
89 Case Studies: Examples from Life ScienceFigure 23: Deep Learning segmentation and classifi cation of mitochondria objects. Left image shows manually
segmented mitochondria (yellow objects) and the Deep Learning inference results (cyan objects) overlayed to illustrate the
accuracy of the predictions. Right image shows the spectrum of the mitochondria phenotypes, which is reflected in the
color of the corresponding objects [purple (normal) to red (extremely swollen)]. The phenotype is quantified as the mean
intensity of the object divided by its volume and stored in the custom feature value. Original imaging data was kindly
provided by Dr. Wendy Bautista, MD PhD, Barrow Neurological Institute, Phoenix Children’s Hospital.
Using AI to Overcome Challenging
Segmentation
www.zeiss.com/microscopy/ai-mitochondriaunlocking unprecedented insights into the
organization of muscle fi bers and their cellular
components.
Challenges of imaging of muscle samples
using EM
Muscle samples present several unique
challenges. Firstly, capturing the complex
details of muscle fi bers at high resolution
demands specialized equipment and
meticulous sample preparation. Additionally,
preserving the delicate ultrastructure of the
sample during fi xation and embedding is
crucial to avoid artifacts in the fi nal images.
Another challenge posed by muscle samples
is the large size of muscle fi bers, which
makes it diffi cult to capture a comprehensive
overview while maintaining the high resolution
necessary to image individual fi laments within the tissue. This requires custom imaging
strategies and advanced equipment capable of
handling such large samples.
In this case study, three-dimensional (3D)
volumetric data of the mouse muscle samples
was collected using the ZEISS Crossbeam 550
FIB-SEM system at room temperature.
The samples were prepared using the rOTO
(reduced osmium-thiocarbohydrazide-osmium)
protocol which is a technique that helps
preserve the ultrastructural details of muscle
tissues.
Segmentation inhibits EM analysis of
muscles
One of the most signifi cant hurdles in the
analysis of EM data for muscle samples is the
segmentation of cellular components. Unlike
fl uorescence light microscopy images, which
allow for the separation of diff erent labeled
targets, EM images show various objects of
interest, all in a single grayscale image. The
mean gray values for these objects frequently
overlap. This makes it particularly challenging
— — — — — — — — — — — — — — —
Page 92
90
Case Studies: Examples from Life ScienceFigure 24: Analysis of mouse muscle ultrastructure. (a) 2D slice from a volumetric FIB-SEM dataset of mouse muscle
ultrastructure acquired using a ZEISS Crossbeam 550 FIB-SEM. (b) Segmentation result of the image in panel (a), showing
various components of the muscle tissue in different colors: filaments (green), capillary (yellow), myofibrils (blue),
mitochondria (cyan), and sarcoplasmic reticulum (pink). The segmentation was performed using a multiclass Deep
Learning model trained on ZEISS arivis Cloud and implemented in ZEISS arivis Pro software.
to accurately delineate their boundaries.
Muscle fibers consist of a dense network
of myofibrils, mitochondria, nuclei, and
other subcellular structures. This complexity
exacerbates the segmentation difficulties.
Furthermore, traditional segmentation
algorithms often fail to cope with the high
complexity and minimal contrast within and
between these intricate structures.
AI-powered segmentation:
A transformative approach
To overcome these challenges, a combination
of Deep Learning models and cloud-based
processing was employed to tackle the
segmentation of key cellular components,
including the cell, mitochondria, myofibrils, and
filaments.
The AI-assisted segmentation process involved
partially annotating a handful of images
from the volumetric data by painting regions
of interest for each cellular component in
different colors. The annotation and Deep
Learning training for semantic segmentation
were performed using the ZEISS arivis Cloud
software. The trained model was downloaded
to the ZEISS arivis Pro software to segment the
entire volume, render the 3D reconstruction,
and perform further analysis. The volumetric data was accurately segmented
down to the pixel level by leveraging the
powerful texture recognition capabilities
of Deep Learning, despite the high image
complexity and minimal contrast. Using both
local and cloud-based processing solutions
allowed for efficient handling of the large
dataset sizes, further enhancing the accuracy
and speed of the segmentation process.
The segmentation results are shown in Figure
24, with panel (a) depicting a 2D slice from the
original FIB-SEM data and panel (b) depicting
the segmented components, including
filaments, capillary, myofibrils, mitochondria,
and sarcoplasmic reticulum, in different colors.
The successful implementation of AI-powered
segmentation enabled the acquisition of
unprecedented insights into the organization
of mouse muscle fibers. Figure 25 presents
a 3D volume rendering of the segmented
components from Figure 24b overlaid on
the original FIB-SEM data, allowing for a
comprehensive visualization of the muscle
ultrastructure in its native context.
This level of detailed visualization and
quantification of muscle ultrastructure
is essential for understanding muscle
— — — — — — — — — — — — — — —
Page 93
91
Case Studies: Examples from Life ScienceFigure 25: 3D volume rendering of segmented mouse muscle ultrastructure overlaid on the original EM data. The
rendering visualizes the segmented components of the muscle tissue, including filaments (green), capillary (yellow),
myofibrils (blue), mitochondria (cyan), and sarcoplasmic reticulum (pink), in their native 3D context within the EM volume,
which was acquired using a ZEISS Crossbeam 550 FIB-SEM. The segmentation was performed using a multiclass Deep
Learning model trained on ZEISS arivis Cloud and implemented in ZEISS arivis Pro software.
Summary
The challenges posed by EM imaging of muscle
samples are formidable, but the application of
AI-powered segmentation has demonstrated
transformative potential in overcoming these
barriers. By leveraging Deep Learning and
cloud-based processing, the complex cellular
components within mouse muscle fibers were development, identifying pathological
alterations in muscle diseases, and designing
targeted therapeutic interventions. The findings
have the potential to significantly advance the
field of muscle biology research and pave the
way for groundbreaking discoveries.
References
1. Ronneberger O, Fischer P and Brox T. (2015). U-Net: Convolutional Networks for Biomedical
Image Segmentation. In: Navab N, Hornegger J, Wells W, and Frangi A. (eds) Medical Image
Computing and Computer-Assisted Intervention – MICCAI 2015. MIC CAI 2015. Lecture Notes
in Computer Science (Vol. 9351, pp. 234-241). Springer, Cham. doi:10.1007/978-3-319-24574-
4_28.accurately segmented, unlocking a new level
of insights into muscle ultrastructure and
function.
This case study highlights the transformative
impact of AI in the field of microscopy image
analysis, showcasing how cutting-edge
technology can empower researchers to
unravel the complexities of biological systems
and drive scientific progress.
— — — — — — — — — — — — — — —
Page 94
92
Case Studies: Examples from Life ScienceUsing zebrafish as a model for biomedical
research is well established. This case study
explores how zebrafish are used for in vivo
research of Shigella and other bacterial
pathogens. We will review the challenges
of sample throughput demands, and how
they were resolved using AI-driven solutions
for more efficiency, higher microscope
performance, and enhanced image analysis
capabilities.
The importance of zebrafish for
biomedical research
Zebrafish are highly amenable to laboratory
research, producing hundreds of embryos per
day and they are considered a close model of
the human immune system. Their genome is
fully sequenced and can be easily manipulated.
Combined with their optical accessibility,
this makes them useful for quantitative
microscopy approaches and drug screening.
This is why they serve as a great model for
disease characterization, researching biological
processes in depth in vivo , and identifying
Figure 26: Imaging workflow overview. (a) Flow chart describing the AI-based workflow. (b) Whole zebrafish is segmented
in a well plate. (c) AGM region segmented in a well plate.Enhancing the utility of zebrafish models to study infectious diseases
using Deep Learning
new treatment methods. Moreover, their rapid
growth makes it easy to observe diverse effects
over time.
The Mostowy Lab at the Department of
Infection Biology, London School of Hygiene
and Tropical Medicine, led by Dr. Serge
Mostowy, aims to deepen our understanding
of cellular immunity and illuminate innovative
therapeutic approaches using zebrafish models
[1]. Their current focus is on deciphering the
molecular and cellular mechanisms underlying
host defense against Shigella , an important
human pathogen, which today lacks an
effective vaccine.
The challenges of in vivo research
High numbers of zebrafish embryos are
readily available for laboratory study, but
the bottleneck lies in processing samples
for quantitative microscopy. In addition, it is
challenging to study the whole animal while
it is alive. This calls for higher throughput in
image acquisition and analysis over time.
— — — — — — — — — — — — — — —
Page 95
93
Case Studies: Examples from Life ScienceFigure 27: AI-based predictions of zebrafish embryos in well plates, as seen in ZEISS arivis Cloud. The AI model overcomes
diverse shapes and positions, even in low-resolution images.
Acquiring the necessary images from an entire
96-well plate of zebrafish at high resolution
is too time- and resource-consuming. To
overcome this, the lab must first find the
embryos in the wells and segment regions of
interest (ROI) in low-resolution images, before
investing time in high-resolution imaging of
the identified regions. Furthermore, traditional
methods of image segmentation are often
insufficient due to low contrast between the
zebrafish and its surroundings, leading to
time-consuming manual annotation. Fully
manual approaches are susceptible to human
bias and frequently take too much time.
This is why the lab sought a more efficient
solution, focusing on automation and AI. The
lab was looking for an enhanced workflow
that not only automated image acquisition, but
also eliminated the need for tedious manual
drawing.
How AI-based automation helps
To enable high-resolution imaging to be
targeted specifically at the zebrafish and its
ROIs, the ZEISS Solutions Lab collaborated with the Mostowy Lab to develop a customized,
AI-driven automated solution that can detect
these ROIs within an entire well (see Figure 26 ).
The joint efforts resulted in the fully automated
acquisition of a time series of high-resolution
z-stacks of both zebrafish and specific ROIs.
The structure of the new workflow is:
■Acquire an image of the entire well at low
resolution.
■Segment the fish and the ROI using
AI-trained model on ZEISS arivis Cloud
(Figure 27 ).
■Integrate AI models into ZEN and analyze
the images to recognize the ROIs.
■Use automated guided acquisition for
high-resolution ROI imaging.
■Automatically trigger the guided acquisition
to acquire multiple images over time (e.g.,
2–4 days).
— — — — — — — — — — — — — — —
Page 96
94
Case Studies: Examples from Life Science
Figure 28: The ZEN software displaying the zebrafish larvae in the wells of a 96-well plate.
The customized solution saves time on fast
imaging of the zebrafish larvae in 96-well
plates ( Figure 28 ).
The Deep Learning model automatically
segments both the entire zebrafish and the
aorta-gonad mesonephros (AGM) region.
High-resolution imaging is then targeted only
to the recognized ROIs. The imaging occurs
automatically over time at defined time points.
The custom Deep Learning model is capable
of detecting zebrafish embryos at different
developing stages, from 1 to 4 days post-
fertilization, which is critical to the research
application. The new workflow results in
high-quality z-stacks of multiple channels
and time series images and reduces human
involvement in the acquisition process. This
enables non-biased image acquisition and
analysis. The entire process is user-friendly and
faster than traditional methods.
Historically, the lab would rely on imaging
3–20 larvae for most experiments. With the
Celldiscoverer 7 microscope (see Figure 29 ) for
automated, AI-enhanced well plate imaging
and analysis, they can now study significantly
more samples. This has added much more depth to the research performed in the
Mostowy Lab by transforming the methods of
using the zebrafish model.
Results with the AI-based workflow
The Mostowy Lab has already published
two papers working with the automated,
AI-enhanced workflow.
In one study, they tracked Shigella infection
and tested the role of diverse antibiotics on
various Shigella strains [2,3]. The team could
observe the infection over time and test the
synergies between antibiotics and the immune
system when combating it.
In a subsequent study, the lab used the AI
workflow to test if mutations in the septin
cytoskeletal protein family affect zebrafish
larvae development, as well as a means of
developing host-directed therapies to control
Shigella infection [4].
AI enables new zebrafish research
ambitions
The AI-enhanced workflow has transformed
ambitions for using the zebrafish model,
according to Dr. Mostowy. The automated
workflow allows the team to work in 96-well
— — — — — — — — — — — — — — —
Page 97
95 Case Studies: Examples from Life Science
Figure 29: View of the ZEN software used to control the Celldiscoverer 7 microscope.plates, generating faster results that enable
applications such as screening pharmacological
compounds.
The new tools will enable monitoring both
Shigella infection over time, and the zebrafi sh
immune system in more detail. This means not
only studying the zebrafi sh as a whole animal
but performing analysis at the single cell level
in vivo , to capture infection events and study
single cells over time.
Watch the Video to Learn More
www.zeiss.com/zebrafi sh-shigellaPossible research advancements
Overall, the advancements mentioned in the
previous section could potentially lead to:
■Faster results for a more immediate clinical
impact.
■Drug discovery and genetic screening.
■Diverse infection research (not just Shigella ).
■A new level of detail for in vivo infection
research (cellular and subcellular level).
■Enhanced models for studying zebrafi sh
development and underlying mechanisms.
— — — — — — — — — — — — — — —
Page 98
96
Case Studies: Examples from Life ScienceReferences
1. Mostowy Lab. Department of Infection Biology. London School of Hygiene and Tropical
Medicine. URL: https://themostowylab.org/research/ (accessed 03 May 2024).
2. Lensen A, Gomes MC, López-Jiménez AT, and Mostowy S. An automated microscopy workflow
to study Shigella–neutrophil interactions and antibiotic efficacy in vivo . Dis Model Mech . (2023)
16(6):dmm049908. doi: 10.1242/dmm.049908.
3. First person – Arthur Lensen and Margarida C. Gomes. URL: https://journals.biologists.com/
dmm/article/16/6/dmm050255/308934/First-person-Arthur-Lensen-and-Margarida-C-Gomes
(accessed 03 May 2024).
4. Torraca V, Bielecka MK, Gomes MC, Brokatzky D, Busch-Nentwich EM, Mostowy S. Zebrafish
null mutants of Sept6 and Sept15 are viable but more susceptible to Shigella infection.
Cytoskeleton . (2023) 80 :266–274. doi: 10.1002/cm.21750.
Acknowledgment
This case study and images used are courtesy of Dr. Serge Mostowy and Dr. Margarida C. Gomes
from the Mostowy Lab at the Department of Infection Biology, London School of Hygiene and
Tropical Medicine.
— — — — — — — — — — — — — — —
Page 99
97
Case Studies: Examples from Life Science
— — — — — — — — — — — — — — —
Page 100
98
Case Studies: Examples from Life ScienceMouse models are valuable tools in genetic
research since they closely resemble humans
in terms of physiology and genetics. These
qualities render them indispensable for
researching human diseases, developmental
biology, genetic abnormalities, and toxicity. All
these research fields benefit from a thorough
understanding of mouse embryo development
and the impact and function of different genes
and proteins in this process.
Comparing the phenotype of mouse
embryos from different genetic lines enables
researchers to examine the consequences
of targeted gene alterations. This enhances
comprehension of gene function, genetic
disorders, developmental processes, and
prospective therapeutic targets [1]. Capturing a
digital record of the observable characteristics
of the internal structure of mouse embryos
provides a unique way of comparing these
different genetic lines. Scientists can use the 3D
datasets from different stages of development
to discern phenotypic patterns, genetic
aberrations, and their associations with human
illnesses [2].
Figure 30: Iodine contrasted E15.5 mouse embryo imaged using Zeiss Xradia Context microCT. (a) 3D rendering of the
reconstructed dataset. (b) Digital section through the 3D rendered dataset to show the internal embryo components in the
chosen embryo cross-section. Sample courtesy of Chih-Wei Logan Hsu, Baylor College of Medicine.Exploring mouse embryo development with microCT and AI
MicroCT imaging of mouse embryos:
Non-destructive insights into
developmental anatomy
Micro-computed tomography (microCT) is
an ideal imaging technology to analyze the
physical characteristics of mouse embryos.
MicroCT is a non-destructive method, allowing
the capture of both exterior and interior
structures without needing to physically
section the sample (see Figure 30 ).
For optimal microCT imaging of mouse
embryos, fixation, and staining procedures
are necessary to improve tissue contrast.
Hydrogel can be used to provide stabilization
and support to maintain tissue shape during
imaging [3]. The microCT scan generates
a precise and accurate 3D depiction of the
specimen, facilitating the visualization of
intricate anatomical features. A comprehensive
view of embryonic progression can be
obtained by examining several embryos at
various developmental stages [4].
— — — — — — — — — — — — — — —
Page 101
99 Case Studies: Examples from Life ScienceHarnessing AI for microCT analysis
Despite the remarkable contrast achieved by
microCT in biological samples, analyzing 3D
volumes remains a complex task due to the
high degree of tissue similarity. This challenge is
particularly evident when managing numerous
specimens that require consistent analysis
results.
AI algorithms, particularly those based on Deep
Learning, provide robust methods to facilitate
the examination of mouse embryo microCT
datasets by automating and streamlining the
segmentation process for organs and tissues.
They accurately distinguish between diff erent
structures, even when they share similar
characteristics.
Figure 30b presents a digital cross-section of a
3D rendering showcasing an iodine-contrasted
E15.5 mouse embryo. In this representation,
internal components such as the liver, heart,
and eyes are clearly discernible. However,
the image lacks suffi cient grayscale contrast
between these organs, hindering their
segmentation through traditional histogram
thresholding-based approaches.
Furthermore, these regions exhibit minimal
texture diff erences at the pixel level, rendering
conventional feature engineering-based
Machine Learning approaches ineff ective.
Crafting specifi c features for this task may
prove time-consuming, even for seasoned
Machine Learning experts. Deep Learning, with
its millions of tunable parameters, is particularly
suited to accurately model the intricate
distinctions among these regions.
For organ segmentation, we employed a U-net
based semantic segmentation approach on
the ZEISS arivis Cloud platform that facilitates
data-driven training of Deep Learning models
designed explicitly for image segmentation.
The semantic segmentation method on
ZEISS arivis Cloud employs a modifi ed U-net
with an Effi cientNet encoder, providing adaptability across various applications. In
addition, it integrates Focal Loss to address
challenges related to class imbalance and the
segmentation of diffi cult classes versus easy
classes. Figure 31a showcases the results,
illustrating clear segmentation of the brain and
spinal cord, heart, liver, kidney, and eyes, each
depicted in distinct colors. Figure 31b displays
the same regions using the original pixel values,
essentially off ering a digital extraction of these
organs from the encompassing 3D dataset.
3D visualization of mouse
embryo segmentation
www.zeiss.com/mouse-embryo
Summary
The integration of microCT technology and
advanced artifi cial intelligence methodologies
can enhance the exploration of the complex
landscape of mouse embryo development. The
U-net based semantic segmentation approach
was instrumental in overcoming the challenges
posed by complex anatomical structures in
the 3D volumetric dataset. As technology
continues to evolve, the synergy between
imaging technologies and AI promises to
further enhance our understanding of mouse
embryo development and the infl uence of
genes and external factors on this process.
— — — — — — — — — — — — — — —
Page 102
100
Case Studies: Examples from Life ScienceReferences
1. Dickinson ME, Flenniken A, Ji X, et al. High-throughput discovery of novel developmental
phenotypes. (2016) Nature 537(7621): 508–514 doi: 10.1038/nature19356.
2. Hsu CW, Wong L, Rasmussen TL, Kalaga S, McElwee ML, Keith LC, Bohat R, Seavitt RJ, Beaudet
AL, and Dickinson ME. Three-dimensional microCT imaging of mouse development from early
post-implantation to early postnatal stages. (2016) Dev Biol. 419 (2):229–236 doi: 0.1016/j.
ydbio.2016.09.011.
3. Wong MD, Spring S, and Henkelman MR. Structural Stabilization of Tissue for Embryo
Phenotyping Using Micro-CT with Iodine Staining. (2013) PLoS ONE 8(12):e84321 doi: 10.1371/
journal.pone.0084321.
4. Hsu CW, Kalaga S, Akoma U, Rasmussen TL, Christiansen AE, and Dickinson ME. High
resolution imaging of mouse embryos and neonates with X-ray micro-computed tomography.
(2019) Curr Protoc Mouse Biol . 9:e63 doi: 10.1002/cpmo.63.Figure 31: Iodine contrasted E15.5 mouse embryo imaged using Zeiss Xradia Context microCT. (a) Segmentation of
internal organs was performed for the brain and spinal cord (turquoise), heart (red), liver (yellow), kidney (purple) and
eyes (blue). The image segmentation process involved training a Deep Learning model on ZEISS arivis Cloud. Subsequently,
the trained model was applied in ZEISS arivis Pro software to perform segmentation and visualize the complete volume,
providing comprehensive insights into the segmented structures. (b) The segmented organs were subsequently digitally
extracted from the whole dataset for separate visualization. Sample courtesy of Chih-Wei Logan Hsu, Baylor College of
Medicine.
— — — — — — — — — — — — — — —
Page 103
101
Case Studies: Examples from Life Science
— — — — — — — — — — — — — — —
Page 104
102
Case Studies: Examples from Materials ScienceThe importance of investigating the
microstructure of aluminum oxide
Aluminum oxide (Al2O3) is a highly versatile
material with excellent mechanical, electrical,
and thermal properties. Its high resistance
to wear, corrosion, and oxidation further
contributes to its widespread use. The
microstructure of aluminum oxide, which
includes the size, shape, and distribution of
its grains, inclusions, and grain boundaries,
can significantly impact its physical and
mechanical properties. For instance, the size
and distribution of the grains can affect the
strength, toughness, and hardness. The grain
boundaries can influence its behavior under
different conditions, such as temperature,
stress, and corrosion. Thus, investigating
the microstructure of aluminum oxide can
help researchers and engineers optimize
its properties for specific applications and
understand its behavior under varying
conditions.
Figure 32: Aluminum oxide grains partially annotated
on the ZEISS arivis Cloud platform for Machine Learning
and Deep Learning training. The green areas indicate the
aluminum oxide grains, the blue outlines correspond to the
grain boundaries, and the red areas represent inclusions
and pores.
Figure 33: Conventional Machine Learning settings
in ZEN for the aluminum oxide grain segmentation
training. ‘Deep Features 64’ setting extracts 64 features
from the training regions, and the ‘Conditional Random
Field’ postprocessing refines the segmentation result by
incorporating contextual information.Case studies
Examples from Materials Sciences
Improving microstructure analysis of aluminum oxide with Deep
Learning
Segmentation of aluminum oxide grains:
Machine Learning vs. Deep Learning
The efficiency of conventional Machine
Learning and Deep Learning approaches for
image segmentation of aluminum oxide grains
were compared using images collected from
a polished aluminum oxide sample (courtesy
of Bernthaler group at Hochschule Aalen).
Images were captured using a ZEISS Crossbeam
550 focused ion beam scanning electron
microscope with a pixel size of 0.03 μm x
0.03 μm and 2048 x 1536 pixels in x and y
dimensions.
A backscattered electron detector provided
the necessary contrast between the aluminum
oxide grains and grain boundaries, where grain
boundaries appear darker than the grains. A
single random image from the image stack was
— — — — — — — — — — — — — — —
Page 105
103 Case Studies: Examples from Materials Science
Discover further information on the
features used in ZEN
www.zeiss.com/zen-intellisis-feature-extractors
Figure 34: (a) Electron microscopy image of aluminum oxide microstructure. (b) Segmentation result of (a) obtained by
applying a conventional Machine Learning model trained using the annotations from Figure 32 . (c) Close-up of the area
outlined by the square in (b). Although conventional Machine Learning methods produce results that appear satisfactory,
upon closer examination, it becomes evident that numerous grain boundaries are not continuous. As a result, any attempt
to measure grain size using this image would result in erroneous fi ndings that are biased toward larger grain sizes. (d)
Segmentation result of (a) obtained by applying a Deep Learning model trained using the annotations from Figure 32 .
(e) Close-up of the area outlined by the square in (d) . Deep Learning segmentation resulted in continuous grain boundaries,
which will yield more reliable grain size measurements.selected for training. The image was partially
annotated on the ZEISS arivis Cloud platform,
where pixels corresponding to the grains, grain
boundaries, and inclusions were painted using
a digital pen to defi ne the ground truth (see
Figure 32 ).
The annotations were used to train a Deep
Learning model on the ZEISS arivis Cloud
platform. arivis Cloud employs the widely
recognized U-net architecture [1] for image
segmentation but with encoder and decoder
modifi cations to increase speed and accuracy.
Additionally, the annotations were exported
to ZEN for use as ground truth labels for
conventional Machine Learning training.
Features from the training regions were
extracted using the ‘Deep Features 64’ setting
(see Figure 33 ). This setting extracts 64 features
by applying ‘layer 1’ from the VGG19 network
[2], pretrained on over 14 million images from the ImageNet database. It’s important to note
that no Deep Learning training occurs during
the Machine Learning training process. Instead,
the pre-trained Deep Learning network is being
used to extract features, which then serve
as input to a conventional Machine Learning
algorithm, Random Forest.
Deep Learning outperforms Machine
Learning for grain segmentation
The results from both the Machine Learning
and Deep Learning segmentation, respectively,
for a random image in the dataset are shown
in Figure 34 . Similar to the training annotations,
the segmentation result shows aluminum oxide
grains in green, grain boundaries in blue, and
inclusions in red. While the Machine Learning
segmentation (see Figure 34b ) appears to be
— — — — — — — — — — — — — — —
Page 106
104
Case Studies: Examples from Materials Science
Figure 35: (a) Electron microscopy image of aluminum oxide microstructure, identical to that shown in Figure 34a . (b)
Grain Size Analysis using the image segmented by conventional Machine Learning incorrectly assigns the bulk of the pixels
to a single large grain, shown in red. (c) Analysis using the Deep Learning-segmented image demonstrates that the grains
are correctly identified, offering more precise grain size distribution data when compared to Machine Learning.acceptable at first glance, many discontinuous
grain boundaries are observed on closer
inspection (see Figure 34c ). This is due to the
inability of the pre-engineered features to
properly present the grain boundary features to
the Machine Learning algorithm, despite being
pre-trained on 14 million images. Any grain
analysis using this approach will lead to an
overestimated grain size distribution. Feature
learning via Deep Learning training helps here,
as it can learn the appropriate features needed
to represent the grain boundaries accurately.
Deep Learning successfully segmented the
grain boundaries (see Figure 34d ), whereas
conventional Machine Learning failed (see
Figure 34c ).
Segmentation is often an intermediate step
in a bigger analysis goal, such as Grain Size
Analysis. Figure 35 shows the results from
Grain Size Analysis using the respective
segmented images from Machine Learning and
Deep Learning approaches. The analysis was
performed using the ZEN software by assigning
all enclosed regions within continuous grain
boundaries to a specific grain.
The Deep Learning-based segmentation
produces continuous grain boundaries that
accurately represent the true grain structure
in the aluminum oxide micrograph. However,
the porous grain boundaries from the Machine
Learning segmentation resulted in the bulk
of the image being detected as a single grain
(shown as the red region in Figure 35b ). Any subtle changes in image quality can result in
significant differences in quantitative results
if image segmentation is inconsistent. Deep
Learning has better generalization ability
and can forgive image variability to some
extent, making it ideal for tasks where even
subtle image variability is expected, and for
applications that need highly reproducible
results with minimal human intervention.
Importance of grain size measurement in
aluminum
Measuring grain size in aluminum is critical
to ensuring material quality and performance
in aerospace, automotive, and construction
industries. Aluminum’s widespread use in
various industries is due to its exceptional
mechanical properties, including strength,
ductility, and toughness, all of which are
significantly influenced by grain size.
Enhancing grain size measurement in
aluminum
Smaller grain sizes generally result in higher
strength and improved ductility, while larger
grain sizes tend to have the opposite effect.
Precise measurement of grain size is, therefore,
crucial to ensure the quality and performance
of aluminum materials across diverse
applications.
Optical microscopy coupled with chemical
etching using Barker’s reagent is the traditional
method for measuring grain size in aluminum.
This process involves polishing a sample,
— — — — — — — — — — — — — — —
Page 107
105
Case Studies: Examples from Materials Scienceetching it to reveal grain boundaries, and
examining it under a microscope with polarized
light. The grain size is determined by counting
the number of grains per unit area or by
manually measuring the average grain diameter
via point counting or intensity thresholding.
Despite its effectiveness, these approaches are
challenging because accurately segmenting
colorful images obtained from the color
etching process is unreliable and often
necessitates inefficient manual calculations.
Challenges with segmenting color-etched
aluminum images
Image segmentation of color-etched aluminum
samples poses several unique challenges. These
include:
■Polishing artifacts: Aluminum alloys
can be challenging to polish, leading
to the presence of micro scratches and
contamination in samples. These flaws,
combined with other artifacts from
the polishing process, complicate grain
segmentation.
■Non-uniform coloring: The color etching
process may not uniformly color all grains of
the same size, resulting in variations in the
color contrast between adjacent grains.
■Grain boundary interference: The color
contrast between adjacent grains may not
be distinct enough to accurately identify the
grain boundaries.
■Overlapping grains: In some cases, adjacent
grains may overlap or appear connected,
making it difficult to accurately distinguish
their boundaries.
■Anisotropy: The color etching process may
reveal different colors depending on the
crystallographic orientation of the grains,
resulting in anisotropy in the color contrast.These challenges underscore the need for
advanced automated techniques.
Limitations of intensity-based
segmentation
Traditional segmentation methods based on
intensity analysis typically involve dividing
images with bimodal intensity profiles into
distinct regions using pixel intensity values. For
example, a predetermined threshold is applied
to differentiate between pixels representing
grain boundaries, which typically exhibit
lower intensity values, and those representing
grains, characterized by higher intensity values.
However, this approach is inadequate for
accurately segmenting images obtained from
Barker-etched aluminum, even when they are
of high quality.
One notable limitation is its tendency to
misclassify darker areas within grains, such as
pitting and cracks, as grain boundaries. This
misclassification can be observed in Figure 36b,
where, in addition to identifying actual grain
boundaries, all dark pixels within the interior
region of the grains are erroneously classified
as grain boundaries. For accurate segmentation
of these grains, it becomes imperative to
account for additional features beyond pixel
intensities alone. Machine and Deep Learning
approaches can use multiple image attributes
to train algorithms that effectively detect and
delineate grains.
— — — — — — — — — — — — — — —
Page 108
106
Case Studies: Examples from Materials ScienceFigure 36: Limitations of threshold-based segmentation. (a) Original image of an aluminum sample etched with Barker’s
reagent and imaged under a microscope with polarized light. (b) Segmentation of grain boundaries using a threshold-
based approach on pixel intensity. Dark regions within grains, such as pitting and cracks, are erroneously segmented as
grain boundaries, shown in yellow.
Figure 37: Limitations of conventional Machine Learning. (a) Original image of an aluminum sample etched with Barker’s
reagent and imaged under a microscope with polarized light. (b) Segmented image illustrating different grains in various
colors. The segmentation method is suboptimal as large regions are incorrectly identified as single grains.
Integrating AI into segmentation
Conventional Machine Learning techniques
have proven efficient at image segmentation
tasks. The process involves the extraction of
diverse features from images through the
application of digital image filters. These
extracted features are subsequently input
into Machine Learning algorithms, such as
Random Forest, to facilitate segmentation.
However, even with these methods, achieving
satisfactory results for grain segmentation in
aluminum alloys treated with Barker’s solution
remains a challenge, as depicted in Figure 37b. The inadequate performance of conventional
Machine Learning can be attributed to the
challenges outlined earlier. The limited set of
image attributes used in conventional Machine
Learning fails to adequately address the
complexity inherent in the segmentation task.
Harnessing Deep Learning for
segmentation of color-etched aluminum
Instance segmentation offers promising
solutions to the challenges encountered in
traditional methodologies. By leveraging Deep
Learning algorithms, this technique enables
— — — — — — — — — — — — — — —
Page 109
107
Case Studies: Examples from Materials Scienceaccurate detection and segmentation of
individual grains in color-etched aluminum
samples.
Unlike conventional methods, instance
segmentation can effectively handle irregular
shapes, overlapping grains, and anisotropic
color contrasts. Moreover, its automation
capability ensures consistent and objective
grain size measurements, minimizing human
error and enhancing overall efficiency.
Figure 38: Accurate grain segmentation through instance segmentation. (a) Original image of an aluminum sample
etched with Barker’s reagent and imaged under a microscope with polarized light. (b) Segmented image resulting from
instance segmentation, accurately delineating grains and grain boundaries. Grains and grain boundaries are depicted in
random colors for visualization purposes. The instance segmentation model used for this segmentation was trained on
ZEISS arivis Cloud.
The benefits of instance segmentation
Adopting instance segmentation brings
several benefits to grain size measurement in
aluminum:
■Accurate detection of individual grains, even
in complex or irregular structures.
■Precise measurement of grain size and
shape, enhancing data accuracy.
■Clear identification of grain boundaries,
facilitating accurate segmentation.
Figure 39: Enhanced grain segmentation in a challenging aluminum sample. (a) Original image displaying numerous
artifacts, including polishing streaks, contamination, and blurred grain boundaries. (b) The result from instance
segmentation showcasing precise separation of grains and grain boundaries. Grains are depicted in random colors for
visualization purposes. The instance segmentation model used for this segmentation was trained on ZEISS arivis Cloud.
— — — — — — — — — — — — — — —
Page 110
108
Case Studies: Examples from Materials ScienceSummary
In summary, incorporating instance
segmentation into the grain size measurement
process for aluminum offers a transformative
approach, addressing the limitations of
traditional methodologies. AI solutions such
as ZEISS arivis Cloud provide accessible tools
for creating customized instance segmentation
models without the need for coding expertise
and seamlessly integrates AI segmentation
within the image acquisition and analysis
pipeline, streamlining the AI segmentation
process and making advanced image analysis
techniques more accessible. All images used
in this case study are courtesy of IMFAA
Hochschule Aalen. ■Automation of the measurement process,
saving time and reducing the frequency of
errors.
■Consistent and objective measurements,
ensuring reliability and reproducibility.
It yields reliable results suitable for further
downstream analysis, such as evaluating grain
size distribution. Figure 38b shows grains from
the original image accurately segmented by
accurately defining the boundaries between
them.
Training custom instance segmentation
models using ZEISS arivis Cloud
A custom model tailored for grain
segmentation in Barker-etched aluminum
polarized images has been trained on ZEISS
arivis Cloud. This trained model was then
applied to segment a challenging image from
a sample showing various artifacts, including
polishing streaks, contamination, and blurred
grain boundaries. Figure 39b demonstrates the
excellent grain segmentation achieved using
this approach and highlights the superiority
of instance segmentation compared to other
methods.
References
1.Ronneberger O, Fischer P, and Brox, T. U-Net: Convolutional Networks for Biomedical Image
Segmentation. (2015) arX iv:1505.04597 doi: 10.48550/arXiv.1505.04597.
2.Simonyan K, Zisserman A. Very Deep Convolutional Networks for Large-Scale Image
Recognition. (2014) arX iv:1409.1556v6 doi: 10.48550/arXiv.1409.1556
— — — — — — — — — — — — — — —
Page 111
109
Case Studies: Examples from Materials Science
— — — — — — — — — — — — — — —
Page 112
110
Case Studies: Examples from Materials ScienceC45 steel, also known as AISI 1045 steel
or S45C steel, holds significant importance
in various industries due to its exceptional
properties and versatile applications:
■Shaft manufacturing: C45 steel is
chosen for shafts due to its high tensile
strength and fatigue resistance, crucial for
enduring mechanical forces and prolonging
operational lifespan.
■Gears and sprockets: The wear resistance
of C45 steel suits gears and sprockets, vital
for power transmission systems, enduring
constant friction and abrasion to maintain
efficiency.
■Machine parts: The superior machinability
of C45 steel makes it ideal for various
machine parts like bolts, nuts, and studs,
enabling easy shaping and machining.
■Automotive parts: C45 steel is favored in
automotive components such as crankshafts
and axles for its high tensile strength
and toughness, ensuring reliable engine
performance and longevity.
■Construction machinery: The strength
and durability of C45 steel make it a
top choice for construction machinery
components like excavators and cranes,
capable of withstanding heavy loads and
harsh environments.
This case study explores the challenges of
segmenting ferrite and pearlite phases in
C45 steel microstructures, which is crucial
for understanding its mechanical properties
and performance. We discuss the importance
of grain size measurement in steel, common
methods used, and how AI-driven instance
segmentation emerges as a solution to Instance segmentation in C45 steel analysis: Improving microstructural
insights with AI
the challenges encountered in accurately
segmenting ferrite and pearlite grains.
Importance of grain size measurement
in steel
C45 steels consist of various grains belonging
to primarily two phases: ferrite and pearlite.
Nital etching is a common practice to reveal the
grain structure in these alloys. Measuring the
grain size of C45 steel is vital as it significantly
influences its mechanical properties, including
strength, toughness, ductility, and fatigue
resistance. Plus, grain size affects machinability
and weldability.
By measuring grain size, manufacturers can
optimize the manufacturing process and ensure
materials meet required specifications, aiding in
quality control and failure analysis.
Common grain size measurement
methods
Metallography employs various methods for
grain size measurement, including:
Comparison chart method
This method relies on comparing the
microstructure of the sample with a standard
chart or image containing known grain
sizes. By visually matching the sample’s
microstructure to the closest standard, the
grain size can be estimated. While relatively
straightforward, this method is subjective
and depends heavily on the observer’s
interpretation.
Linear intercept method
In this method, a line is drawn across the
microstructure, intercepting a specified
number of grains. The length of each intercept
is measured, and the average grain size is
calculated based on these measurements.
Although it provides statistical data, this
— — — — — — — — — — — — — — —
Page 113
111
Case Studies: Examples from Materials Sciencemethod may not account for grains that lie
outside the intercept lines, potentially leading
to inaccuracies.
Planimetric method: This method involves
measuring the area of a specified number of
grains within the microstructure. By dividing
the total area by the number of grains, the
average grain size can be determined. While
offering a more comprehensive assessment
of grain size distribution, this method can be
time-consuming and may require advanced
image analysis techniques for accurate
segmentation.
Each method has its strengths and limitations,
and the choice depends on factors such as the
complexity of the microstructure, the desired
level of detail, and the available resources for
image analysis.
Challenges in ferrite and pearlite
segmentation
Segmenting ferrite and pearlite in steel
microstructures poses several challenges:
■Similar appearance under optical
microscopy.
■Complex morphologies and orientations.
■Interference from other constituents like
carbides and martensite.
■Image quality issues such as poor lighting
and low contrast.
These challenges necessitate advanced image
analysis techniques for accurate segmentation.
AI-based segmentation techniques
Artificial intelligence has revolutionized
image analysis. Deep Learning, in particular,
has demonstrated remarkable capabilities
in achieving precise and reproducible
segmentation results across diverse datasets and is particularly suited to measuring grain
size in steel.
Semantic segmentation
Semantic segmentation, a key approach
within Deep Learning-based segmentation,
involves classifying each pixel in an image.
This technique enables the segmentation of
contiguous pixels representing distinct phases
or regions within the image.
Semantic segmentation is invaluable for
accurately delineating structural elements
such as ferrite and pearlite phases in C45 steel
microstructures. This approach is appropriate
for area fraction measurements, where details
down to the grain level are not required.
Instance segmentation
Instance segmentation represents a further
refinement of semantic segmentation, as it
not only classifies pixels but also identifies
and delineates individual grains or objects.
This approach provides detailed insights into
microstructural characteristics, facilitating
advanced analysis such as grain size distribution
for various phases in the material.
Analysis of Nital-etched polished C45
steel samples
In this study, images of Nital-etched polished
C45 steel samples were examined. These
images were captured using a light microscope
under brightfield imaging. The images exhibit
three distinctive regions:
1. Bright areas with higher pixel values.
2. Dark areas with lower pixel values.
3. Regions with pixel values between bright
and dark.
Bright regions correspond to ferrite, while
darker regions represent pearlite. Additionally,
the intermediate regions with medium
— — — — — — — — — — — — — — —
Page 114
112
Case Studies: Examples from Materials Scienceintensities were attributed to the pearlite phase
for the purposes of this study.
Segmentation of grains in these images
presents challenges even for human observers
due to the ambiguity in assigning regions to
specific phases based on intensity, especially
in areas with medium intensities. Furthermore,
identifying grain boundaries that separate
grains can be challenging, particularly for
pearlite, where the contrast around grain
boundaries is not discernible against the busy
texture of pearlite.
C45 steel grain analysis results using
AI-based methods
To overcome these challenges, an instance
segmentation model was trained on ZEISS
arivis Cloud. The model was trained using
annotations of a handful of random grains
from a selection of images, providing ground
truth for both ferrite and pearlite grains
separately.
This approach ensures that the phases
are segmented accurately and that the corresponding grains are identified, allowing
for grain size distribution analysis of the
respective phases.
The trained model was then imported into
ZEISS arivis Pro and used to segment and
analyze multiple images, including the one
shown in Figure 40a. It is important to note
that ZEISS arivis Cloud-trained models can
be seamlessly imported into various ZEISS
software packages, including ZEN, ZEN
core, and ZEISS arivis Pro. In this study, ZEISS
arivis Pro was chosen for its capability to
accommodate and automate customized
downstream image analysis routines.
Figure 40b illustrates the instance
segmentation result, with ferrite and pearlite
phases clearly separated and overlaid on the
original image in blue and yellow, respectively.
This image closely resembles the result
obtained from semantic segmentation, which
aims to segment individual phases, thus
allowing the quantification of area fractions for
each phase, as illustrated in Figure 41a .
Figure 40: Instance segmentation results. (a) Original image of Nital-etched polished C45 steel sample captured under an
optical microscope using brightfield illumination. (b) Instance segmentation result overlaying ferrite and pearlite phases on
the original image. Ferrite is depicted in blue, while pearlite is shown in yellow. (c) Color-coded visualization of all instance-
segmented grains based on their size, with blue indicating small grains, red representing large grains, and intermediate
sizes represented by colors spanning the spectrum between blue and red. (d) Visualization similar to panel (c) but focusing
solely on grains belonging to the ferrite phase.
— — — — — — — — — — — — — — —
Page 115
113
Case Studies: Examples from Materials ScienceSummary
In summary, training an AI model on ZEISS
arivis Cloud and importing it to ZEISS arivis Pro
enables efficient segmentation and analysis of
multiple images at scale. This approach offers
comprehensive insights into the microstructural
features of Nital-etched polished C45 steel
samples, facilitating accurate analysis through
an automated pipeline.
Figure 41: Analysis of segmented phases. (a) Pie chart illustrating the area fractions of ferrite and pearlite phases
calculated from the instance segmentation result (Figure 40b). (b) Scatter plot demonstrating the relationship between
grain areas and mean intensities. The plot showcases distinctions in mean intensities between pearlite (yellow data points)
and ferrite (blue data points) grains.
In addition to determining area fractions, our
instance segmentation approach provides
information down to the grain level, facilitating
grain distribution analysis for all grains, both
phases combined, and individually. Figure 40c
displays all grains color coded according to
their size, with colors ranging from blue for
small grains to red for large grains. Figure 40d
presents a similar visualization but only for
grains belonging to the ferrite phase.
Beyond visualization, the grain data enables
further analysis, as demonstrated in Figure
41b, where grain areas are plotted against
the corresponding mean intensities. The plot
reveals differences in mean intensities between
pearlite (yellow data points) and ferrite (blue
data points) grains.
— — — — — — — — — — — — — — —
Page 116
Summary 114Summary
This book provided a comprehensive overview
of the importance of AI in image analysis,
presenting a diverse array of use cases and
demonstrating how to leverage this technology
effectively.
The first chapter introduced readers to the
concept of AI and its growing significance
in research, particularly in image analysis.
It explained the distinctions between AI,
Machine Learning, and Deep Learning,
emphasizing Deep Learning’s suitability for
challenging image analysis tasks. The chapter
also introduced ZEISS software products that
make AI accessible to a wide range of users.
Chapter two focused on image segmentation,
offering a historical perspective on various
approaches, from Otsu thresholding to
Deep Learning. This chapter provided the
necessary background about AI-based image
segmentation, laying the groundwork for
subsequent chapters where readers would
learn about the use of this technology for
diverse applications using various ZEISS
software packages.
The third chapter, new to this edition, explored
ZEISS arivis software for AI-powered image
analysis. It explained how ZEISS arivis Cloud
simplifies the training of custom image
segmentation models, which can be imported
into ZEISS arivis Pro for automated analysis of
multi-dimensional large images. The chapter
also discussed scaling image analysis using
multiple processors on ZEISS arivis Hub and the
ability to create ground truth labels in 3D using
the immersive ZEISS arivis Pro VR environment.
Chapter four, another new addition, focused
on AI integration in ZEN and ZEN core
software. It explored how AI can guide image
acquisition, enabling smart microscopy. The
chapter detailed various AI-powered tools
within these software packages, including AI-based denoising, object classification,
and pre-packaged applications in BioApps
and Material Apps for tasks ranging from cell
counting to Grain Size Analysis.
In the fifth chapter, the book discussed
how AI tools could be used in routine
image analysis applications. Integration of
AI was demonstrated using examples from
microscopy, such as tissue and blood sample
analysis for atypical cells and cell morphologies.
Furthermore, it showed how AI tools help
with repetitive and time-consuming tasks and
eliminate human error. The chapter reviewed
the ZEISS Labscope imaging app and showed
how its AI modules benefit these applications.
Chapter six, a new addition, explored the
use of Deep Learning for X-ray microscopy
reconstruction. It covered X-ray microscopy
basics, including how dual-stage magnification
achieves high resolution from large samples.
The chapter then explained how Deep
Learning-based reconstruction can increase
throughput without compromising resolution
compared to traditional FDK reconstruction.
Since the use of AI technology had become
increasingly significant in science and industry,
the seventh and final chapter of the book
centered on an expanded collection of case
studies. These case studies highlighted how AI-
enabled analysis of microscope image datasets
provided new and faster answers to research or
engineering problems. One of the case studies
demonstrated the potential application of AI
tools in segmenting and measuring organelles,
characterizing mitochondria, and classifying
the spatial distribution of nuclear pores using
a volumetric FIB-SEM dataset. Another case
study demonstrated how AI image analysis
assisted in understanding Wnt inhibition
in organoid formation. New case studies
included examples such as segmenting mouse
muscle 3D ultrastructure, enhancing grain size
— — — — — — — — — — — — — — —
Page 117
Summary 115measurement in aluminum, and segmenting
phases in C45 steels, among others.
For readers looking to apply AI technology to
their own image analysis, here are a couple of
additional tips and best practices to keep in
mind.
■Carefully consider the problem and
determine whether AI is the appropriate tool
to use.
■Have a clear understanding of the data and
ensure that there is sufficient high-quality
data to train the models.
■Select the AI tools carefully, as different
algorithms may be better suited to
different types of data and analysis tasks.
For example, the instance segmentation
algorithm is better suited to segment
individual cells separately, while the semantic
segmentation algorithm is more appropriate
when cells need to be segmented collectively
from the background.
■Continually evaluate and validate the models
and incorporate feedback from domain
experts to ensure accurate and meaningful
results.
In conclusion, this updated edition offered
readers an in-depth exploration of AI’s
capabilities in image analysis, inspiring them
to further investigate these techniques in their
own research and work. As AI continues to
evolve rapidly, this book serves as a valuable
resource for unlocking new insights and
capabilities across various scientific disciplines.
Thank you for your time and interest in this
book.
Dr. Sreenivas Bhattiprolu
— — — — — — — — — — — — — — —
Page 118
116Our software is powerful, fl exible, and easy
to use, making it easy to get started with your
image analysis. It is the perfect solution for
researchers, engineers, and scientists.The ZEISS arivis image analysis platform off ers
scalable software tools on a desktop, server,
and in the cloud. With the ZEISS arivis product
portfolio, researchers can easily perform
advanced image analysis to extract information
from image data, regardless of its complexity.
No matter the source and format of the image,
our products are highly integrated, providing
users in academia and across varied industries
with a streamlined image processing and
analysis process for enhanced effi ciencies due
to automation and user-friendliness.
The ZEISS arivis family of products
www.zeiss.com/arivisZEISS arivis family of products
ZEISS arivis Pro
With ZEISS arivis Pro, you can unlock the
full potential of your scientifi c images. Our
powerful tools help you create seamless
analysis pipelines, eff ortlessly process massive
multidimensional datasets, and get the insights
you need to make better decisions.
Here are some of the features of ZEISS arivis
Pro:
■Automated end-to-end image analysis
pipelines, created with just a few clicks.
■Multi-dimensional image analysis is made
easy with an easy-to-use interface.
■Numerous AI-powered tools for automated
image analysis.
■Effi cient handling of large quantities of data,
with the capability to load millions of objects
seamlessly.
■Optional VR toolkit for an even more
immersive experience.
ZEISS arivis Pro
www.zeiss.com/arivis-pro
ZEISS Microscopy Software Solutions
ZEISS Microscopy Software SolutionsVisit our website to learn more:
— — — — — — — — — — — — — — —
Page 119
117The ZEISS arivis family of products
www.zeiss.com/arivis
Designed for biotech, pharma, materials
science, electronics, and more.
Upgrade your image analysis capabilities
with ZEISS arivis Cloud. Collaborate and train
custom Deep Learning models from anywhere
with ease. Get reproducible and reliable results
faster.
ZEISS arivis Cloud
ZEISS arivis Cloud provides the tools necessary
to train custom Deep Learning models for
semantic (pixel-level) and instance (object-level)
segmentation. These models can then be
used as part of image analysis pipelines in
ZEN and ZEISS arivis Pro to power automated
smart image acquisition and analysis of large
datasets.
Key features:
■Customizable Deep Learning models for
pixel and object segmentation in images.
■Export models to automate image analysis
using ZEN and ZEISS arivis software.
■Easy portability and collaboration.
■No coding required!ZEISS arivis Hub
ZEISS arivis Hub has got you covered when
you want to scale up your image analysis. This
powerful platform enables you to optimize
your computing resources, import and organize
your datasets, and manage your data access
and identifi cation with ease, making it ideal
for 2D and 3D High Content Analysis (HCA)
applications.
Key capabilities include the ability to:
■Parallelize your computations for enhanced
scalability.
■Easily create workfl ows with one or multiple
pipelines for connecting various analysis
tasks into one streamlined process.
■View your spatially resolved results directly
on your raw datasets, saving you time and
increasing cost effi ciency.
ZEISS arivis Cloud
www.zeiss.com/arivis-cloud
ZEISS arivis Hub
www.zeiss.com/arivis-hub
ZEISS Microscopy Software SolutionsWhether your images are already stored or
currently being generated, ZEISS arivis Hub
onboards them and schedules analysis jobs for
optimized and maximized throughput.
— — — — — — — — — — — — — — —
Page 120
118ZEISS provides end-to-end microscopy
software solutions that are fully integrated
with every imaging system from ZEISS. No
matter the complexity of your imaging needs
or application, ZEISS will fi nd the hardware and
software solution you need. ZEISS ZEN family of products
ZEISS ZEN
www.zeiss.com/zen
ZEISS Microscopy Software SolutionsZEN microscopy software
ZEN is your complete solution from sample to
knowledge. Whether you’re a beginner or an
expert, ZEN has everything you need to get the
most out of your microscopy experiments.
ZEN is the universal user interface on every
ZEISS imaging system. It provides intuitive
tools and modules to assist you with all your
microscopy tasks. Whether you need to:
■Quickly and easily acquire high-quality
images using smart automation.
■Process images using scientifi cally proven
algorithms.
■Visualize big data with a GPU-powered 3D
engine.
■Analyze images using Machine Learning-
based tools.
■Correlate between light and electron
microscopes to gain a deeper understanding
of your samples.With ZEN, you can design multi-dimensional
workfl ows exactly the way you want. ZEN’s
intuitive tools and modules make it easy to
accomplish simple tasks, while still off ering
the fl exibility to tackle even the most complex
research experiments.
ZEISS Light Microscopy Software
www.zeiss.com/light-microscopy-software
— — — — — — — — — — — — — — —
Page 121
119
ZEISS ZEN core
www.zeiss.com/zen-coreZEISS ZEN core
ZEISS ZEN core is your ultimate software suite
for connected microscopy from materials lab
to production. It off ers a range of imaging,
segmentation, analysis, and data connectivity
tools that make it the most comprehensive
solution for multi-modal microscopy in
connected material laboratories.
With ZEN core, you get:
■An adaptive user interface that’s easy to
confi gure and use.
■Advanced imaging and automated analysis
tools.
■Data connectivity features that are designed
to work seamlessly across all your connected
devices and equipment.
ZEISS Microscopy Software SolutionsZEN core is the perfect software suite for
anyone who needs comprehensive microscopy
capabilities, from materials lab researchers to
production teams. With ZEN core, you can take
your microscopy experiments to the next level
and get the insights you need to make better
decisions.
— — — — — — — — — — — — — — —
Page 122
120Other software solutions
ZEISS Labscope
ZEISS Labscope is your easy-to-use imaging
app. With it you can connect all the
microscopes in your lab or classroom to a
digital network and display their live images
simultaneously from anywhere in the room.
Getting reproducible results faster has never
been easier or more fun.
Here’s how Labscope can help you:
■Eff ortlessly observe and share images in
real-time in your digital network.
■Snap images, record videos, and measure
samples with a push of a button. Increase
effi ciency with dedicated features that are
targeted at routine tasks.
■Collaborate and teach with ease as you
observe your students in real-time. Switch
easily between microscopes in the lab
and in class, turning each lesson into a
demonstration.
ZEISS Microscopy Software Solutions
ZEISS Labscope is the perfect solution for
connecting and managing all your microscopes
in one place. Say goodbye to manual juggling
and hello to easy digital networking, fast
results, and collaborative teaching with
Labscope.
ZEISS Labscope
www.zeiss.com/labscope
— — — — — — — — — — — — — — —
Page 123
121ZEISS DeepRecon Pro
Part of the Advanced Reconstruction Toolbox
(ART), ZEISS DeepRecon Pro leverages AI
to tackle complex imaging challenges with
innovative solutions. As the fi rst commercially
available Deep Learning reconstruction
technology for X-ray microscopes (XRM), it
transforms how you handle big data.
Key benefi ts of ZEISS DeepRecon Pro:
■Unlock the potential of big data generated
by your XRM.
■Increase throughput by up to 10× without
compromising resolution or image quality.
■Intuitive interface, enabling even novice
users to operate with ease.
■Support for diverse sample types, sizes, and
shapes.
ZEISS DeepRecon Pro
www.zeiss.com/art
Experience the robust and continuously
evolving innovations from ZEISS X-ray
Microscopy with the Advanced Reconstruction
Toolbox.
ZEISS Microscopy Software Solutions
— — — — — — — — — — — — — — —
Page 124
Contributors 122Contributors
Chapter 1: What is AI and why does it matter?
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Ofra Kleinberger-Riedrich, Sr. Content & Product Marketing Manager, Carl Zeiss Microscopy
GmbH
Chapter 2: How to train custom AI models for image segmentation
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Ofra Kleinberger-Riedrich, Sr. Content & Product Marketing Manager, Carl Zeiss Microscopy
GmbH
■Dr. Simon Franchini, Technical Lead Machine Learning, Carl Zeiss Microscopy GmbH
Chapter 3: AI in ZEISS arivis software for scalable automated analysis
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Maria Marosvoelgyi, Product Manager, Carl Zeiss Microscopy Software Center Rostock GmbH
Chapter 4: AI in ZEN and ZEN core imaging and analysis platform
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Dr. Marion Lang, Product Manager, Carl Zeiss Microscopy GmbH
■Dr. Sebastian Rhode, Software Architect - AI Solutions, Carl Zeiss Microscopy GmbH
Chapter 5: AI for routine image analysis using ZEISS Labscope
■Anke Koenen, Marketing Specialist, Carl Zeiss Microscopy GmbH
■Dr. Michael Gögler, Market Sector Manager, Carl Zeiss Microscopy GmbH
■Dr. Benjamin Schwarz, Market Sector Manager, Carl Zeiss CMP GmbH
— — — — — — — — — — — — — — —
Page 125
Contributors 123Chapter 6: AI for X-ray microscopy with Deep Learning-based reconstruction
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Dr. Nicolas Gueninchault, Product Marketing Manager, Carl Zeiss X-ray Microscopy, Inc.
Chapter 7: Case studies: Examples from Life sciences
Microscopy and Deep Learning for Neurological Disease Research
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Dr. Kevin O’Keefe, Senior Software Sales Biotech Pharma, Carl Zeiss Microscopy, LLC
■Dr. Amita Gorur, Senior Applications Scientist, Carl Zeiss Microscopy, LLC
■Dr. Christopher Zugates, Head of Customer Success, Carl Zeiss Microscopy, LLC
■Dr. Andy Schaber, Product Application Sales Specialist, Carl Zeiss Microscopy, LLC
Organoid analysis
■Dr. Philipp Seidel, Product Marketing Manager Life Sciences Software, Carl Zeiss Microscopy
GmbH
■Dr. Volker Doering, Application Development Engineer, Life Sciences Automation, Carl Zeiss
Microscopy GmbH
Enhancing single-cell analysis with instance segmentation in phase contrast
microscopy images
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Dr. Sandra Lemke, Product Owner - AI and Applications, Carl Zeiss Microscopy GmbH
■Dr. Frank Vogler, Applications Specialist, Carl Zeiss Microscopy Deutschland GmbH
■Dr. Marion Lang, Product Manager, Carl Zeiss Microscopy GmbH
— — — — — — — — — — — — — — —
Page 126
Contributors 124Analysis of FIB-SEM volume electron microscopy data
■Dr. Mariia Burdyniuk, Customer Success Specialist, Carl Zeiss Microscopy, LLC
■Dr. Christopher Zugates, Head of Customer Success, Carl Zeiss Microscopy, LLC
Analysis of Mitochondria Using Deep Learning
■Dr. Mariia Burdyniuk, Customer Success Specialist, Carl Zeiss Microscopy, LLC
■Dr. Wendy Bautista, Physician Scientist, National Cancer Institute (NCI)
■Dr. Mones Abu Asab, Senior Ultrastructural Scientist, National Eye Institute, NIH
Segmenting mouse muscle 3D ultrastructure
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Joy James Costa, Application Engineer, Carl Zeiss Microscopy Software Center Rostock GmbH
■Dr. Federico Ribaudo, Product Manager arivis Pro, Carl Zeiss Microscopy Software Center
Rostock GmbH
Enhancing the utility of zebrafish models to study infectious diseases using Deep
Learning
■Dr. Serge Mostowy, Department of Infection Biology, London School of Hygiene and Tropical
Medicine
■Dr. Margarida C. Gomes, Mostowy Lab, Department of Infection Biology, London School of
Hygiene & Tropical Medicine
■Ofra Kleinberger-Riedrich, Sr. Content & Product Marketing Manager, Carl Zeiss Microscopy
GmbH
Exploring mouse embryo development with microCT and AI
■Joy James Costa, Application Engineer, Carl Zeiss Microscopy Software Center Rostock GmbH
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Rachna Parwani, Product Applications Development Engineer, Carl Zeiss X-ray Microscopy, Inc.
■Dr Rosy Manser, Solution Manager X-Ray Microscopy, Life Science Sector, Carl Zeiss Limited, UK
— — — — — — — — — — — — — — —
Page 127
Contributors 125Case studies : Examples from Materials science
Improving microstructure analysis of aluminum oxide with Deep Learning
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Tim Schubert, Materials Scientist, Institut für Materialforschung (IMFAA)
Enhancing grain size measurement in aluminium
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Torben Wulff, Business Sector Manager, Materials Science, Carl Zeiss Microscopy GmbH
Instance segmentation in C45 steel analysis: Improving microstructural insights
with AI
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
■Torben Wulff, Business Sector Manager, Materials Science, Carl Zeiss Microscopy GmbH
Summary
■Dr. Sreenivas Bhattiprolu, Director, Digital Solutions, Carl Zeiss X-ray Microscopy, Inc.
— — — — — — — — — — — — — — —
Page 128
